| Ref | Part Number | Description |
|---|
| 1 |
47-3990 |
DECAL Price: $19.68 |
| 1 |
532401043 |
SEAT.XG150.BLK.KB/SLD.NO-LOGO This part replaces 532188715. Price: $219.99 |
| 2 |
47-3570-01 |
REAR CROSS CHANNEL ASM This part replaces 47-3570. Price: $1,179.36 |
| 2 |
531152401 |
SERVICE KIT BRACKET SEAT PIVOT This part replaces 532140551. Price: $8.99 |
| 3 |
32128-23 |
NUT-HF Price: $1.51 |
| 3 |
871110616 |
BOLT, HEX 3/8-16X1 Price: $3.99 |
| 4 |
3290-216 |
WASHER Price: $3.83 |
| 4 |
819131610 |
WASHER PM Price: $4.99 |
| 5 |
3-2196-01 |
SHEAVE This part replaces 3-2196. Price: $141.72 |
| 5 |
532145006 |
PUSH CLIP Price: $2.99 |
| 6 |
32153-5 |
NUT-HEX Price: $1.59 |
| 7 |
325-14 |
SCREW-HH Price: $2.64 |
| 7 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK This part replaces 532124181. Price: $5.99 |
| 8 |
47-3560-01 |
FRONT CROSS CHANNEL ASM This part replaces 47-3560. Price: $1,253.08 |
| 8 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 9 |
3290-274 |
RIVET-POP Price: $0.25 |
| 9 |
596140201 |
Washers This part replaces 819131614. Price: $2.99 |
| 10 |
47-3900 |
PLATE-INFORMATION Price: $68.97 |
| 10 |
532195530 |
PAN.ASM.SEAT.1SLOT Price: $17.99 |
| 11 |
322-3 |
SCREW-HH Price: $0.79 |
| 11 |
532166369 |
KNOB.SEAT.ADJ.WINGNUT Price: $6.99 |
| 12 |
3256-2 |
WASHER-FLAT Price: $0.39 |
| 12 |
532174648 |
BRKT.MNTNG.SWITCH.SEAT.BLACK Price: $8.99 |
| 13 |
532121248 |
BUSHING Price: $4.99 |
| 13 |
65-5890 |
CAP-END Price: $8.09 |
| 14 |
106-9665 |
TUBE & CAP ASM This part replaces 65-5871. Price: $17.71 |
| 14 |
872050412 |
BOLT.ROUND.HEAD.SQUARE.NECK Price: $4.99 |
| 15 |
2412-102 |
CLAMP-R Price: $6.85 |
| 15 |
532121249 |
SPACER SPLIT Price: $4.99 |
| 16 |
32153-3 |
NUT-HEX, SIDE DEFORM Price: $5.59 |
| 16 |
532123740 |
SPRING COMPRESSED Price: $3.99 |
| 17 |
47-3470-03 |
SUPPORT-VALVE This part replaces 47-3470. Price: $79.97 |
| 17 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 532123976. Price: $3.99 |
| 18 |
325-6 |
SCREW-HH Price: $1.42 |
| 21 |
587907801 |
BOLT.5/16-18X5/8.SHOULDER This part replaces 532171852. Price: $2.99 |
| 22 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 24 |
819171912 |
WASHER Price: $3.99 |
| 25 |
532127018 |
BOLT,SHOULD Price: $4.99 |
