| Ref | Part Number | Description |
|---|
| 1 |
532150546 |
KIT.WHEEL.STEERING This part replaces 532121472. Price: $64.99 |
| 1 |
95-7541 |
PLATE-COVER Price: $89.04 |
| 2 |
106-1140 |
GASKET This part replaces 95-7540. Price: $17.66 |
| 2 |
532142033 |
AXLE ASSY Price: $59.99 |
| 3 |
340-70 |
NUT-LOCK Price: $2.10 |
| 3 |
532135227 |
SPINDLE LH Price: $15.39 |
| 4 |
33114-025 |
SCREW-HH Price: $0.70 |
| 4 |
532135228 |
SPINDLE RH Price: $12.97 |
| 5 |
323-6 |
SCREW-HH Price: $0.66 |
| 5 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 6 |
32128-21 |
NUT-HF Price: $0.39 |
| 6 |
532121748 |
WASHER Price: $3.99 |
| 7 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 7 |
819272016 |
WASHER Price: $3.99 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
532003366 |
BEARING.STEERING.COLUMN This part replaces 532124937. Price: $3.99 |
| 10 |
532130468 |
LINK.DRAG.SOL.BALL JT.20.064 Price: $64.99 |
| 11 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 12 |
873610600 |
NUT Price: $2.99 |
| 12 |
92-7534 |
HOSE-HYD Price: $123.48 |
| 13 |
532155134 |
KIT-AXLE This part replaces 532110438. Price: $13.26 |
| 13 |
92-7538 |
HOSE ASM Price: $167.59 |
| 14 |
106-6774 |
JOINT-BALL This part replaces 92-5838-01. Price: $79.04 |
| 14 |
874011056 |
Bolt Hex 5/8-11 Unc X 3-1/2 Price: $4.99 |
| 15 |
583612401 |
LOCKNUT M This part replaces 873901000. Price: $2.99 |
| 16 |
532132624 |
AXLE PIN Price: $2.42 |
| 16 |
92-7472 |
REAR TUBE ASM Price: $185.79 |
| 17 |
531166901 |
SERVICE KIT SHAFT ASM ST This part replaces 532140176. Price: $42.99 |
| 17 |
92-5836 |
WASHER Price: $5.34 |
| 18 |
532057079 |
THRUST WASHER Price: $1.99 |
| 18 |
98-3867 |
WASHER-THRUST Price: $3.21 |
| 19 |
532160395 |
STEERING SHAFT SUPPORT This part replaces 532124035. Price: $8.99 |
| 19 |
74-5700 |
BEARING-NEEDLE, ROLLER Price: $27.84 |
| 20 |
340-126 |
NUT-BULKHEAD Price: $4.61 |
| 20 |
596582301 |
Washers This part replaces 532126684. Price: $2.99 |
| 21 |
105-9818 |
HOSE-HYD This part replaces 92-7537. Price: $287.57 |
| 21 |
596029801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040400. Price: $2.99 |
| 22 |
532165857 |
SCREW.HX.WSH.HD This part replaces 871070410. Price: $3.99 |
| 23 |
532156365 |
PITMAN SHAFT ASSY This part replaces 532127501. Price: $29.99 |
| 24 |
532109816 |
NYLINER T (7283A) Price: $4.99 |
| 24 |
92-7536 |
HOSE-HYD Price: $196.76 |
| 25 |
3296-68 |
NUT-LOCK, NI Price: $14.67 |
| 25 |
531152201 |
SERVICE KIT BRACKET BRKT This part replaces 532124036. Price: $12.99 |
| 26 |
532126847 |
BUSHING.DRAGLINK (2 2) Price: $4.99 |
| 26 |
92-1765 |
WASHER-THRUST Price: $2.57 |
| 27 |
100-3774 |
GEAR-DRIVEN, 10 PITCH Price: $241.72 |
| 27 |
532136874 |
GEAR.SECTOR Price: $69.99 |
| 28 |
71-4590 |
WASHER-THRUST Price: $3.32 |
| 28 |
819131414 |
WASHER This part replaces 819131416. Price: $3.99 |
| 29 |
534200501 |
BOLT HEX PATCH 3/8-16X3/4 This part replaces 817490612. Price: $1.99 |
| 29 |
71-4580 |
BEARING Price: $80.51 |
| 30 |
100-3775 |
GEAR-DRIVER, 10 PITCH Price: $171.88 |
| 30 |
596029501 |
Pins This part replaces 876020412. Price: $2.99 |
| 31 |
340-9 |
FITTING-HYD, STRAIGHT Price: $67.47 |
| 32 |
237-166 |
O-RING Price: $10.46 |
| 32 |
532192757 |
ROD.TIE.WIRE.FORM This part replaces 532130465. Price: $29.99 |
| 33 |
92-7386 |
HYD MOTOR ASM Price: $2,754.42 |
| 34 |
340-142 |
FITTING-ELBOW-90 Price: $65.90 |
| 35 |
325-4 |
SCREW-HH Price: $0.95 |
| 36 |
32151-96 |
RING-RETAINING Price: $0.54 |
| 36 |
532155107 |
STEERING BUSHING KIT This part replaces 532102803. Price: $6.99 |
| 37 |
32120-15 |
RING-SNAP, EXT Price: $1.20 |
| 37 |
817211008 |
Screw Slftp #10-16 x 1/2 Ty-Ab This part replaces 817431008. Price: $3.99 |
| 38 |
532150546 |
KIT.WHEEL.STEERING This part replaces 532126805. Price: $64.99 |
| 39 |
583789501 |
WASHER.13/32x2 3/8x12GA This part replaces 819133808. Price: $4.99 |
| 40 |
873610600 |
NUT This part replaces 532124701. Price: $2.99 |
| 41 |
532104820 |
ADAPTER-WHEEL LT Price: $13.99 |
| 41 |
86-2820 |
Assembly-Wheel (Incl. Ref. #29-31) Price: Call Us |
| 42 |
532140216 |
BOOT STEERING SHAFT Price: $2.38 |
| 42 |
92-7553 |
TUBE-REAR DRAIN Price: $174.40 |
| 43 |
532121749 |
WASHER Price: $2.99 |
| 43 |
92-5833 |
SPACER-JOINT, BALL Price: $20.71 |
| 44 |
532154307 |
KIT.EXTENSION.STEERING.PLM/LR This part replaces 532140171. Price: $34.99 |
| 44 |
74-5500 |
BOLT-WHEEL Price: $10.84 |
| 45 |
340-2 |
FITTING-STRAIGHT Price: $11.43 |
| 45 |
812000029 |
RING CLIP Price: $3.99 |
| 46 |
353-989 |
PLUG-HEX, HOLLOW Price: $21.59 |
| 46 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 47 |
100-3795 |
JOINT-BALL Price: $76.85 |
| 47 |
532183226 |
FITTING.GREASE.TAPERED This part replaces 532124836. Price: $4.99 |
| 48 |
100-3796 |
SPACER-JOINT, BALL Price: $13.33 |
| 49 |
340-97 |
FITTING-ELBOW, 90 DEG Price: $36.21 |
| 50 |
874760412 |
BOLT.HEX.1/4.X.3/4.DICHROMATE This part replaces 817490412. Price: $3.99 |
| 50 |
98-3806 |
HYD CYLINDER ASM Price: $818.91 |
| 51 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 54 |
100-3770 |
PIN-AXLE, PIVOT Price: $146.29 |
| 54 |
595305701 |
Screws This part replaces 874780520. Price: $3.99 |
| 55 |
302-33 |
FITTING-GREASE Price: $2.31 |
| 55 |
532140285 |
CLIP Price: $2.99 |
| 57 |
100-3771 |
PIN-STOP Price: $47.62 |
| 63 |
110-4750 |
DRIVE AXLE ASM This part replaces 100-3784. Price: $8,909.28 |
| 68 |
32136-14 |
NUT-HST Price: $3.38 |
| 69 |
3272-12 |
PIN-COTTER Price: $0.25 |
| 70 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 71 |
94-9973 |
RING-RETAINING Price: $1.02 |
| 72 |
92-7539 |
HOSE-HYD Price: $134.23 |
| 73 |
92-7646 |
ELBOW-BULKHEAD, 45 DEG Price: $105.61 |
| 75 |
69-8910 |
WASHER Price: $1.70 |
| 76 |
240-7 |
GROMMET-RUBBER Price: $16.51 |
| 77 |
69-8900 |
SPACER Price: $14.26 |
| 78 |
92-7552-03 |
DISCONTINUED Price: Call Us |
