| Ref | Part Number | Description |
|---|
| 1 |
127-7134 |
NON DRIVEN BEARING HOUSING ASM Price: $270.13 |
| 2 |
530071605 |
KIT HARNESS CLAMP This part replaces 530055392. Price: $2.99 |
| 3 |
237-22 |
O-RING This part replaces 107-8844. Price: $2.43 |
| 3 |
530015770 |
Screw Price: Call Us |
| 4 |
112-6966 |
ROLLER BRUSH ASM Price: $431.52 |
| 4 |
530071868 |
KIT TUBE CLAMP J-BAR UPGRADE This part replaces 530095970. Price: $5.99 |
| 5 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 5 |
530071868 |
KIT TUBE CLAMP J-BAR UPGRADE This part replaces 530016336. Price: $5.99 |
| 6 |
108-4480 |
BRACKET-MOUNTING Price: $34.10 |
| 6 |
530071868 |
KIT TUBE CLAMP J-BAR UPGRADE This part replaces 530095971. Price: $5.99 |
| 7 |
108-4172 |
SEAL-EXCLUDER Price: $6.52 |
| 7 |
530071585 |
Kit-Gearbox Assy. Price: $54.99 |
| 8 |
530016312 |
Screw Price: $1.99 |
| 8 |
94-6936 |
WASHER-HARDENED Price: $0.58 |
| 9 |
322-16 |
SCREW-HH Price: $3.39 |
| 9 |
530071605 |
KIT HARNESS CLAMP This part replaces 530055395. Price: $2.99 |
| 10 |
108-4491 |
SPACER Price: $11.71 |
| 11 |
112-6957 |
WASHER-HARDENED Price: $1.37 |
| 11 |
530015770 |
Screw Price: Call Us |
| 12 |
115-0821 |
PULLEY-DRIVEN, RRB (5-RIB) Price: $60.66 |
| 12 |
530096183 |
Flexshaft-Split boom Price: $2.99 |
| 13 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 13 |
530096020 |
Assy.-Driveshaft Price: $17.99 |
| 14 |
104-1843 |
FITTING-GREASE, 90 DEG Price: $5.20 |
| 14 |
530016014 |
Screw Price: $1.99 |
| 15 |
530016224 |
Screw Price: $1.99 |
| 16 |
530071383 |
Kit-Blade Shield Price: $9.99 |
| 17 |
530095815 |
Dust cup - Blade Price: $6.99 |
| 18 |
952701611 |
Accy.-Weed Blade (8") Price: $26.19 |
| 19 |
530095816 |
Washer-Blade Retaining Price: $6.99 |
| 20 |
530016240 |
Washer-Belleville Price: $1.99 |
| 21 |
530015793 |
Nut-Flange Price: $1.99 |
| 22 |
530094417 |
Assy-Shoulder Strap Price: $20.65 |
| 23 |
530031159 |
Wrench-Hex (5/32") Price: $1.99 |
