| Ref | Part Number | Description |
|---|
| 1 |
137-8577 |
ES REEL-SPA 4 BOLT, 8 BLD This part replaces 12-3599. Price: $506.13 |
| 1 |
531167901 |
SERVICE KIT IMPELLER WELDMENT This part replaces 532184105. Price: $44.99 |
| 2 |
36-7190 |
GRASS SHIELD ASM Price: $89.46 |
| 2 |
598831601 |
Service Kit This part replaces 532427148. Price: $199.99 |
| 3 |
10-4930-01 |
BAR-BED This part replaces 10-4930. Price: $194.64 |
| 3 |
532188909 |
BEARING FLANGE Price: $24.99 |
| 4 |
36-7260 |
BAR-OFF, CUT Price: $24.10 |
| 4 |
532427146 |
PULLEY.FLANGE.IMPELLER Price: $29.99 |
| 5 |
104-2065 |
SCREW-HWH This part replaces 32144-73. Price: $0.28 |
| 5 |
585056901 |
CHUTE.DISCHARGE.BASE This part replaces 532442438. Price: $9.99 |
| 6 |
321-5 |
SCREW-HH Price: $0.22 |
| 6 |
597433002 |
Brackets This part replaces 532184095. Price: $3.99 |
| 7 |
532192199 |
CLEAN OUT TOOL Price: $14.99 |
| 7 |
94-6395 |
BEDKNIFE, LOWCUT, GR This part replaces 63-8500. Price: $60.45 |
| 8 |
119-4151 |
SCREW-BEDKNIFE This part replaces 57-4910. Price: $0.41 |
| 8 |
532405400 |
CLIP.CLEANOUT.TOOL Price: $2.99 |
| 9 |
21-8450 |
REAR ROLLER ASM Price: $188.65 |
| 9 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 873800400. Price: $1.99 |
| 10 |
52-3180 |
BEARING-ROLLER, FRONT This part replaces 21-8430. Price: $31.50 |
| 10 |
596322101 |
BOLT HEXAGON BOLT 1/4-20 X 1-5 This part replaces 874780426. Price: $2.99 |
| 11 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 11 |
594944401 |
NUT HEXAGON FLANGE 5/16-18 ST This part replaces 532427942. Price: $5.99 |
| 12 |
596031601 |
Screws This part replaces 532163183. Price: $2.99 |
| 12 |
65-8600 |
KNOB-ADJUSTMENT, HEIGHT Price: $43.42 |
| 13 |
3243-13 |
SCREW-SET, SQH Price: $3.32 |
| 13 |
532427145 |
HUB.IMP.PULLEY.D-SHAFT Price: $4.99 |
| 14 |
27-2650 |
HOC ADJUSTMENT ASM Price: $59.81 |
| 14 |
532427154 |
SLEEVE.IMP.PULLEY.D-SHAFT Price: $3.99 |
| 15 |
3290-125 |
SCREW-SET,HSH Price: $1.47 |
| 15 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532145212. Price: $3.99 |
| 16 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 16 |
532180355 |
BOLT.CARRIAGE.5/16-18X Price: $3.99 |
| 17 |
3217-9 |
NUT-HH Price: $0.37 |
| 17 |
532194189 |
SCREW.HWH.13-16-5.8.BZP Price: $4.99 |
| 18 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 18 |
532086447 |
PLUG.AUGER.GEAR.BOX.SNOW This part replaces 532407760. Price: $3.99 |
| 19 |
12-0460 |
CAPLUG Price: $2.84 |
| 20 |
323-2 |
SCREW-HH Price: $0.68 |
| 20 |
532427345 |
GASKET.GEAR.BOX Price: $4.99 |
| 21 |
10-5080-01 |
CAP-END This part replaces 10-5080. Price: $94.19 |
| 21 |
532174698 |
SEAL, OIL This part replaces 532407770. Price: $4.99 |
| 22 |
253-61 |
SEAL-OIL Price: $9.11 |
| 22 |
532174701 |
BUSHING FLANGE 1" This part replaces 532407762. Price: $29.99 |
| 23 |
3296-60 |
NUT-LOCK, NI Price: $5.08 |
| 23 |
532007396 |
WASHER RACE BEARING THRUST This part replaces 532174697. Price: $3.99 |
| 24 |
254-94 |
BEARING-CONE, TAPERED Price: $8.48 |
| 24 |
598831601 |
Service Kit This part replaces 532407763. Price: $199.99 |
| 25 |
254-72 |
BEARING-CUP, TAPERED Price: $9.67 |
| 25 |
532174657 |
SHAFT, AUGER This part replaces 532407764. Price: $59.99 |
| 26 |
108-6475 |
KIT-BEARING HOUSING This part replaces 10-5120. Price: $42.60 |
| 26 |
532189282 |
KEY, SQUARE 1/4 X .875 Price: $4.99 |
| 27 |
302-40 |
FITTING-GREASE, 90 DEG Price: $1.70 |
| 27 |
532174686 |
BUSHING.FLANGE.(.625X.75) This part replaces 532407758. Price: $22.99 |
| 28 |
217-74 |
BOLT-WHEEL Price: $4.87 |
| 28 |
532174683 |
WASHER, THRUST 5/8 Price: $6.99 |
| 29 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 29 |
532427147 |
SHAFT.IMPELLER.D-SHAFT Price: $74.99 |
| 30 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 30 |
532001572 |
PIN.ROLL.3/16 X 1" This part replaces 532184205. Price: $3.99 |
| 31 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 31 |
532174681 |
WASHER, THRUST 3/4 Price: $11.99 |
| 32 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 32 |
532174684 |
BEARING TRUST 3/4 NTA-1220 Price: $6.99 |
| 33 |
10-5060 |
BRACKET-HOC Price: $38.24 |
| 33 |
532407769 |
BUSHING, FLANGE 3/4 Price: $7.99 |
| 34 |
10-5010 |
SCREW-ADJUSTMENT, ROLLER Price: $53.13 |
| 34 |
532407768 |
O-RING Price: $3.99 |
| 35 |
3254-6 |
WASHER-LOCK, INTERNAL Price: $0.31 |
| 35 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 532407767. Price: $4.99 |
| 36 |
94-2958 |
STUD/BALL This part replaces 2411-7. Price: $6.70 |
| 37 |
11-0070 |
SCRAPER COMB ASM Price: $92.26 |
| 38 |
3254-8 |
WASHER-LOCK Price: $0.37 |
| 39 |
3219-1 |
NUT-HEX Price: $0.47 |
| 40 |
33-1000 |
SCRAPER BRUSH ASM Price: $54.29 |
| 41 |
33-0630 |
BRUSH Price: $24.64 |
| 42 |
3230-6 |
BOLT-CARR This part replaces 3-7253. Price: $0.59 |
| 43 |
253-96 |
SEAL-OIL Price: $6.85 |
| 44 |
3255-9 |
WASHER-LOCK Price: $0.28 |
| 45 |
57-3210 |
SCREW Price: $2.28 |
| 46 |
3233-26 |
SCREW-CARR, SHORT NECK Price: $2.21 |
| 47 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 48 |
3296-9 |
NUT-HEX Price: $0.25 |
| 49 |
8-2520 |
DISCONTINUED Price: Call Us |
| 50 |
3249-3 |
SCREW-PRH Price: $0.34 |
| 51 |
8-2530 |
COMB Price: $34.64 |
| 52 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 53 |
3255-8 |
WASHER-LOCK Price: $0.31 |
| 54 |
32108-20 |
SCREW Price: $0.61 |
| 55 |
70-1100 |
DISCONTINUED Price: Call Us |
| 56 |
93-1394 |
NUT-SPLINE This part replaces 10-5100. Price: $27.80 |
| 57 |
32128-36 |
NUT-HF Price: $1.56 |
| 58 |
321-4 |
SCREW-HH Price: $0.99 |
