| Ref | Part Number | Description |
|---|
| 1 |
105-8250 |
CONSOLE Price: $213.37 |
| 1 |
198417 |
Wire Asm Inner/Sprg W/plunger Price: Call Us |
| 2 |
105-8254-03 |
LID-CONSOLE Price: $63.57 |
| 2 |
198070 |
Shaft Asm Lift RH w/Inf Price: Call Us |
| 3 |
105-8255-03 |
BAFFLE-CONSOLE Price: $33.59 |
| 3 |
188822 |
Pin Groove 5/16 Dia x 1.875 Price: Call Us |
| 4 |
105-8256 |
ROD-HINGE Price: $17.77 |
| 4 |
12000002 |
E Ring #5133-62 Price: Call Us |
| 5 |
105-8283 |
BUSHING Price: $1.70 |
| 5 |
19211621 |
Washer 21/32 x 1 x 21 Ga. Price: Call Us |
| 6 |
105-8251 |
POD Price: $67.39 |
| 6 |
120183X |
Bearing Nylon Blk 629 Id Price: Call Us |
| 7 |
105-8252-03 |
BRACKET-POD Price: $113.31 |
| 7 |
125631X |
Grip Handle Price: Call Us |
| 8 |
105-8284-03 |
SHIELD-VALVE Price: $21.17 |
| 8 |
124526X |
Button Plunger Price: Call Us |
| 11 |
139865 |
Link Lift LH Fixed Length Price: Call Us |
| 12 |
139866 |
Link Lift RH Fixed Length Price: Call Us |
| 12 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 13 |
4939M |
Retainer Spring Price: Call Us |
| 15 |
173288 |
Link Front Price: Call Us |
| 16 |
73350800 |
Nut Jam Hex 1/2-13 unc Price: Call Us |
| 17 |
175689 |
Trunnion Price: Call Us |
| 17 |
233-42 |
KNOB Price: $12.88 |
| 18 |
73800800 |
Nut Lock W/Wsh 1/2-13 unc Price: Call Us |
| 18 |
93-5961 |
BOOT-LEVER Price: $56.35 |
| 19 |
139868 |
Arm Suspension Rear Price: Call Us |
| 20 |
105-8288 |
ROD-JOYSTICK Price: $26.49 |
| 20 |
194209 |
Pin Cotter 7/16 Bow Tie Lock Price: Call Us |
| 22 |
105-8280-03 |
PLATE-CONSOLE Price: $9.63 |
| 23 |
105-8305 |
DECAL-PANEL, CONTROL Price: $23.63 |
| 24 |
105-8306 |
DECAL-SELECTOR, SPEED Price: $20.42 |
| 25 |
104-2541 |
SWITCH ASM This part replaces 88-9830. Price: $36.70 |
| 27 |
63-8360 |
KEY-IGNITION Price: $5.29 |
| 28 |
3218-3 |
NUT-JAM Price: $0.25 |
| 29 |
3230-1 |
BOLT-CARR Price: $1.49 |
| 30 |
32144-19 |
SCREW-SHWH Price: $0.89 |
| 31 |
169865 |
Bearing Pvt Lift Price: Call Us |
| 31 |
32144-10 |
SCREW-HWH Price: $4.29 |
| 32 |
3290-134 |
SCREW Price: $0.27 |
| 34 |
3290-148 |
NUT-HF Price: $0.25 |
| 35 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 36 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 37 |
3256-77 |
WASHER-FLAT Price: $1.60 |
