| Ref | Part Number | Description |
|---|
| 1 |
144927 |
Battery Price: Call Us |
| 1 |
3220-2 |
NUT-JAM Price: $0.50 |
| 2 |
107-1561 |
SEAL KIT This part replaces 105-3349. Price: $494.78 |
| 2 |
74760412 |
Bolt Hex Head 1/4-20 x 3/4 Price: Call Us |
| 5 |
3274-81 |
SCREW-HSH Price: $0.74 |
| 6 |
99-8701 |
ROTATING KIT This part replaces 93-6322. Price: $1,722.95 |
| 7 |
105-4572 |
SERVO PISTON ASM Price: $640.29 |
| 8 |
186491 |
Box Battery Price: Call Us |
| 8 |
94-3032 |
FOLLOWER-PISTON Price: $574.71 |
| 9 |
94-3033 |
PLATE-COVER Price: $121.09 |
| 10 |
105-9853 |
PLATE-COVER This part replaces 94-3034. Price: $142.29 |
| 11 |
94-3026 |
CAMPLATE ASM Price: $1,164.81 |
| 12 |
76-6950 |
RACE-THRUST Price: $25.65 |
| 13 |
76-6960 |
BEARING-THRUST Price: $23.23 |
| 14 |
105-2864 |
VALVE-BYPASS Price: $126.09 |
| 15 |
323-45 |
SCREW-HH Price: $0.68 |
| 16 |
105-2857 |
VALVE-RELIEF Price: $1,042.90 |
| 16 |
176138 |
Switch Interlock Push-In Price: Call Us |
| 17 |
3274-59 |
SCREW-HSH Price: $1.15 |
| 18 |
99-8704 |
PLATE-VALVE This part replaces 94-3022. Price: $457.47 |
| 19 |
105-2859 |
HOUSING ASM Price: $2,027.42 |
| 20 |
105-2860 |
BACKPLATE ASM Price: $1,120.74 |
| 21 |
105-2861 |
SHAFT-DRIVE Price: $431.22 |
| 21 |
175688 |
Harness Socket Light W/4152J Price: Call Us |
| 22 |
3217-5 |
NUT-HEX Price: $0.25 |
| 22 |
4152J |
Bulb Light Price: Call Us |
| 23 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 24 |
400254 |
Cable Battery Price: Call Us |
| 24 |
60-6240 |
WASHER This part replaces 94-3007. Price: $15.20 |
| 26 |
105-2858 |
VALVE-RELIEF Price: $1,100.81 |
| 26 |
175158 |
Fuse Price: Call Us |
| 27 |
105-2862 |
ARM-CONTROL Price: $36.88 |
| 27 |
73510400 |
Nut Keps Hex 1/4-20 unc Price: Call Us |
| 28 |
145491 |
Cable, Ground Price: Call Us |
| 28 |
93-6306 |
CONTROL ASM Price: $1,822.55 |
| 29 |
401545 |
Switch, Seat Price: Call Us |
| 29 |
94-3030 |
WASHER Price: $6.24 |
| 30 |
105-2863 |
ORIFICE Price: $56.40 |
| 30 |
193350 |
Switch, Ignition Price: Call Us |
| 33 |
140401 |
Key, Ignition Price: Call Us |
| 34 |
110712X |
Switch Light / Reset Price: Call Us |
| 40 |
194276 |
Harness Ignition Price: Call Us |
| 42 |
154336 |
Cover, Terminal Price: Call Us |
| 46 |
401763 |
Gauge Hourmeter Price: Call Us |
| 50 |
174653 |
Switch, PTO Price: Call Us |
| 55 |
17490512 |
Screw Thdrol 5/16-18 x 3/4 TYTT Price: Call Us |
| 59 |
400303 |
Outlet 12-Volt Price: Call Us |
| 71 |
400260 |
Harness Ign. Dash Price: Call Us |
| 79 |
175242 |
Bulbholder Asm. Incan Descent Price: Call Us |
| 90 |
400724 |
Cover Terminal Battery Price: Call Us |
| 91 |
190270 |
Strap Battery Mount Front Price: Call Us |
| 99 |
17670412 |
Screw Hexwsh Thdrol 1/4-20 x 3/4 Price: Call Us |
