| Ref | Part Number | Description |
|---|
| 1 |
340-98 |
FITTING-ELBOW, 90 DEG Price: $31.91 |
| 2 |
100-3879 |
HYD HOSE ASM Price: $167.28 |
| 2 |
146682 |
Spring Return Brake Price: Call Us |
| 3 |
123666X |
Pulley Transaxle 18" tires Price: Call Us |
| 3 |
340-4 |
FITTING-STRAIGHT Price: $11.58 |
| 4 |
110-0004 |
HYD MANIFOLD ASM This part replaces 98-4579. Price: $4,068.40 |
| 4 |
12000028 |
Ring Retainer # 5100-62 Price: Call Us |
| 5 |
121520X |
Strap Torque 30 Degrees RH Price: Call Us |
| 6 |
17060512 |
Screw 5/16-18 x 3/4 Price: Call Us |
| 6 |
340-101 |
FITTING-HYD, 45 DEG Price: $31.00 |
| 7 |
162240 |
Plate Rod Shift T/a Price: Call Us |
| 7 |
354-77 |
FITTING-QUICK Price: $55.94 |
| 8 |
131679 |
Rod Shifter Blk Price: Call Us |
| 8 |
354-79 |
CAP-DUST Price: $7.81 |
| 9 |
86-9190 |
HOSE Price: $84.09 |
| 10 |
76020416 |
Pin Cotter 1/8 x 1 Cad Price: Call Us |
| 11 |
105701X |
Washer Plate Shf 388 Sq Hole Price: Call Us |
| 11 |
340-92 |
FITTING-STRAIGHT Price: $12.29 |
| 12 |
19151216 |
Washer 15/32 x 3/4 x 16 Ga Price: Call Us |
| 12 |
75-6640 |
FITTING-HYD, SPECIAL Price: $80.34 |
| 13 |
74550412 |
Bolt 1/4-28 unf Gr. 8 w/Patch Price: Call Us |
| 13 |
98-9348 |
HYD HOSE ASM Price: $140.31 |
| 14 |
10040400 |
Washer Lock Hvy Helical 1/4 Price: Call Us |
| 14 |
99-6160 |
FITTING-ELBOW 90 LONG This part replaces 98-9781. Price: $92.35 |
| 15 |
340-139 |
FITTING-ELBOW 90 Price: $117.76 |
| 16 |
73800500 |
Nut Lock Hex w/Ins 5/16-18 Unc Price: Call Us |
| 16 |
98-9347 |
HYD HOSE ASM Price: $212.81 |
| 17 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 18 |
322-3 |
SCREW-HH Price: $0.79 |
| 18 |
74780616 |
Bolt Fin Hex 3/8-16 Unc x 1 Gr. 5 Price: Call Us |
| 19 |
73800600 |
Nut lock Hex w/Ins 3/8-16 Unc Price: Call Us |
| 20 |
98-9742 |
VALVE-CONTROL, FLOW Price: $158.79 |
| 21 |
106933X |
Knob Rd 1/2-13 Plstc Thds Blk Price: Call Us |
| 22 |
100-3878 |
HYD HOSE ASM Price: $187.15 |
| 22 |
130804 |
Rod Brake LT Price: Call Us |
| 23 |
340-1 |
FITTING-STRAIGHT Price: $10.19 |
| 24 |
73350600 |
Nut Hex Jam 3/8-16 Unc Price: Call Us |
| 25 |
106888X |
Spring Rod Brake 2 00 Zinc Price: Call Us |
| 25 |
340-143 |
ELBOW-SWIVEL, 90 DEG Price: $58.91 |
| 26 |
19131316 |
Washer 13/32 x 13/16 x 16 Ga Price: Call Us |
| 27 |
76020412 |
Pin Cotter 1/8 x 3/4 Cad Price: Call Us |
| 28 |
175765 |
Rod Brake Parking LT/YT Price: Call Us |
| 29 |
71673 |
Cap Brake Parking Black Price: Call Us |
| 30 |
174973 |
Bracket Transmission Price: Call Us |
| 32 |
74760512 |
Bolt Fin Hex 5/16-18 x 3/4 Price: Call Us |
| 34 |
175578 |
Shaft Asm Pedal Foot Nibbed Price: Call Us |
| 35 |
120183X |
Bearing Nylon Blk 629 Id Price: Call Us |
| 36 |
19211616 |
Washer 21/32 x 1 x 16 Ga Price: Call Us |
| 37 |
1572H |
Pin Roll 3/16 x 1" Price: Call Us |
| 38 |
179114 |
Pulley Composite Flat Price: Call Us |
| 39 |
74760648 |
Bolt Fin Hex 3/8-16 x 3 Price: Call Us |
| 41 |
175556 |
Keeper Belt Idler Price: Call Us |
| 47 |
127783 |
Pulley Idler V Groove Plastic Price: Call Us |
| 48 |
154407 |
Bellcrank Clutch Grnd Drv STL Price: Call Us |
| 49 |
123205X |
Retainer Belt Style Spring Price: Call Us |
| 50 |
72110612 |
Bolt Carr Sh 3/8-16 x 1-1/2 Gr. 5 Price: Call Us |
| 51 |
73680600 |
Nut Crownlock 3/8-16 Unc Price: Call Us |
| 52 |
73680500 |
Nut Crownlock 5/16-18 Unc Price: Call Us |
| 53 |
105710X |
Link Clutch 7 66 Price: Call Us |
| 55 |
105709X |
Spring Return Clutch 6 75 Price: Call Us |
| 56 |
17060620 |
Screw 3/8-16 x 1-1/4 Price: Call Us |
| 57 |
130801 |
V-Belt Ground Drive 95 Price: Call Us |
| 59 |
169691 |
Keeper Belt Chassis Span Ctr Price: Call Us |
| 61 |
17120614 |
Screw 3/8-16 x .875 Price: Call Us |
| 62 |
8883R |
Cover Pedal Blk Round Price: Call Us |
| 63 |
175410 |
Engine Pulley LT/YT Price: Call Us |
| 64 |
71170764 |
Bolt Hex 7/16-20x4 Gr 5 Price: Call Us |
| 65 |
10040700 |
Washer Lock Hvy Hlcl Spr 7/16 Price: Call Us |
| 66 |
154778 |
Keeper Belt Engine Price: Call Us |
| 70 |
134683 |
Guide Belt Mower Drive RH Price: Call Us |
| 74 |
137057 |
Spacer Axle Price: Call Us |
| 75 |
121749X |
Washer 25/32 x 1 1/4 x 16 Ga Price: Call Us |
| 76 |
12000001 |
E-ring #5133-75 Price: Call Us |
| 77 |
123583X |
Key Square 2 0 x 1845/ 1865 Price: Call Us |
| 78 |
121748X |
Washer 25/32 x 1-5/8 x 16 Ga Price: Call Us |
| 79 |
2228M |
Key Woodruff Price: Call Us |
| 96 |
4497H |
Retainer Spring 1" Price: Call Us |
| 112 |
19091210 |
Washer 9/32 x 3/4 x 10 Ga Price: Call Us |
| 113 |
127285X |
Strap Torque 90 Degrees LH Price: Call Us |
| 116 |
72140608 |
Bolt Rdhd Sq Neck 3/8-16 x 1 Price: Call Us |
| 120 |
73900600 |
Nut Lock Flg 3/8-16 Price: Call Us |
| 145 |
74490540 |
Bolt Hex Flg.Hd. 5/16-18 x Gr.5 Price: Call Us |
| 150 |
175456 |
Spacer Retainer Lt Price: Call Us |
| 151 |
19133210 |
Washer 13/32 x 2 x 10 Ga. Price: Call Us |
| 170 |
178394 |
Keeper, Belt Transaxle Price: Call Us |
| 202 |
72110614 |
Bolt Carr Sh 3/8-16 x 1-3/4 Gr.5 Price: Call Us |
| 212 |
145212 |
Nut Hex Flg Lock Price: Call Us |
