| Ref | Part Number | Description |
|---|
| 1 |
2411-38 |
JOINT-BALL Price: $21.96 |
| 1 |
408007 |
IMPELLER BELT Price: Call Us |
| 2 |
419744 |
TRACTION BELT Price: Call Us |
| 2 |
93-2279 |
CLAMP-CABLE Price: $7.12 |
| 3 |
419925X479 |
IDLER ARM Price: Call Us |
| 4 |
193397X479 |
IDLER BRACKET Price: Call Us |
| 4 |
3296-27 |
NUT-LOCK, NI Price: $0.27 |
| 5 |
180523 |
IDLER PULLEY Price: Call Us |
| 5 |
33024-00 |
NUT-LOCK, NI Price: $0.75 |
| 6 |
74780524 |
SCREW 5/16-18 X 1.50 Price: Call Us |
| 7 |
426589 |
NUT 5/16-18 Price: Call Us |
| 7 |
94-9611 |
HANDLE Price: $151.08 |
| 8 |
175330 |
IDLER ARM PIN Price: Call Us |
| 8 |
256-311 |
BUSHING-SPLIT Price: $13.37 |
| 9 |
112-0278 |
SWITCH-REED This part replaces 93-2055. Price: $55.79 |
| 9 |
85179 |
RETAINER CLIP Price: Call Us |
| 10 |
120-5341 |
KIT-SERVICE, ACTUATOR This part replaces 93-2056. Price: $43.38 |
| 10 |
428867 |
SCREW 5/16-18 X .625 Price: Call Us |
| 11 |
187786 |
TRACTION IDLER ARM Price: Call Us |
| 11 |
94-1378 |
TUBE-PIVOT, HANDLE Price: $9.66 |
| 12 |
180522 |
TRACTION PULLEY Price: Call Us |
| 12 |
33115-040 |
SCREW-HH Price: $1.22 |
| 13 |
33025-00 |
NUT-LOCK, NI Price: $0.54 |
| 13 |
74780520 |
SCREW 5/16-18 X 1.00 Price: Call Us |
| 14 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 14 |
59289 |
WASHER Price: Call Us |
| 15 |
73930500 |
NUT 5/16-18 Price: Call Us |
| 15 |
94-6398 |
BRACKET-TRACTION Price: $31.52 |
| 16 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 16 |
851084 |
IDLER BUSHING Price: Call Us |
| 17 |
400026 |
WASHER Price: Call Us |
| 17 |
75-5470 |
SPACER-BEARING Price: $3.06 |
| 18 |
179157 |
ENGINE PULLEY Price: Call Us |
| 18 |
251-259 |
BEARING-BALL Price: $13.67 |
| 19 |
180478 |
ENGINE TRACTION PULLEY Price: Call Us |
| 19 |
94-9617 |
PIN-SPRING Price: $9.91 |
| 20 |
233-42 |
KNOB Price: $12.88 |
| 20 |
409475 |
SPACER Price: Call Us |
| 21 |
120-3198 |
ROLLER-PIVOT This part replaces 94-9614. Price: $9.78 |
| 21 |
74610516 |
SCREW 5/16-18 X 1.00 Price: Call Us |
| 22 |
10040500 |
LOCKWASHER 5/16 Price: Call Us |
| 22 |
94-9619 |
BUSHING Price: $17.13 |
| 23 |
155452 |
BELT GUIDE Price: Call Us |
| 23 |
3256-1 |
WASHER-FLAT Price: $0.39 |
| 24 |
11050500 |
LOCKWASHER 5/16 Price: Call Us |
| 24 |
94-9618 |
SPACER-SPRING Price: $9.85 |
| 25 |
94-9620 |
SPRING-TORSION Price: $20.28 |
| 26 |
33023-00 |
NUT-LOCK Price: $0.25 |
| 27 |
105-5417-03 |
BRACKET-CABLE, SHIFTER Price: $21.91 |
| 29 |
322-2 |
SCREW-HH Price: $0.69 |
| 30 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 31 |
3290-321 |
SCREW-HWH Price: $3.99 |
