| Ref | Part Number | Description |
|---|
| 0020 |
6219MA |
CORD, Electric, 10FT. 110V Price: $37.42 |
| 0050 |
704210 |
BOLT, 5/16-18X1.50 This part replaces 002X97MA. Price: $4.19 |
| 0060 |
028X76MA |
NUT,SPEED Price: $3.82 |
| 0070 |
703115 |
NUT This part replaces 1739305YP. Price: $3.06 |
| 0090 |
1501109MA |
PULLEY, Engine Price: $38.55 |
| 0100 |
703298 |
WASHER, 5/16 This part replaces 1919381SM. Price: $3.94 |
| 0110 |
703299 |
SCREW, 5/16-24X1 3/4 This part replaces 1921982SM. Price: $4.41 |
| 0120 |
1733324SM |
BELT, DRIVE Price: $17.10 |
| 0130 |
37X120MA |
BELT, Auger V4L 35.58 Price: $17.73 |
| 0140 |
1739070YP |
BELT GUIDE Price: $7.13 |
| 0150 |
5025170SM |
WASHER, 5/16" LOCK This part replaces 1917356SM. Price: $3.51 |
| 0160 |
703336 |
CAPSCREW, 5/16-24X.75 This part replaces 1921515SM. Price: $3.95 |
| 0170 |
1687797YP |
KIT, IDLER ASEM This part replaces 1501112YZMA. Price: $7.81 |
| 0180 |
1501065MA |
BUSHING,IDLER BRKT Price: $5.09 |
| 0190 |
165X164MA |
SPRING,EXT IDLER 8-13 Price: $6.68 |
| 0200 |
1502120MA |
IDLER, Plastic Ball Bearing Price: $20.34 |
| 0210 |
703230 |
NUT, 3/18-16, GR2 This part replaces 1960251SM. Price: $4.41 |
| 0220 |
1960268SM |
CARRIAGE BOLT, 3/8-16 x 1-1/4, G5 This part replaces 585781MA. Price: $3.61 |
| 0230 |
1501111YZMA |
ASSEMBLY, Auger Idler Price: $26.10 |
| 0240 |
1501200MA |
SPACER/AUGER BRKT Price: $5.23 |
| 0250 |
703128 |
WASHER This part replaces 1960027SM. Price: $3.19 |
| 0260 |
1733451SM |
ARM, Control Price: $19.49 |
| 0270 |
703300 |
PIN, 3/32 X 1.6 This part replaces 711682MA. Price: $3.50 |
| 0280 |
703313 |
PIN, CLEVIS, ZINC This part replaces 1736381YP. Price: $4.64 |
| 0290 |
1753969BMYP |
COVER, Bottom This part replaces 1740906ASM. Price: $65.85 |
| 0300 |
703054 |
SCREW, 1/4-20X0.625 This part replaces 1927429SM. Price: $3.82 |
| 0310 |
165X160MA |
SPRING, Extension, Auger Idler Price: $3.95 |
| 0320 |
1740572LYP |
FRAME BOX Price: $98.99 |
| 0330 |
1733583LYP |
PLATE, Engine Mount Price: $38.49 |
| 0340 |
703985 |
SCREW, 5/16-18X.5 This part replaces 1924856SM. Price: $3.61 |
| 0350 |
703228 |
SCREW, 5/16-18 X .75 This part replaces 1664847SM. Price: $3.94 |
| 0360 |
1733923SM |
COVER, Belt Price: $70.31 |
| 0370 |
1751355YP |
SCREW, 1/4-20 X 3/4 This part replaces 26X306MA. Price: $6.00 |
| 0400 |
1750172YP |
SEAL, Strip Price: $6.29 |
| 0410 |
703301 |
BOLT, HEX, 5/16-24X1 This part replaces 910828MA. Price: $3.51 |
| 0420 |
7023590SM |
PIN, Cotter, Self Locking, 1/4" Price: $3.61 |
| 0500 |
703302 |
WASHER, 5/16 This part replaces 7091528SM. Price: $3.82 |
| 0510 |
1750135YP |
SEAL, Engine Plate Price: $13.39 |
