| Ref | Part Number | Description |
|---|
| 1 |
100-9943-0P |
TUBE ASM-ROLLER 3" DIA This part replaces 100-9943-03. Price: $176.36 |
| 1 |
532136973 |
Wire Asm Inner W/plunger 17 32 (AYP part number) Price: $11.99 |
| 2 |
107-3296 |
SHAFT-ROLLER, REAR Price: $78.91 |
| 2 |
532140278 |
Shaft Asm Lift (AYP part number) Price: $34.17 |
| 3 |
532138284 |
Pin Groove (AYP part number) Price: $3.99 |
| 3 |
93-3007 |
SEAL-OIL Price: $4.46 |
| 4 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 4 |
812000002 |
E Ring #5133-62 (AYP part number) Price: $3.99 |
| 5 |
109966 |
BEARING-BALL Price: $14.99 |
| 5 |
819211621 |
Washer PLTD 21/32 X 1 X 21ga (AYP part number) Price: $3.99 |
| 6 |
532120183 |
Bearing Nylon Blk 629 ld (AYP part number) Price: $2.99 |
| 6 |
93-1251 |
SEAL-INNER Price: $9.50 |
| 7 |
532109413 |
Grip Handle Bicycle Matte Blk (AYP part number) Price: $2.99 |
| 7 |
93-1252 |
SEAL-OUTER Price: $18.76 |
| 8 |
32120-62 |
RING-RETAINING Price: $4.29 |
| 8 |
532125925 |
PLUNGER BUTTON KIT This part replaces 532124526. Price: $5.99 |
| 9 |
253-70 |
SEAL-OIL Price: $6.52 |
| 10 |
532122512 |
Spring Cprsn 3 750 Oiled Price: $4.99 |
| 11 |
532145537 |
LIFT LINK LH This part replaces 532139865. Price: $14.99 |
| 12 |
532145536 |
LIFT LINK RH This part replaces 532139866. Price: $7.99 |
| 13 |
532124670 |
Retainer Spring (AYP part number) Price: $5.99 |
| 15 |
532127218 |
Link Front (AYP part number) Price: $9.99 |
| 16 |
873350800 |
Nut Jam Hex 1/2-13 Unc (AYP part number) Price: $1.99 |
| 17 |
532175689 |
TRUNNION This part replaces 532130171. Price: $2.99 |
| 18 |
539101331 |
NUT 1/2-13 HEX NYLOC ZD This part replaces 873800800. Price: $1.99 |
| 19 |
532139868 |
Arm Suspension Rear (AYP part number) Price: $11.99 |
| 20 |
532003146 |
SPRING RETAINER This part replaces 532124660. Price: $1.99 |
| 21 |
819151216 |
Washer 15/32 x 3/4 x 16 Ga. (AYP part number) Price: Call Us |
| 22 |
812000037 |
Ring Klip #T534037 (AYP part number) Price: $3.99 |
| 23 |
532110807 |
Nut Special (AYP part number) Price: $3.99 |
| 24 |
819131016 |
Washer 13/32 x 5/8 x 16 Ga. (AYP part number) Price: $3.99 |
| 25 |
532002876 |
SPRING This part replaces 532124874. Price: $3.99 |
| 26 |
876020308 |
Pin cotter 3/32 x 1/2 (AYP part number) Price: $1.99 |
| 27 |
532126971 |
Rod adj Lifte zino 7.49 work lg. Price: $4.99 |
| 28 |
873220600 |
NUT.HEX.3/8-16UNC This part replaces 873350600. Price: $3.99 |
| 29 |
532138057 |
Knob info 3/8 - 16 Unc. Blk w/sym (AYP part number) Price: $5.99 |
| 30 |
532110810 |
Turnnion dp. stop dbl thds plt. Price: $14.99 |
| 31 |
532169865 |
BEARING.PIVOT.LIFT This part replaces 532140302. Price: $3.99 |
| 32 |
873810600 |
Nut Lock 3/8-24 W/Nylon Insert (AYP part number) Price: $2.99 |
| 49 |
532140168 |
Bracket Stop inf. Hgt. (AYP part number) Price: $2.90 |
