| Ref | Part Number | Description |
|---|
| 1 |
105-9861 |
STEERING CYLINDER ASM Price: $1,317.06 |
| 3 |
340-97 |
FITTING-ELBOW, 90 DEG Price: $36.21 |
| 3 |
597688201 |
Covers Price: $27.99 |
| 4 |
74-5700 |
BEARING-NEEDLE, ROLLER Price: $27.84 |
| 5 |
32120-15 |
RING-SNAP, EXT Price: $1.20 |
| 6 |
32120-76 |
RING-SNAP, EXT Price: $0.34 |
| 7 |
340-9 |
FITTING-HYD, STRAIGHT Price: $67.47 |
| 8 |
340-142 |
FITTING-ELBOW-90 Price: $65.90 |
| 9 |
325-7 |
SCREW-HH Price: $1.53 |
| 10 |
106-9888 |
WASHER-FLAT Price: $0.49 |
| 11 |
121-3101 |
MOTOR-PISTON Price: $2,639.96 |
| 12 |
237-166 |
O-RING Price: $10.46 |
| 13 |
104-0755 |
PINION-27 TOOTH Price: $168.40 |
| 14 |
100-3053 |
GEAR-45 TOOTH Price: $220.85 |
| 14 |
587483301 |
KIT.HOOD.ASM.HUSQ.GT.TEX.668 This part replaces 532441177. Price: $74.99 |
| 17 |
93-5268 |
NUT-LUG Price: $2.20 |
| 18 |
597407101 |
Grilles Price: $84.99 |
| 20 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 21 |
32136-14 |
NUT-HST Price: $3.38 |
| 22 |
92-5836 |
WASHER Price: $5.34 |
| 23 |
110-4750 |
DRIVE AXLE ASM Price: $8,909.28 |
| 24 |
100-3796 |
SPACER-JOINT, BALL Price: $13.33 |
| 25 |
353-989 |
PLUG-HEX, HOLLOW Price: $21.59 |
| 26 |
32121-110 |
PIN-ROLL, SLOTTED Price: $1.93 |
| 27 |
115-9142 |
PIN-REAR AXLE Price: $103.95 |
| 28 |
92-1765 |
WASHER-THRUST Price: $2.57 |
| 29 |
98-3867 |
WASHER-THRUST Price: $3.21 |
| 30 |
3296-68 |
NUT-LOCK, NI Price: $14.67 |
| 31 |
302-33 |
FITTING-GREASE Price: $2.31 |
| 32 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 33 |
33114-025 |
SCREW-HH Price: $0.70 |
| 34 |
593944402 |
Engines Price: $74.99 |
| 36 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK This part replaces 817060512. Price: $4.99 |
| 36 |
95-7541 |
PLATE-COVER Price: $89.04 |
| 37 |
104-2353 |
PIN-DOWEL Price: $2.17 |
| 37 |
532441419 |
FENDER.TEX.SRD.CRD.BASE Price: $159.99 |
| 38 |
340-77 |
FITTING-ELBOW, 90 DEG Price: $24.95 |
| 39 |
340-98 |
FITTING-ELBOW, 90 DEG Price: $31.91 |
| 40 |
110-8829 |
SENDER-TEMPERATURE Price: $80.84 |
| 52 |
596040501 |
Hardware Price: $2.99 |
| 62 |
596728201 |
Bolts Price: $3.99 |
| 68 |
596030701 |
Screws Price: $2.99 |
| 119 |
596322601 |
Nuts Price: $2.99 |
| 130 |
596321701 |
Screws Price: $2.99 |
| 137 |
532407590 |
BUMPER DASH Price: $3.99 |
| 150 |
532439774 |
AIR.DUCT.GTV.BLACK Price: $39.99 |
| 151 |
531077401 |
SERVICE KIT PIVOT BRACKET BRAC This part replaces 532436670. Price: $37.99 |
| 152 |
531169901 |
SERVICE KIT SHIELD SHIELD.BROW This part replaces 532199535. Price: $19.99 |
| 162 |
596134101 |
Screws Price: $2.99 |
| 175 |
590607702 |
PLATE.PNT.CROSSMEMBER.HUSQ/PRE Price: $32.99 |
| 176 |
532400776 |
SCREW.#10-24X5/8.RN.QU Price: $4.99 |
| 177 |
532195228 |
BUSHING STEERING Price: $4.99 |
| 180 |
593898801 |
CHASSIS WELDMENT.CRD2.BKP_BLTS Price: $199.99 |
| 182 |
586738602 |
DASH LOWER.HUSQ.PRED NO CRUISE Price: $59.99 |
| 183 |
595305701 |
Screws Price: $3.99 |
| 189 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 194 |
596135701 |
GSPW Nuts Price: $2.99 |
| 195 |
532404137 |
PLUG.HOLE.DASH.LOWER.12V.BLK Price: $4.99 |
| 198 |
532441552 |
INDICATOR.DECK.LIFT.RED Price: $11.99 |
| 199 |
583371401 |
PLATE.DECKLIFT.SRD This part replaces 532418739. Price: $7.99 |
| 204 |
597408001 |
Vents Price: $19.99 |
| 213 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- Price: $3.99 |
| 214 |
532199145 |
CLIP.RETAINER.TINNER. Price: $2.99 |
| 217 |
532409167 |
ROD.PIVOT.HOOD Price: $9.99 |
| 218 |
532196395 |
X-PIECE.HOOD.STOP.NON/ Price: $6.99 |
| 235 |
596564201 |
Spacers Price: $4.99 |
| 236 |
873930500 |
NUT.CENTERLOCK.5/16- Price: $3.99 |
| 241 |
593337601 |
Screws Price: $3.99 |
| 246 |
591449001 |
SPRING.LTCH.BGR.GEN2.5.CRD.TEX Price: $1.99 |
| 247 |
582552602 |
STRAP.BATTERY.TCRD.GEN2.5X431 Price: $27.99 |
| 248 |
596039401 |
BOLT ROUND HEAD SQUARE NECK BO This part replaces 872110504. Price: $2.99 |
| 249 |
586936001 |
SCREW.BUTTONHD.10-24X1/2.(2 2) Price: $2.99 |
| 250 |
596040801 |
Hardware Price: $2.99 |
| 251 |
589318904 |
BRACKET.PNT.LH.SUPP.BKPLT.EDIP Price: $12.99 |
| 252 |
581992204 |
BRACKET.PNT.RH.SUPP.BKPLT.EDIP Price: $11.99 |
| 253 |
596238401 |
BOLT CUP HEAD SQUARE NECK BOLT Price: $2.99 |
| 254 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873900400. Price: $3.99 |
| 255 |
589392203 |
Bolts Price: $3.99 |
| 256 |
596219001 |
Nuts Price: $1.99 |
| 257 |
589746602 |
LATCH.ASM.BGR.LH.GEN2.5.STMPD Price: $19.99 |
| 258 |
589746702 |
LATCH.ASM.BGR.RH.GEN2.5.STMPD Price: $19.99 |
| 282 |
532414110 |
CLIP.RETAINER.CONSOLE.LT.HUSQ Price: $2.99 |
| 283 |
532447212 |
CONSOLE.DECKLIFT.CRDII.498 Price: $129.99 |
| 284 |
532447220 |
CONSOLE.PEDAL.HYDRO Price: $54.99 |
| 287 |
817600406 |
SCREW 1/4X20 Price: $2.99 |
| 308 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 309 |
582552502 |
BACKPLATE.TEXCRD2.5.BAGGER.479 Price: $129.99 |
| 319 |
581313907 |
LEVER.PRSNC.BGR.TEX.CRD.GEN2.1 Price: $11.99 |
| 334 |
583564401 |
BRACKET.ENGINE. This part replaces 532442537. Price: $8.99 |
| 338 |
594093901 |
Bolts Price: $1.99 |
| 339 |
583510301 |
SUBASM.BAGGER.FULL.LVER.(2 2) This part replaces 532436641. Price: $5.99 |
| 340 |
582552702 |
BATTERY.DOOR.TCRD.GEN2.5.MS479 Price: $32.99 |
| 341 |
582060801 |
LATCH.BATTERY.DOOR.TCRD Price: $3.99 |
| 342 |
582826802 |
SUPPORT.PNT.FENDER.CRD.TEX Price: $17.99 |
| 347 |
583566701 |
HITCH.TOW.TEX.CRD.GEN.2 This part replaces 532442887. Price: $12.99 |
| 368 |
581424801 |
FULL.LEVER.BAGGER.TEX.CRD Price: $3.99 |
| 370 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
| 375 |
586908201 |
BUMPER CLIP-ON. DASH 1" Price: $3.99 |
| 378 |
590849801 |
BUSHING FLANGE; PLASTIC Price: $3.99 |
| 531307007 |
TRACTOR |
BUMPER KIT ALL MODELS This part replaces 597334801. Price: $59.00 531307007 |
