| Ref | Part Number | Description |
|---|
| 1 |
82-4580-03 |
BRACKET-NEUTRAL This part replaces 82-4580. Price: $8.22 |
| 2 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 3 |
1-513051 |
SWITCH-OPEN, NORMALLY This part replaces 65-7410. Price: $17.99 |
| 4 |
82-4570 |
PLATE-SWITCH Price: $9.71 |
| 5 |
32144-1 |
SCREW-TAPTITE Price: $3.19 |
| 6 |
82-4130 |
SIDE FLANGE BEARING ASM Price: $6.78 |
| 7 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 8 |
82-4210-01 |
BRACKET-BUSHING This part replaces 82-4210. Price: $28.95 |
| 9 |
82-4290 |
RH LEVER WA Price: Call Us |
| 10 |
3296-13 |
NUT-LOCK, NI Price: $0.34 |
| 11 |
82-8220 |
HYDRAULIC PUMP Price: $1,639.52 |
| 12 |
32128-42 |
NUT-HF Price: $0.98 |
| 13 |
322-7 |
SCREW-HH Price: $0.89 |
| 14 |
82-3790 |
ARM-PUMP Price: Call Us |
| 15 |
3256-1 |
WASHER-FLAT Price: $0.39 |
| 16 |
82-4230 |
FOLLOWER ARM *B Price: Call Us |
| 17 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 18 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 19 |
2411-34 |
JOINT-BALL Price: $29.99 |
| 20 |
82-4270 |
LH LEVER WA Price: Call Us |
| 21 |
3296-47 |
NUT-LOCK, NI Price: $3.59 |
| 22 |
82-4330-01 |
ARM-DETENT, LH This part replaces 82-4330. Price: $41.41 |
| 23 |
82-4370 |
BUSHING-ARM, DETENT Price: $7.62 |
| 24 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 25 |
82-4240 |
SPACER-BEARING Price: $6.49 |
| 26 |
251-259 |
BEARING-BALL Price: $13.67 |
| 27 |
3274-32 |
SCREW-HSBH Price: $4.79 |
| 28 |
82-3920 |
STOP-REVERSE Price: $9.71 |
| 29 |
82-4090 |
LEFT BRACKET WA *R Price: $62.79 |
| 30 |
322-14 |
SCREW-HH Price: $1.01 |
| 31 |
321-3 |
SCREW-HH Price: $0.28 |
| 32 |
82-4600 |
DECAL-HYDRO Price: $17.60 |
| 33 |
323-6 |
SCREW-HH Price: $0.66 |
| 34 |
321-8 |
SCREW-HH Price: $0.34 |
| 35 |
32112-11 |
NUT-PUSH Price: $0.79 |
| 36 |
80-0650 |
SPACER-TUBULAR Price: $6.99 |
| 37 |
32128-10 |
NUT-LOCK, HHF Price: $0.27 |
| 38 |
105-1210 |
SPRING-EXTENSION This part replaces 82-4160. Price: $14.81 |
| 39 |
86-4760 |
SPRING-EXTENSION Price: $9.99 |
| 40 |
93-1371 |
LH PIVOT ARM WA *RO This part replaces 82-4030. Price: $77.01 |
| 41 |
257-5 |
WASHER-THRUST Price: $1.83 |
| 42 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 43 |
237-124 |
GROMMET Price: $2.30 |
| 44 |
324-5 |
SCREW-HH Price: $0.54 |
| 45 |
32144-10 |
SCREW-HWH This part replaces 32144-3. Price: $4.29 |
| 46 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 47 |
32121-4 |
PIN-ROLL, SLOTTED Price: $3.49 |
| 48 |
82-4120 |
BALL JOINT ROD Price: Call Us |
| 49 |
32144-4 |
SCREW-HWH Price: $1.29 |
| 50 |
2412-106 |
CLAMP-R Price: $2.04 |
| 51 |
3290-418 |
RING-RETAIN,PUSH,EXT,FLAT Price: $2.49 |
