| Ref | Part Number | Description |
|---|
| 1 |
321-4 |
SCREW-HH Price: $0.99 |
| 1 |
532186093 |
WHEEL.STEERING.LEGND2.GRY This part replaces 532193943. Price: $89.99 |
| 2 |
27-4910-01 |
PTO LEVER WA This part replaces 27-4910. Price: $214.21 |
| 2 |
532413591 |
AXLE.SVC.ASM CAST IRON.TEX This part replaces 532195968. Price: $119.99 |
| 3 |
21-1880 |
GRIP-HANDLE Price: $11.67 |
| 4 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 4 |
596873601 |
SPINDLE.WELDED.LH.15"TEX.X431 This part replaces 532403087. Price: $14.99 |
| 5 |
251-269 |
BEARING Price: $19.20 |
| 5 |
538691201 |
SPINDLE.WLDMT.RH.15INTIRE.X431 This part replaces 532403088. Price: $19.99 |
| 6 |
32121-31 |
PIN-SPRING Price: $0.26 |
| 6 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 7 |
3-6514 |
THRUST WASHER Price: $1.74 |
| 7 |
532121748 |
WASHER Price: $3.99 |
| 8 |
32104-116 |
SCREW-HWHTF Price: $0.55 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
29-6930 |
DISCONTINUED-SEE PB#936 Price: Call Us |
| 9 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 10 |
47-4780-03 |
ENGAGEMT ARM ASM This part replaces 47-4780. Price: $69.64 |
| 11 |
44-8680-03 |
DISCONTINUED This part replaces 44-8680. Price: Call Us |
| 12 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 13 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 13 |
532121749 |
WASHER Price: $2.99 |
| 14 |
32144-11 |
SCREW-THD ROLL, HWH Price: $6.99 |
| 14 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 15 |
3272-5 |
PIN-COTTER Price: $1.39 |
| 15 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 16 |
3296-5 |
NUT-HEX Price: $3.09 |
| 16 |
587738904 |
KIT.SRVC.STEERINGSHAFT.2HISHFT This part replaces 532408219. Price: $34.99 |
| 17 |
44-8890 |
SPRING RET TOP Price: $30.36 |
| 18 |
44-8820 |
DISCONTINUED Price: Call Us |
| 19 |
3256-41 |
WASHER Price: $1.18 |
| 19 |
531169101 |
SERVICE KIT PLATE PLATE.STEER. This part replaces 532194729. Price: $19.99 |
| 20 |
27-7900 |
SCREW-ADJUSTING Price: $21.70 |
| 21 |
3220-3 |
NUT-HJ Price: $0.28 |
| 21 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 532186737. Price: $7.99 |
| 22 |
281-1 |
PLUG-PIPE, SQH Price: $4.56 |
| 22 |
587738901 |
KIT.SRVC.STEERINGSHAFT.LWRBSHG This part replaces 532194845. Price: $14.99 |
| 23 |
283-42 |
PIN-CLEVIS Price: $40.05 |
| 24 |
37-7060-01 |
DISCONTINUED This part replaces 37-7060. Price: Call Us |
| 25 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 26 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 26 |
532193652 |
INSERT.CAP.STRG.WH.GRAY Price: $11.99 |
| 27 |
63-7590 |
RELAY Price: $78.15 |
| 28 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 35 |
532194732 |
GEAR.SECTOR.PLATE.DDL. Price: $27.99 |
| 45 |
819183812 |
WASHER 9/16"ID, 2 3/8"OD Price: $7.99 |
| 51 |
873940800 |
NUT.HEX.1/2-20 Price: $3.99 |
| 53 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 57 |
532407465 |
BRACKET.UPSTOP.TEX Price: $5.99 |
| 58 |
532194747 |
BOLT.SHOULDER.SECTOR.P Price: $7.99 |
| 59 |
532194748 |
WASHER.THURST.SECTOR.S Price: $4.99 |
| 60 |
583612801 |
NUT.FLANGE.LOCK.5/8-11 This part replaces 873971000. Price: $3.99 |
| 61 |
597047802 |
Links This part replaces 532194740. Price: $11.99 |
| 62 |
597047902 |
Links This part replaces 532194741. Price: $11.99 |
| 63 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 64 |
532199849 |
RETAINER.CLIP.SPRING.S Price: $4.99 |
| 66 |
871020748 |
BOLT HEX FGHD 7/16-14 X 3 SERR Price: $4.99 |
| 67 |
529496302 |
BUSHING, AXLE This part replaces 532194737. Price: $2.99 |
| 68 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 69 |
532199162 |
WASHER.1.5X.505X.118 Price: $4.99 |
