| Ref | Part Number | Description |
|---|
| 1 |
217-111 |
CAP-HUB This part replaces 242-55. Price: $22.31 |
| 2 |
3272-17 |
PIN-COTTER Price: $1.79 |
| 2 |
532123583 |
SQUARE KEY Price: $3.99 |
| 3 |
32136-1 |
NUT-SLOTTED Price: $3.46 |
| 4 |
3256-29 |
WASHER-FLAT Price: $2.59 |
| 5 |
254-62 |
BEARING-ROLLER, CONE Price: $12.61 |
| 6 |
115-9471 |
BEARING-CUP This part replaces 254-61. Price: $6.46 |
| 7 |
93-0181 |
TIRE (11-14) 8 PLY Price: $212.68 |
| 8 |
217-103 |
BOLT-WHEEL Price: $2.51 |
| 9 |
5108 |
VALVE This part replaces 232-27. Price: $6.29 |
| 10 |
93-0182 |
DISCONTINUED Price: Call Us |
| 11 |
242-54 |
HUB Price: $168.31 |
| 12 |
254-66 |
CUP-BEARING, ROLLER Price: $17.92 |
| 13 |
254-65 |
BEARING-ROLLER, CONE Price: $62.13 |
| 14 |
253-127 |
SEAL Price: $74.45 |
| 15 |
325-3 |
SCREW-HH Price: $1.49 |
| 15 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 16 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 17 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 17 |
532197296 |
SPRING.BRAKE.HG3000/3500 Price: $5.99 |
| 18 |
13-6120 |
DISCONTINUED Price: Call Us |
| 19 |
67-5360 |
DECAL-DANGER Price: $14.99 |
| 20 |
13-6240 |
ADJUSTMENT ROD WA Price: $65.88 |
| 21 |
3218-6 |
NUT-JAM Price: $0.61 |
| 22 |
325-5 |
SCREW-HH Price: $1.20 |
| 23 |
13-6000-01 |
GEAR BOX BASE WA This part replaces 13-6000. Price: $968.55 |
| 24 |
3-3107 |
BUMPER-PEDAL, CLUTCH Price: $3.80 |
| 25 |
323-8 |
SCREW-HH Price: $1.20 |
| 26 |
3218-3 |
NUT-JAM Price: $0.25 |
| 27 |
3256-28 |
WASHER-FLAT Price: $0.48 |
| 28 |
235-15 |
GRIP-HANDLE Price: $11.84 |
| 29 |
32104-95 |
SCREW-HWH Price: $0.41 |
| 29 |
532423239 |
ROD.BRAKE.T2.TEX This part replaces 532408391. Price: $39.99 |
| 30 |
32104-96 |
SCREW-HH Price: $5.59 |
| 31 |
20-9580 |
ROPE-LATCH Price: $47.65 |
| 32 |
13-6910-01 |
SPACER-GUIDE, ROPE This part replaces 13-6910. Price: $18.39 |
| 33 |
13-6890-01 |
GUIDE-ROPE This part replaces 13-6890. Price: $119.16 |
| 33 |
812000001 |
E-RING LT Price: $3.99 |
| 34 |
2412-40 |
CLAMP-CONDUIT Price: $6.72 |
| 35 |
3217-9 |
NUT-HH Price: $0.37 |
| 35 |
596874801 |
Rods This part replaces 532401031. Price: $6.99 |
| 36 |
328-23 |
SCREW-HH Price: $13.03 |
| 37 |
3253-9 |
WASHER-LOCK Price: $1.02 |
| 37 |
532121749 |
WASHER Price: $2.99 |
| 38 |
3217-12 |
NUT-HEX Price: $3.12 |
| 39 |
323-2 |
SCREW-HH Price: $0.68 |
| 40 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 41 |
93-7709 |
PAD Price: $6.23 |
| 42 |
510089501 |
PAD, FOOT PEDAL This part replaces 532124872. Price: $4.99 |
| 42 |
603773 |
LOCKNUT This part replaces 32153-2. Price: $2.09 |
| 43 |
13-7460 |
PLATE-HITCH, CAUTION Price: $30.27 |
| 44 |
3259-15 |
DRIVE SCREW Price: $0.25 |
| 45 |
13-4310-01 |
TONGUE WA This part replaces 13-4310. Price: $4,199.75 |
| 46 |
13-6200 |
PIN-HITCH, POINTED Price: $40.83 |
| 47 |
3290-343 |
PIN-HAIR Price: $0.76 |
| 48 |
13-5870-01 |
FRONT SHIELD WA This part replaces 13-5870. Price: $376.54 |
| 49 |
13-5880-01 |
DROP SHAFT SHIELD WA This part replaces 13-5880. Price: $394.15 |
| 49 |
596136201 |
Bolts This part replaces 872110614. Price: $3.99 |
| 50 |
13-5790-01 |
SIDE SHAFT SHIELD This part replaces 13-5790. Price: $199.92 |
| 50 |
532194327 |
IDLER.FLAT.910.OFFSET Price: $17.99 |
| 51 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 51 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 52 |
532194326 |
IDLER.V-GROOVE.910.OFFSET Price: $19.99 |
| 56 |
532125907 |
BELT Price: $34.99 |
| 64 |
532197865 |
SHAFT.ASM.PEDAL.BRK.CNTR Price: $44.99 |
| 73 |
595316601 |
Bolts This part replaces 874490544. Price: $3.99 |
| 80 |
581550701 |
STRAP.TORQUE.T2 This part replaces 532408393. Price: $22.99 |
| 99 |
532408418 |
ROD.ASM.BYPASS.SPRING.T2.FS Price: $7.99 |
| 114 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 116 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 121 |
532175611 |
BRACKET STRAP TORQUE Price: $6.99 |
| 122 |
872010520 |
BOLT.5/16-18X2.5 Price: $4.99 |
| 125 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 143 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 153 |
532004497 |
RETAINER M This part replaces 532124788. Price: $4.99 |
| 159 |
596029501 |
Pins This part replaces 876020412. Price: $2.99 |
| 160 |
596029401 |
GSPW Retainers This part replaces 532169484. Price: $3.99 |
| 161 |
532105709 |
SPRING, RETURN LT Price: $9.99 |
| 163 |
594007201 |
Rods This part replaces 532413322. Price: $22.99 |
| 166 |
532429164 |
NUT.PUSH.625 This part replaces 532197290. Price: $4.99 |
| 167 |
531152901 |
SERVICE KIT LATCH LATCH.BRAKE. This part replaces 532405257. Price: $2.99 |
| 170 |
532413430 |
KEEPER.CENTER SPAN.1.688 Price: $5.99 |
| 183 |
532156972 |
SPACER, AXLE PVST Price: $5.99 |
| 184 |
532411484 |
HANDLE.PARKNG BRK.PRED.LT.428 This part replaces 532409747. Price: $24.99 |
| 185 |
872110622 |
BOLT Price: $3.99 |
| 187 |
596135501 |
Washers This part replaces 819133210. Price: $4.99 |
| 188 |
582217001 |
LINK.CLUTCH.GROUND DRIVE.LONG This part replaces 532194323. Price: $4.99 |
| 189 |
531169001 |
SERVICE KIT BELLCRANK This part replaces 532194317. Price: $6.99 |
| 190 |
532194318 |
KEEPER.BELLCRANK.DRIVE Price: $5.99 |
| 205 |
532121748 |
WASHER Price: $3.99 |
| 210 |
532400980 |
ROCKER.ASM.PEDAL.CONTR Price: $32.99 |
| 211 |
532120183 |
BEARING.NYLON Price: $5.99 |
| 214 |
532421263 |
PEDAL.FORWARD.PAD.TEX This part replaces 532401722. Price: $6.99 |
| 215 |
583376501 |
PAD.PEDAL.REVERSE This part replaces 532419482. Price: $8.99 |
| 216 |
532196131 |
BRACKET.PULLEY.IDLER.W/TEX Price: $6.99 |
| 221 |
532403187 |
RETAINER.SPRING.CLIP.H Price: $3.99 |
| 222 |
879212010 |
WASHER 21/32 X 1-1/4 X 10 GA. Price: $3.99 |
| 231 |
532407287 |
IDLER.V-GROOVE.1.688.OFFSET Price: $19.99 |
| 263 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 268 |
596140201 |
Washers This part replaces 819131614. Price: $2.99 |
| 275 |
583122001 |
GUARD.MUFFLER This part replaces 532182402. Price: $5.99 |
