| Ref | Part Number | Description |
|---|
| NS |
48527 |
WIRE HARNESS ADAPTER Price: Call Us |
| 1 |
46508 |
HANDLE ASSY W/GRIPS LARGE SWZ This part replaces 45280. Price: Call Us |
| 2 |
42675 |
QUADRANT, SPEED CONTROL Price: Call Us |
| 4 |
04062-02 |
HAIR PIN, SMALL Price: Call Us |
| 5 |
04014-01 |
CAPSCREW, 1/4-20 X .75 FLAT HD. HEX SOCKET Price: Call Us |
| 6 |
04040-09 |
FLAT WASHER, .656 ID X 1.312 OD X .095 Price: Call Us |
| 7 |
45282 |
SPEED ADJUSTMENT LEVER Price: Call Us |
| 8 |
43086 |
BUSHING, SPEED ADJUSTMENT LEVER Price: Call Us |
| 10 |
48493-01 |
BALL PLUNGER Price: Call Us |
| 11 |
48092 |
KNOB, SPEED ADJUSTMENT LEVER Price: Call Us |
| 13 |
45142 |
SAFETY INTERLOCK, HAND GRIP - LH Price: Call Us |
| 13A |
45572 |
Operator Presence Lever, RH This part replaces 45141. Price: Call Us |
| 14 |
48312 |
BUSHING, CONTROL ROD Price: Call Us |
| 15 |
45142 |
SAFETY INTERLOCK HAND GRIP LH This part replaces 44014. Price: Call Us |
| 16 |
48326 |
GRIP, CUTTER DECK ENGAGE Price: Call Us |
| 18 |
46090 |
BLADE CLUTCH LEVER ASSY.(INCLUDES GRIP) Price: Call Us |
| 19 |
04041-10 |
FLAT WASHER, 3/8 X 2 X 16 GA. Price: Call Us |
| 20 |
44002 |
BELT CLUTCH ROD, UPPER This part replaces 46076. Price: Call Us |
| 22 |
48159 |
GRIP, HANDLE Price: Call Us |
| 24 |
48324-01 |
GRIP, NEUTRAL LATCH - RH Price: Call Us |
| 24 |
48324-02 |
GRIP, NEUTRAL LATCH - LH Price: Call Us |
| 25 |
461242 |
Neutral Latch, RH This part replaces 46083-01. Price: Call Us |
| 25A |
461241 |
Neutral Latch, LH This part replaces 46083-02. Price: Call Us |
| 26 |
04032-01 |
CURVED SPRING WASHER Price: Call Us |
| 29 |
48492 |
GRIP, STEERING CONTROL Price: Call Us |
| 30 |
46333 |
STEERING CONTROL LEVER - RH(INCLUDES GRIP) Price: Call Us |
| 30A |
46334 |
STEERING CONTROL LEVER - LH(INCLUDES GRIP) Price: Call Us |
| 31 |
04026-01 |
HEX NUT, 9/16-18 SPRING STEEL Price: Call Us |
| 32 |
48313 |
SPRING, GRIP RETURN Price: Call Us |
| 33 |
48021 |
SWITCH, INTERLOCK(GOLD COLORED) Price: Call Us |
| 38 |
48050 |
SPRING, COMPRESSION Price: Call Us |
| 42 |
48017-02 |
KEY, IGNITION Price: Call Us |
| 43 |
48017-04 |
HEX NUT, 5/8-32 Price: Call Us |
| 44 |
48017-03 |
LOCKWASHER, 5/8 INTERNAL TOOTH Price: Call Us |
| 45 |
48612 |
WIRE HARNESS ADAPTER This part replaces 48171. Price: Call Us |
| 49 |
48610 |
WIRE HARNESS This part replaces 48495. Price: Call Us |
| 51 |
44050 |
Rod, Steering Control This part replaces 46294. Price: Call Us |
| 52 |
04050-01 |
RETAINING RING, 5/8 EXT. - "E" Price: Call Us |
| 53 |
43155 |
JACKSHAFT, SPEED CONTROL Price: Call Us |
| 54 |
04063-13 |
KEY, 1/8 X 1/2 WOODRUFF #3 Price: Call Us |
| 56 |
46335 |
CAM, SPEED CONTROL(INCLUDES SETSCREW) Price: Call Us |
| 57 |
43157 |
SWIVEL JOINT, STEERING ROD Price: Call Us |
| 58 |
48100-04 |
BUSHING Price: Call Us |
| 59 |
46336 |
PIVOT, PUMP CONTROL SHAFT(INCLUDES BUSHINGS Price: Call Us |
| 61 |
04001-69 |
BOLT, HEX HD., 5/16-18 X 1-3/4 FULL THREAD Price: Call Us |
| 62 |
48409 |
BEARING, SPEED CONTROL Price: Call Us |
| 63 |
43161 |
SPACER, SPEED CONTROL BEARING Price: Call Us |
| 64 |
42730 |
BAR, SPEED CONTROL ADJUSTMENT Price: Call Us |
| 68 |
04065-05 |
DRIVE PIN, 5/32 X 7/8 TYPE U Price: Call Us |
| 69 |
48051 |
SPRING, NEUTRAL RETURN Price: Call Us |
| 70 |
45292 |
HANDLE, NEUTRAL ADJUSTMENT Price: Call Us |
| 71 |
45271 |
BELLCRANK, LH CONTROL Price: Call Us |
| 71A |
45272 |
BELLCRANK, RH CONTROL Price: Call Us |
| 72 |
48494-02 |
Spring, Return This part replaces 48494. Price: Call Us |
| 73 |
48224 |
BEARING, NEUTRAL RETURN Price: Call Us |
| 75 |
48114-04 |
Fitting, Grease This part replaces 48114-01. Price: Call Us |
| 76 |
46337 |
NEUTRAL CAM, RH(INCLUDES GREASE FITTING) Price: Call Us |
| 76A |
46338 |
NEUTRAL CAM, LH(INCLUDES GREASE FITTING) Price: Call Us |
| 79 |
45094 |
BELLCRANK PIVOT WELDMENT Price: Call Us |
| 81 |
44064 |
BLADE CLUTCH ROD, LOWER This part replaces 44003. Price: Call Us |
| 82 |
46339 |
BELLCRANK, CUTTER ENGAGE(INCLUDES GREASE Price: Call Us |
| 83 |
45295 |
SHAFT, LH PUMP CONTROL Price: Call Us |
| 86 |
481476 |
Switch, Foot Safety This part replaces 48026. Price: Call Us |
| 87 |
48028-01 |
CABLE TIE Price: Call Us |
| 88 |
48059-01 |
CLAMP, FUEL HOSE Price: Call Us |
| 89 |
48179-01 |
FUEL HOSE, SHORT 7/32 ID X 3-1/2(KA ONLY) Price: Call Us |
| 90 |
48057-02 |
FUEL FILTER Price: Call Us |
| 91 |
483617 |
Fuel Hose, 1/4" I.D. Non-Perm (791DFI Fuel Return) This part replaces 48058-05. Price: Call Us |
| 92 |
483747 |
Ball Valve w/Screen This part replaces 48308. Price: Call Us |
| 93 |
482571 |
Bushing This part replaces 48309. Price: Call Us |
| 94 |
48205 |
PAD, RUBBER - FUEL TANK - LOWER Price: Call Us |
| 96 |
421239 |
Strap, Fuel Tank This part replaces 42369. Price: Call Us |
| 97 |
48292 |
PAD, RUBBER - FUEL TANK - UPPER Price: Call Us |
| 98 |
481603 |
Fuel Tank Cap This part replaces 48311. Price: Call Us |
| 99 |
46846 |
Fuel Tank Assy. This part replaces 46174. Price: Call Us |
| 100 |
44051 |
Rod Speed Control This part replaces 46295. Price: Call Us |
| 101 |
45279 |
BELLCRANK, SPEED CONTROL Price: Call Us |
| 103 |
46619 |
Oil Reservoir This part replaces 45276. Price: Call Us |
| 104 |
48535 |
CAP, OIL RESERVOIR Price: Call Us |
| 105 |
48394 |
THROTTLE CONTROL Price: Call Us |
