| Ref | Part Number | Description |
|---|
| 1 |
1-613098 |
PULLEY-IDLER Price: $33.36 |
| 2 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 3 |
98-5975 |
WASHER-BELLEVILLE Price: $3.09 |
| 4 |
323-6 |
SCREW-HH Price: $0.66 |
| 5 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 6 |
3217-7 |
NUT-HEX Price: $0.28 |
| 7 |
94-2547 |
BOLT-EYE Price: $15.17 |
| 8 |
105-6992 |
SPRING-EXTENSION Price: $21.88 |
| 9 |
1-809107 |
WASHER-HARDENED Price: $3.25 |
| 10 |
1-603384 |
BUSHING-PIVOT, IDLER Price: $8.74 |
| 11 |
105-7010 |
IDLER ARM ASM Price: $217.31 |
| 12 |
116-4669 |
IDLER-PULLEY, FLAT This part replaces 99-8912. Price: $54.77 |
| 13 |
1-806005 |
PIN-COTTER Price: $2.39 |
| 14 |
100-7338 |
CLEVIS Price: $57.99 |
| 15 |
104-3634 |
PIN-CLEVIS Price: $18.99 |
| 16 |
3220-5 |
NUT-JAM Price: $0.65 |
| 17 |
131-3945 |
ROD-MOUNT, DECK This part replaces 104-8047. Price: $28.01 |
| 18 |
1-800805 |
SCREW-HH Price: $2.42 |
| 19 |
104-8037-03 |
PLATE-BOLT, RETAINER Price: $3.42 |
| 20 |
104-3699-01 |
LINK-HOC, ADJUSTING Price: $41.22 |
| 21 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 22 |
3296-16 |
NUT-LOCK, NI Price: $1.39 |
| 23 |
46-6290 |
O-RING Price: $2.59 |
| 24 |
3256-1 |
WASHER-FLAT Price: $0.39 |
| 25 |
133-9289 |
FITTING-WASHOUT This part replaces 95-2747. Price: $3.86 |
| 26 |
3229-1 |
BOLT-CARR Price: $3.39 |
| 28 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 29 |
302-19 |
FITTING-GREASE Price: $0.61 |
| 30 |
67-2150-03 |
BAFFLE This part replaces 67-2150-01. Price: $356.99 |
| 31 |
3230-1 |
BOLT-CARR Price: $1.49 |
