| Ref | Part Number | Description |
|---|
| 1 |
32121-6 |
PIN-ROLL, SLOTTED Price: $0.28 |
| 2 |
32121-45 |
PIN-SPRING Price: $0.27 |
| 3 |
49-6440-03 |
PEDAL-FORWARD Price: $84.90 |
| 4 |
74-9100 |
PAD-PEDAL, FORWARD Price: $27.08 |
| 5 |
75-2970 |
PEDAL-TRACTION Price: $135.64 |
| 6 |
74-9110 |
PAD-PEDAL, REVERSE Price: $13.49 |
| 7 |
75-6550 |
DISC-FRICTION Price: $7.96 |
| 8 |
75-6490 |
LEVER ASM Price: $78.45 |
| 9 |
233-42 |
KNOB Price: $12.88 |
| 10 |
93-6699 |
DECAL-FAST / SLOW Price: $18.07 |
| 11 |
112-5084 |
BRACKET-LEVER This part replaces 75-6510. Price: $61.39 |
| 12 |
75-6580 |
CABLE-PEDAL Price: $34.72 |
| 13 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 14 |
3272-2 |
PIN-COTTER Price: $2.29 |
| 15 |
3290-461 |
WASHER-SPRING Price: $3.89 |
| 16 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 17 |
32128-20 |
NUT-HF Price: $0.99 |
| 18 |
256-236 |
BEARING-MOUNT, FLANGE Price: $27.99 |
| 19 |
322-3 |
SCREW-HH Price: $0.79 |
| 20 |
93-8742 |
FOOTPAD-BRAKE Price: $27.95 |
| 23 |
63-7880 |
PIN-LATCH, BRAKE Price: $6.04 |
| 24 |
92-7530 |
CABLE-BRAKE, LH Price: $132.98 |
| 25 |
92-7529 |
CABLE-BRAKE, RH Price: $132.98 |
| 26 |
3256-69 |
WASHER-FLAT Price: $0.62 |
| 27 |
32121-16 |
PIN-SPRING Price: $0.41 |
| 28 |
283-58 |
PIN-CLEVIS Price: $3.87 |
| 29 |
75-1440-03 |
PEDAL-BRAKE, LH Price: $207.74 |
| 30 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 31 |
32121-50 |
PIN-SPRING Price: $1.21 |
| 32 |
75-1430 |
RH BRAKE PEDAL ASM Price: $255.51 |
| 34 |
75-3270-03 |
HUB-PIVOT, TRACTION Price: $144.73 |
| 35 |
75-1470 |
PIN-PIVOT, BRAKE Price: $45.68 |
| 36 |
92-7531-03 |
TUBE-PUMP CONTROL Price: $139.90 |
| 37 |
3220-3 |
NUT-HJ Price: $0.28 |
| 38 |
2411-36 |
BEARING-END, ROD Price: $32.13 |
| 39 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 40 |
323-9 |
SCREW-HH Price: $1.29 |
| 41 |
5-0652 |
SPACER Price: $5.35 |
| 42 |
323-29 |
SCREW-HH Price: $0.42 |
| 43 |
60-5700 |
SPRING Price: $27.02 |
| 44 |
92-7608-03 |
BRACKET-SPRING Price: $16.86 |
| 45 |
92-7609 |
SHAFT-SPRING Price: $62.79 |
| 46 |
92-7610 |
RETAINER-SPRING Price: $26.52 |
| 47 |
32121-11 |
PIN-ROLL Price: $0.47 |
| 48 |
32144-14 |
SCREW-HWHTF Price: $4.29 |
| 49 |
3256-5 |
WASHER-FLAT Price: $0.27 |
| 51 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 539102502 |
539102502 |
STUD, 5/16C Price: $8.99 |
| 539102519 |
539102519 |
BUSHING Price: $2.99 |
| 539102587 |
539102587 |
GROMMET, BUMPER Price: $4.99 |
| 539102619 |
539102619 |
PIVOT PIN Price: $32.99 |
| 539102845 |
539102845 |
SPRING Price: $2.99 |
| 539104197 |
539104197 |
STRUT MOUNT WELDMENT Price: $51.99 |
| 539104199 |
539104199 |
HCS 5/8C X 2 GR.5 Price: $2.99 |
| 539104411 |
597783101 |
GSPW Knobs This part replaces 539104411. Price: $3.99 |
| 539104763 |
539104763 |
U-CLIP 5/16-18 NUT RETAINER Price: $4.99 |
| 539105039 |
539105039 |
STUD/PLATE MOUNT Price: $4.99 |
| 539105169 |
539105169 |
KNOB Price: $7.99 |
| 539105224 |
539105224 |
SEAT BRKT W/DECAL Price: $24.99 |
| 539106899 |
539106899 |
BATTERY HOLD DOWN Price: $59.99 |
| 539106941 |
539106941 |
FOOTREST ORANGE Price: $66.99 |
| 539110806 |
539110806 |
STRUT, RT Price: $424.99 |
| 539110807 |
539110807 |
STRUT, LT Price: $417.99 |
| 539110819 |
539110819 |
CLEVIS PIN 3/8 Price: $2.99 |
| 539111098 |
539111098 |
IZ FRAME W/DECALS Price: $949.99 |
| 539111573 |
539111573 |
IZ FOOTPLATE W/DECAL Price: $159.99 |
| 539976934 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 539976934. Price: $3.99 |
| 539976978 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 539976978. Price: $1.99 |
| 539976998 |
596899901 |
GSPW Zerks This part replaces 539976998. Price: $2.99 |
| 539977778 |
539977778 |
ANTI-SKID PAD Price: $3.99 |
| 539990184 |
596580701 |
Nuts This part replaces 539990184. Price: $2.99 |
| 539990209 |
596580801 |
Bolts This part replaces 539990209. Price: $2.99 |
| 539990333 |
539990333 |
LOCKWASHER 5/8 Price: $2.99 |
| 539990365 |
596029501 |
Pins This part replaces 539990365. Price: $2.99 |
| 539990580 |
596230901 |
Screws This part replaces 539990580. Price: $2.99 |
| 539990692 |
596134901 |
GSPH This part replaces 539990692. Price: $2.99 |
