| Ref | Part Number | Description |
|---|
| 1 |
596040501 |
Hardware This part replaces 873510500. Price: $2.99 |
| 2 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 3 |
873220600 |
NUT.HEX.3/8-16UNC Price: $4.99 |
| 4 |
874930576 |
Bolt, Hex 5/16-18 x 4-3/4 Price: $4.99 |
| 5 |
532001572 |
PIN.ROLL.3/16 X 1" This part replaces 532124963. Price: $3.99 |
| 6 |
532110111 |
LEVER ASM CRT Price: $11.99 |
| 7 |
872110404 |
BOLT Price: $7.99 |
| 8 |
532008700 |
PANEL.INDICATOR.SHIFT.BLACK Price: $3.99 |
| 10 |
817021008 |
SCREW This part replaces 532086777. Price: $3.99 |
| 11 |
532009484 |
CONDUIT.CLIP.PLATED Price: $4.99 |
| 12 |
596029801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040400. Price: $2.99 |
| 13 |
532050675 |
NUT.HEX..25-20.UNC This part replaces 873220400. Price: $2.99 |
| 14 |
823230506 |
SET SCREW Price: $2.99 |
| 15 |
532120938 |
SPACER Price: $2.70 |
| 16 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 819111116. Price: $2.99 |
| 17 |
532100473 |
SHEAVE 10" CRT Price: $30.75 |
| 18 |
596436301 |
Nuts This part replaces 873220500. Price: $2.99 |
| 19 |
532110651 |
SPACER CRT Price: $2.99 |
| 20 |
532002649 |
KEY T Price: $5.99 |
| 21 |
532110653 |
GUARD CRT Price: $3.57 |
| 22 |
532110652 |
SPACER CRT Price: $4.99 |
| 23 |
532104214 |
NUT TI Price: $3.99 |
| 25 |
532065139 |
VALVE STEM LT This part replaces 532124718. Price: $5.99 |
| 25 |
532102190 |
TIRE.13X5-6.CHEVRON.TILLER Price: $59.99 |
| 25 |
532124258 |
RIM ASM.6"WHITE.TILLER Price: $120.99 |
| 26 |
532126875 |
RIVET,DRILLED Price: $2.99 |
| 27 |
532004497 |
RETAINER M This part replaces 532124788. Price: $4.99 |
| 28 |
532125091 |
BELT GRD Price: $25.01 |
| 29 |
532132672 |
V-BELT This part replaces 532102143. Price: $32.99 |
| 30 |
532104679 |
PULLEY-IDLER TI Price: $14.99 |
| 31 |
812000032 |
KLIP RING Price: $3.99 |
| 32 |
532102384 |
BOLT.FIN.HEX.3/8-16UNC Price: $7.99 |
| 33 |
584289401 |
BRACKET.IDLER.ASM.SHORT This part replaces 532105611. Price: $12.99 |
| 34 |
532102141 |
SHIFT ARM CRT Price: $6.99 |
| 35 |
596564401 |
Bolts This part replaces 874760616. Price: $3.99 |
| 36 |
532102383 |
COUNTERWEIGHT.LH.CRT Price: $84.99 |
| 37 |
596582201 |
Bolts This part replaces 874760524. Price: $2.99 |
| 38 |
532102331 |
BRACKET LH CRT Price: $11.99 |
| 39 |
532130816 |
PULLEY.ENGINE.3".OD This part replaces 532102142. Price: $39.99 |
| 40 |
532102376 |
BRACKET ASSY CRT Price: $18.54 |
| 532104323 |
DECAL |
TI NLA Price: $6.00 532104323 |
