| Ref | Part Number | Description |
|---|
| 1 |
429624 |
CONSOLE PANEL Price: Call Us |
| 1 |
703-2135 |
STEERING SUPPORT Not Available Price: |
| 2 |
178668 |
HEADLIGHT BEZEL Price: Call Us |
| 2 |
747-3016 |
CLAMP Not Available Price: |
| 3 |
180927 |
FLOOD HEADLIGHT Price: Call Us |
| 3 |
712-0237 |
Nut, Hex Center Lock, 5/16-24 Price: $4.37 |
| 4 |
184471 |
SHOULDER SCREW 10-24 X .625 Price: Call Us |
| 4 |
710-1260A |
Self Tapping Screw, 5/16-18 x .75 This part replaces 710-3004. Price: $3.34 |
| 5 |
175262 |
SCREW 10-24 X 1.25 Price: Call Us |
| 5 |
736-0242 |
Washer, Bell, .345 x .88 x .060 Thk Price: $3.75 |
| 6 |
178770 |
WIRE HARNESS Price: Call Us |
| 6 |
912-3057 |
Hex Nut, 5/16-24 This part replaces 712-3057. Price: $5.94 |
| 7 |
712-3000 |
Nut, Hex Center Lock, 3/8-16 GR5 Price: $3.90 |
| 8 |
736-0169 |
Washer, Lock, 3/8 Price: $3.33 |
| 9 |
703-1857 |
BRACKET-PWR STEER BOX Not Available Price: |
| 11 |
719-3067 |
BRACKET, CYLINDER MOUNTING Not Available Price: |
| 12 |
710-3005 |
Screw, Hex Cap, 3/8-16 x 1.25 Lg GR5 Price: $3.61 |
| 13 |
736-0267 |
FLAT WASHER .38X.88 Price: $3.90 |
| 14 |
710-3032 |
Screw, Hex Cap, 1/2-13 x 1.25 Lg GR5 Price: $5.66 |
| 15 |
736-3084 |
Washer, Flat, .51 x 1.12 x .06 Thk HDN Price: $4.39 |
| 16 |
736-0921 |
Washer, Lock, 1/2 Price: $3.90 |
| 17 |
712-3022 |
Nut, Hex Center Lock, 1/2-13 GR5 Price: $3.61 |
| 18 |
736-3003 |
FLAT WASHER .531X.688X.054 Not Available Price: |
| 19 |
710-3177 |
CAP SCREW:.500-13X1.50 Not Available Price: |
| 20 |
923-3053 |
BALL JOINT This part replaces 723-3053. Price: $94.20 |
| 21 |
712-3029 |
Nut, Hex Jam, 1/2-20 GR5 Price: $6.01 |
| 22 |
717-3041A-0637 |
POWER STEERING CYLINDER Not Available This part replaces 717-3041A. Price: |
| 23 |
719-3065 |
STEERING ARM Not Available Price: |
| 24 |
912-3066 |
Hex Nut, 1/2-20 This part replaces 712-3066. Price: $6.01 |
| 25 |
710-3083 |
Screw, Hex Cap, 5/16-18 x 1.38 Lg GR5 Price: $3.94 |
| 51 |
105-9329 |
GASKET-FUNNEL, AIR This part replaces 99-9182. Price: $67.17 |
| 94 |
99-9224 |
VALVE-IDLE ADJ. Price: $34.96 |
| 104 |
99-9226 |
PIN-FLOAT HINGE Price: $9.60 |
| 105 |
99-9227 |
VALVE-NEEDLE Price: $53.84 |
| 113 |
99-9228 |
TUBE-JET Price: $38.19 |
| 117 |
99-9229 |
JET-MAIN Price: $60.43 |
| 117 |
99-9230 |
JET-MAIN (HIGH ALTITUDE) Price: $70.24 |
| 121 |
99-9231 |
CARBUERTOR KIT Price: $250.07 |
| 122 |
99-9184 |
SPACER-CARBURETOR Price: $68.15 |
| 125 |
99-9185 |
DISCONTINUED Price: Call Us |
| 131 |
99-9232 |
SHAFT-THROTTLE Price: $106.45 |
| 133 |
99-9233 |
FLOAT-CARBURETOR Price: $74.95 |
| 137 |
99-9234 |
GASKET-BOWL, FLOAT Price: $8.54 |
| 141 |
99-9235 |
SHAFT-CHOKE Price: $64.37 |
| 142 |
99-9236 |
NOZZLE-CARBURETOR Price: $67.26 |
| 151 |
99-9237 |
SCREW-CROSS / SLOTTED Price: $5.45 |
| 187 |
99-9238 |
LINE-FUEL Price: $23.90 |
| 240 |
108-3854 |
FILTER-FUEL This part replaces 99-9193. Price: $5.49 |
| 254 |
99-9239 |
DRAIN-CARBURETOR. BOWL Price: $16.82 |
| 355A |
99-9240 |
WASHER-SEAL Price: $10.99 |
| 387 |
99-9196 |
PUMP-FUEL Price: $291.24 |
| 601 |
99-9242 |
CLAMP-HOSE Price: $9.72 |
| 947 |
99-9243 |
SOLENOID-FUEL Price: $277.27 |
| 975 |
99-9244 |
BOWL-FLOAT Price: $57.63 |
| 1084A |
99-9199 |
CONNECTOR Price: $6.76 |
| 1084B |
99-9213 |
CONNECTOR Price: $7.44 |
| 1084C |
99-9245 |
CONNECTOR Price: $5.95 |
| 1091 |
99-9246 |
CAP-LIMITER Price: $9.99 |
