| Ref | Part Number | Description |
|---|
| 0 |
640283 |
CARBURETOR Price: $76.28 |
| 1 |
112-0029 |
SPIKER ADAPTER ASM Price: $981.19 |
| 1 |
532174619 |
CHASSIS STAMPING Price: $84.99 |
| 1 |
631615 |
SHAFT & LEV Price: $6.48 |
| 2 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 2 |
532176554 |
DRAWBAR, 12GA Price: $24.99 |
| 2 |
631767 |
SPRING Price: $1.25 |
| 3 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 4 |
283-83 |
PIN-CLEVIS Price: $9.52 |
| 4 |
631184 |
WASHER Price: $1.25 |
| 5 |
3296-25 |
NUT-LOCK, NI Price: $1.34 |
| 5 |
532155272 |
BUMPER.RUBBER.HOOD Price: $3.99 |
| 5 |
631183 |
WASHER Price: $1.25 |
| 6 |
640070 |
SHUTTER Price: $1.25 |
| 6 |
92-2651 |
WASHER Price: $1.83 |
| 7 |
112-0038 |
SPACER Price: $7.34 |
| 7 |
650506 |
SCREW Price: $0.87 |
| 8 |
99-7984 |
KNOB-SOFT GRIP, PUSH-ON Price: $11.31 |
| 9 |
112-7695-03 |
HANDLE Price: $53.91 |
| 9 |
532428394 |
Price: Call Us |
| 10 |
323-12 |
SCREW-HH Price: $1.14 |
| 10 |
872110608 |
BOLT D This part replaces 872140608. Price: $3.99 |
| 11 |
75-5270 |
SPACER-KNOB, SEAT This part replaces 99-2058. Price: $4.61 |
| 12 |
144-7093 |
LINK ASM This part replaces 110-8105. Price: $105.96 |
| 13 |
323-10 |
SCREW-HH Price: $0.89 |
| 14 |
112-7686 |
LATCH Price: $40.54 |
| 15 |
3296-44 |
NUT-LOCK, NI Price: $2.46 |
| 16 |
631807 |
FUEL FITTING Price: $6.03 |
| 17 |
532185847 |
HOOD.STEEL.ELITE.YELLOW Price: $84.99 |
| 17 |
651025 |
SCREW Price: $1.18 |
| 18 |
532184921 |
BUMPER.HOOD.LARGE.1.75" Price: $3.99 |
| 18 |
630766 |
SPRING Price: $1.25 |
| 20 |
640027 |
FUEL JET Price: $2.60 |
| 20A |
640200 |
CAP (BLACK) Price: $1.20 |
| 24 |
874780616 |
BOLT Price: $3.99 |
| 25 |
631867 |
FLOAT BOWL Price: $2.34 |
| 25 |
734117201 |
WASHER This part replaces 819131312. Price: $1.99 |
| 26 |
873680600 |
LOCKNUT This part replaces 873800600. Price: $1.99 |
| 27 |
631024 |
FLOAT SHAFT Price: $1.17 |
| 28 |
532426792 |
GRILLE.ELITE.BASIC.LT.BLACK Price: $44.99 |
| 28 |
632816 |
FLOAT This part replaces 632802. Price: $5.90 |
| 29 |
532189837 |
LENS.GRILLE.BASIC.BAR.LT.CLR Price: $11.99 |
| 29 |
631028A |
GASKET This part replaces 631028. Price: $1.95 |
| 30 |
532445888 |
FENDER.LTST.W/SHFT.CUP.YELLOW Price: $109.99 |
| 30 |
631021B |
INLET NEEDLE KIT This part replaces 631021. Price: $4.82 |
| 31 |
532136619 |
BRACKET FENDER Price: $3.99 |
| 31 |
631022 |
CLIP Price: $1.25 |
| 35 |
640259 |
PRIMER Price: $6.16 |
| 35 |
872110606 |
BOLT Price: $2.99 |
| 36 |
640080 |
NOZZLE Price: $4.95 |
| 36A |
632766 |
CARB VENT TUBE Price: $1.25 |
| 37 |
632547 |
O RING Price: $1.49 |
| 37 |
817490508 |
SCREW LT Price: $3.99 |
| 38 |
532175710 |
BRACKET.ASM.PIVOT.MOWER.REAR Price: $5.99 |
| 39 |
532407807 |
BRACKET PIVOT Price: $14.99 |
| 40 |
640028 |
NUT Price: $5.16 |
| 44 |
27110A |
GASKET Price: $1.45 |
| 47 |
630748 |
WELCH PLUG Price: $1.17 |
| 48 |
631027 |
WELCH PLUG Price: $1.17 |
| 64 |
532154798 |
DASH LOWER Price: $22.99 |
| 114 |
584448901 |
KEEPER-BELT,RR.LH This part replaces 532158112. Price: $5.99 |
| 115 |
817060620 |
SCREW.3/8-16 Price: $3.99 |
| 141 |
532409148 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $2.99 |
| 142 |
532175702 |
PLATE REINFORCEMENT Price: $4.99 |
| 145 |
532409167 |
ROD.PIVOT.HOOD Price: $8.99 |
| 159 |
532185635 |
CUPHOLDER.BLACK Price: $7.99 |
| 205 |
817490608 |
SCREW LT Price: $3.99 |
| 207 |
817670508 |
SCREW, 5/16-18 X 1/2 Price: $3.99 |
| 208 |
817670608 |
SCREW 3/8-16X1/2 Price: $2.99 |
| 209 |
817000612 |
SCREW, 3/8-16X3/4 Price: $2.99 |
| 212 |
532183823 |
INSERT.LENS.REFLECTIVE.LEFT Price: $11.99 |
| 278 |
532416358 |
SCREW.#10 X 0.750.BOS (2 2) Price: $2.99 |
| 532005479 |
PLUG |
BUTTON T Price: $2.99 532005479 |
