| Ref | Part Number | Description |
|---|
| a |
None |
Screw, M4×16 |
| aa |
951-11349A |
FUEL DRAIN PLUG GASKET Price: $3.66 |
| b |
731P18251 |
CARBURETOR COVER Price: $3.89 |
| bb |
910-06752 |
DRAIN BOLT Price: $4.45 |
| c |
None |
Stepper Motor Shock Pad |
| cc |
710-06198 |
FUEL BOWL BOLT Price: $1.92 |
| d |
None |
Protecting Cover Gasket |
| dd |
None |
O-Ring, P18-2001 |
| e |
710-05268 |
SCREW M4-0.7x10 Price: $1.92 |
| ee |
619P05093 |
FLOAT BOWL Price: $9.41 |
| f |
None |
Stepping Motor |
| ff |
721P04699 |
SEAL Price: $1.92 |
| g |
None |
Electronic Conctol Driving Gear |
| gg |
None |
Main Jet |
| h |
None |
Choke Driven Gear |
| hh |
None |
Nozzle Tube |
| i |
None |
Choke Plate |
| ii |
793P00129A |
IDLE MIXTURE SCREW Price: $2.45 |
| j |
736-04638A |
LOCK WASHER Price: $2.88 |
| jj |
None |
Idle Adjusting Screw |
| k |
None |
Screw, M3×5 |
| kk |
None |
Spring |
| l |
732P06586 |
CHOKE SPRING Price: $1.78 |
| ll |
None |
Idle Jet |
| m |
None |
Idle Jet Rivet |
| mm |
None |
Idle Jet Board |
| n |
None |
O-Ring, 4×1.8G |
| nn |
None |
Screw, M3×6 |
| o |
737P05014 |
FUEL NIPPLE Price: $2.39 |
| oo |
732P06606 |
THROTTLE SPRING Price: $1.78 |
| p |
None |
Carburetor Body |
| pp |
None |
Throttle Plate |
| q |
711-06036 |
HINGE FLOAT PIN Price: $0.60 |
| qq |
None |
Throttle Driven Gear |
| r |
751P14036A |
NEEDLE VALVE Price: $5.16 |
| rr |
None |
Stepping Motor |
| s |
732P05251A |
NEEDLE VALVE SPRING Price: $1.70 |
| ss |
None |
Protecting Cover Jacket |
| t |
731P09131 |
CARBURETOR FLOAT Price: $2.89 |
| tt |
None |
Screw, M2.5×4 |
| u |
951-11970 |
FUEL BOWL GASKET Price: $5.95 |
| v |
None |
Idle Mixture Screw |
| w |
736-04629 |
WASHER Price: $3.56 |
| x |
None |
Screw, M5×8 |
| y |
951-22899 |
SOLENOID VALVE This part replaces 751-22899. Price: $19.99 |
| z |
736-05077 |
WASHER 12x8.2x.8 Price: $1.78 |
| 1 |
710-04919 |
BOLT M6-1 x 25 GR8.8 Price: $3.86 |
| 2 |
619P06373 |
VALVE COVER This part replaces 619-06373. Price: $23.91 |
| 3 |
951-14913 |
VALVE COVER GASKET Price: $12.13 |
| 4 |
651P05491 |
ROCKER ARM (EXHAUST) Price: $12.09 |
| 5 |
651P05490 |
ROCKER ARM (INTAKE) Price: $11.76 |
| 6 |
911-06414 |
ROCKER ARM SHAFT Price: $5.04 |
| 7 |
915-05035 |
CAMSHAFT PIN Price: $6.79 |
| 8 |
951-14909 |
EXHAUST VALVE Price: $23.50 |
| 9 |
710-06291 |
BOLT M10-1.25 x 70 Price: $4.31 |
| 10 |
708-07167 |
HEAT SHEILD Price: $1.70 |
| 11 |
710-04915 |
BOLT M6-1 x 12 GR8.8 Price: $3.82 |
| 12 |
951-14912A |
VALVE CAP Price: $3.03 |
| 13 |
951-14911A |
VALVE SPRING SEAT Price: $4.64 |
| 14 |
951-14910 |
VALVE SPRING Price: $8.85 |
| 15 |
951-11964A |
INTAKE VALVE SEAL Price: $9.96 |
| 16 |
951-14908 |
INTAKE VALVE Price: $23.50 |
| 17 |
710-05305 |
HOOK BOLT Price: $3.56 |
| 18 |
910-06299 |
STUD Price: $4.09 |
| 19 |
921-04744 |
EXHAUST GASKET Price: $6.13 |
| 20 |
751P22449 |
BAFFLE BRACKET Price: $7.40 |
| 21 |
951-14915 |
INTAKE PIPE RING Price: $4.31 |
| 22 |
631P08222 |
INTAKE MANIFOLD This part replaces 631-08222. Price: $6.83 |
| 23 |
710-06292 |
BOLT M6 x 22 Price: $4.40 |
| 24 |
710-06319 |
STUD M6-1.00 x 92 Price: $5.48 |
| 25 |
951-14947 |
INTAKE GASKET Price: $7.16 |
| 26 |
651P08733 |
CARBURETOR This part replaces 651-08733. Price: $58.10 |
| 26 |
751P22912 |
FUEL FILTER (WHITE 60 MICRON) Price: $5.29 |
| 27 |
921-04745 |
AIR FLTER GASKET Price: $6.13 |
| 28 |
631P08217 |
AIR FILTER BASE This part replaces 631-08217. Price: $17.08 |
| 29 |
712-05015 |
HEX NUT Price: $5.78 |
| 30 |
937-05066 |
AIR FILTER W/PREFILTER Price: $21.19 |
| 31 |
631P08214 |
AIR FILTER COVER This part replaces 631-08214. Price: $8.53 |
| 32 |
710-05303 |
BOLT 5.5 x 25 Price: $3.56 |
| 33 |
None |
PIN, 12x16 |
| 34 |
951-14898 |
SINGLE PUSH ROD Price: $19.91 |
| 35 |
951-15614 |
TAPPET Price: $5.95 |
| 36 |
951-10292A |
SPARK PLUG (F6RTC/RN11YC/BPR6ES) Price: $6.35 |
| 37 |
710-06290 |
BOLT M5-.8 x 10 Price: $4.31 |
| 38 |
936-05113 |
FLAT WASHER: 5.3 x 10 x 1 Price: $5.10 |
| 39 |
651P08707 |
CYLINDER HEAD This part replaces 651-08707. Price: $132.17 |
| 40 |
921-04743 |
CYLINDER HEAD GASKET Price: $14.47 |
| 41 |
951-05248 |
PISTON RING SET Price: $25.28 |
| 42 |
951-14905 |
PISTON Price: $48.83 |
| 43 |
911-06415 |
PISTON PIN Price: $8.96 |
| 44 |
951-11953A |
PISTON PIN SNAP RING Price: $3.42 |
| 45 |
651P08705 |
CONNECTING ROD This part replaces 651-08705. Price: $30.75 |
| 46 |
915-05026 |
DOWEL PIN Price: $4.40 |
| 47 |
725P14645 |
ELECTRIC STARTER Price: $233.93 |
| 48 |
710-04968 |
BOLT M6 x 16 Price: $5.77 |
| 49 |
751P18186 |
STARTER SHIELD BRACKET Price: $0.58 |
| 51 |
710-04916 |
BOLT M6-1 x 14 GR8.8 Price: $3.86 |
| 52 |
725P18483 |
REGULATOR This part replaces 725-18483. Price: $44.42 |
| 53 |
710-06286 |
BOLT M8-1.25 x 80 Price: $4.40 |
| 54 |
712-04276A |
ACORN NUT M6-1 Price: $5.38 |
| 55 |
736-05109 |
WASHER Price: $5.34 |
| 56 |
631P08216 |
ENGINE SHROUD (4X&AX90H0) This part replaces 631-08216. Price: $15.94 |
| 57 |
710-05303 |
BOLT 5.5 x 25 Price: $3.56 |
| 58 |
951-12205 |
DEBRIS SHIELD Price: $9.07 |
| 59 |
910-06310 |
STUD Price: $6.37 |
| 60 |
710-11659 |
STUD M6 X 113 Price: $2.84 |
| 61 |
912-05102 |
NUT M20 x 1.5 Price: $7.35 |
| 62 |
936-05110 |
WASHER 20.5 x 5 x 40 Price: $5.34 |
| 63 |
751P22232 |
COOLING FAN PLATE Price: $8.31 |
| 64 |
931-10866 |
COOLING FAN Price: $43.41 |
| 65 |
951-15766 |
Flywheel Price: $198.18 |
| 66 |
710-06448 |
BOLT M5 x 28 Price: $3.32 |
| 67 |
751P22615 |
ALTERNATOR This part replaces 751-22615. Price: $26.19 |
| 68 |
710-04943 |
BOLT-M6-1 x 28 GR8.8 Price: $3.76 |
| 69 |
751P22452 |
IGNITION MODULE Price: $18.22 |
| 70 |
951-14921 |
WIRE PLATE Price: $4.31 |
| 71 |
951-14922 |
BREATHER SCREEN Price: $4.31 |
| 72 |
937-05067 |
OIL SEAL 38 x 58 x 8 Price: $13.55 |
| 73 |
907-06254 |
BREATHER COVER Price: $7.20 |
| 74 |
921-04738 |
BREATHER COVER GASKET Price: $5.06 |
| 75 |
732-04718A |
BREATHER VALVE SPRING Price: $3.30 |
| 76 |
951-11614A |
BREATHER VALVE Price: $3.13 |
| 77 |
907-06255 |
BRACKET Price: $4.09 |
| 78 |
651P08708 |
CRANKCASE This part replaces 651-08708. Price: $251.81 |
| 79 |
None |
Not Used |
| 80 |
708P07164 |
ECM MOUNT BRACKET This part replaces 708-07164. Price: $5.12 |
| 81 |
725P18620 |
ENGINE CONTROL MODULE This part replaces 725-18428. Price: $43.45 |
| 82 |
710-06212 |
SCREW M4x12 Price: $1.56 |
| 83 |
951-11700A |
CARBURETOR HOSE CLAMP Price: $3.60 |
| 84 |
951-14091A |
PLUG Price: $2.68 |
| 85 |
723-04071A |
FUEL LINE SUPPORT CLAMP Price: $2.77 |
| 86 |
751-10349 |
FUEL HOSE LOW PERMEATION Price: $8.11 |
| 87 |
None |
Not Used |
| 88 |
931-10630A |
WIRE SUPPORT CLAMP Price: $4.75 |
| 89 |
None |
Not Used |
| 90 |
751P22616 |
TEMPERATURE SENSOR This part replaces 751-22616. Price: $6.83 |
| 91 |
907-06280 |
SHROUD - RIGHT Price: $10.34 |
| 92 |
921-04741 |
CRANKCASE COVER GASKET Price: $14.26 |
| 93 |
715-04096A |
DOWEL PIN 9 X 14 Price: $3.66 |
| 94 |
715-04092A |
DOWEL PIN 7 X 14 Price: $2.97 |
| 95 |
951-14916 |
VENTING HOSE Price: $4.31 |
| 96 |
917-05339 |
BALANCE SHAFT GEAR Price: $25.10 |
| 96 |
917-05340 |
DRIVE TIMING GEAR Price: $22.15 |
| 96 |
951-05245 |
CRANKSHAFT ASSEMBLY Price: $253.31 |
| 97 |
751P10307A |
WOODRUFF KEY Price: $2.01 |
| 98 |
936-05111 |
WASHER 38.3 x 54 x 1 Price: $4.40 |
| 99 |
917-05292A |
BALANCE SHAFT (LH) Price: $71.01 |
| 100 |
917-05293A |
BALANCE SHAFT (RH) Price: $71.01 |
| 101 |
936-05112 |
WASHER 17.2 x 26 x 1 Price: $4.40 |
| 102 |
919-05216 |
CAMSHAFT Price: $70.24 |
| 103 |
931-10867 |
FILTER COVER Price: $4.31 |
| 104 |
937-05069 |
BREATHER FILTER SCREEN Price: $4.20 |
| 105 |
951-14895 |
PRESSURE RELEASE COVER Price: $4.69 |
| 106 |
932-05290 |
PRESSURE RELEASE SPRING Price: $4.40 |
| 107 |
951-15588 |
OIL PUMP STEEL BALL Price: $3.50 |
| 108 |
951-12690 |
ENGINE OIL FILTER Price: $15.89 |
| 109 |
951-12253 |
SCREW JOINT OIL FILTER ADAPTER Price: $6.87 |
| 110 |
710-05313 |
BOLT M8 x 15 Price: $3.56 |
| 111 |
736-04560 |
OIL DRAIN PLUG WASHER Price: $3.68 |
| 112 |
951-05247 |
OIL PUMP ASSEMBLY Price: $51.44 |
| 113 |
921-04742 |
GASKET Price: $6.13 |
| 114 |
710-06289 |
BOLT M8 x 45 Price: $3.89 |
| 115 |
951-14896 |
OIL SEPARATOR Price: $4.69 |
| 116 |
710-06565 |
BOLT M6x12 Price: $1.70 |
| 117 |
710-06287 |
BOLT M6-1 x 45 CL5.8 Price: $4.40 |
| 118 |
924-05033A |
DIPSTICK ASSEMBLY Price: $23.50 |
| 119 |
721P07061 |
O-RING Price: $1.78 |
| 120 |
921-04740 |
O-RING Price: $4.31 |
| 121 |
651P08706 |
CRANKCASE COVER This part replaces 651-08706. Price: $152.68 |
| 122 |
951-11644 |
ENGINE PLUG 3/8 NPT Price: $8.96 |
| 651P08712 |
CYLINDER |
HEAD Price: $194.84 651P08712 |
| 651P08714 |
SHORT |
BLOCK Price: $728.12 651P08714 |
| 952MAX90H0 |
COMPLETE |
ENGINE 547cc This part replaces 752MAX90H0. Price: $1,635.17 952MAX90H0 |
