| Ref | Part Number | Description |
|---|
| 1 |
38-6710 |
DISCONTINUED This part replaces 27-2070. Price: Call Us |
| 2 |
27-3100 |
SPLASH SHIELD Price: $101.97 |
| 2 |
532100710 |
Insert, Steering Wheel (AYP part number) Price: $10.20 |
| 3 |
27-2060 |
REAR UNIT RETURN HOSE Price: $50.97 |
| 3 |
874780616 |
Bolt, Hex 3/8-16 x 1 Gr. 5 (AYP part number) Price: $3.99 |
| 4 |
27-2080 |
DISCONTINUED Price: Call Us |
| 4 |
539990118 |
SLW 3/8 STD This part replaces 810040600. Price: $1.99 |
| 5 |
10-7490 |
DISCONTINUED Price: Call Us |
| 5 |
583789501 |
WASHER.13/32x2 3/8x12GA This part replaces 819133808. Price: $3.99 |
| 6 |
47-4840 |
HYD HOSE ASM This part replaces 27-2010. Price: $124.46 |
| 6 |
532100713 |
Wheel, Steering (AYP part number) Price: $64.99 |
| 7 |
27-2100 |
DISCONTINUED Price: Call Us |
| 7 |
532100711 |
Adapter, Steering (AYP part number) Price: $11.99 |
| 8 |
7-3123 |
DISCONTINUED Price: Call Us |
| 9 |
237-80 |
O-RING Price: $6.10 |
| 9 |
532100714 |
Sleeve, Steering (AYP part number) Price: $3.33 |
| 10 |
237-78 |
O-RING Price: $3.85 |
| 10 |
532009038 |
Bearing (AYP part number) Price: $3.10 |
| 11 |
47-4850 |
HYD HOSE ASM This part replaces 27-2020. Price: $121.00 |
| 11 |
532101274 |
Support Assembly, Steering (AYP part number) Price: $57.32 |
| 12 |
27-2090 |
DISCONTINUED Price: Call Us |
| 12 |
873350800 |
NUT.HEX.JAM.1/2-13 This part replaces 873680800. Price: $1.99 |
| 13 |
47-4830 |
DISCONTINUED This part replaces 10-7700. Price: Call Us |
| 13 |
532126881 |
Washer Compression (AYP part number) This part replaces 819172610. Price: $3.99 |
| 14 |
10-7500 |
DISCONTINUED Price: Call Us |
| 14 |
532104239 |
Bearing, Flanged (AYP part number) Price: $7.99 |
| 15 |
27-2930 |
LH TRACTION LINE Price: $113.24 |
| 15 |
812000034 |
Ring, Klip (AYP part number) Price: $2.99 |
| 16 |
27-2030 |
DISCONTINUED X-REF Price: Call Us |
| 16 |
532006266 |
WASHER THRUST This part replaces 532124956. Price: $5.99 |
| 17 |
237-42 |
O-RING Price: $2.78 |
| 17 |
532005213 |
Bracket, Frame Front (AYP part number) Price: $9.80 |
| 18 |
27-2000 |
DISCONTINUED X-REF Price: Call Us |
| 18 |
532102439 |
Bracket, Support, Steering (AYP part number) Price: $37.99 |
| 19 |
68-5880 |
HOSE-HYD This part replaces 28-2040. Price: $112.20 |
| 19 |
873680600 |
LOCKNUT This part replaces 873610600. Price: $1.99 |
| 20 |
27-2920 |
RH TRACTION LINE Price: $107.92 |
| 20 |
532120424 |
Assembly, Sector Gear (AYP part number) Price: $30.99 |
| 21 |
27-2110 |
RH CYL DROP HOSE Price: $118.00 |
| 21 |
874780880 |
Bolt, Hex 1/2-13 x 5 Gr. 5 (AYP part number) Price: $2.99 |
| 22 |
10-7630 |
DISCONTINUED Price: Call Us |
| 22 |
532102458 |
Shaft, Steering (AYP part number) Price: $63.88 |
| 23 |
10-7670 |
LH FRT RETURN HOSE Price: $49.52 |
| 23 |
532110497 |
Link, Drag (AYP part number) Price: $49.96 |
| 24 |
27-2950 |
LH CU PRESSURE LINE Price: $191.01 |
| 24 |
532106046 |
Spindle, L.H. (AYP part number) Price: $21.82 |
| 25 |
27-2940 |
DISCONTINUED Price: Call Us |
| 26 |
27-2970 |
DISCONTINUED Price: Call Us |
| 26 |
532109849 |
Rod, Tie Assembly (Inc. Key #56-60) (AYP part number) Price: $35.47 |
| 27 |
38-6730 |
DISCONTINUED This part replaces 10-7650. Price: Call Us |
| 27 |
532009040 |
BEARING T This part replaces 532124959. Price: $3.99 |
| 28 |
10-7660 |
DISCONTINUED Price: Call Us |
| 28 |
532124731 |
Rim Assembly, Front (AYP part number) Price: $3.33 |
| 29 |
33-0610 |
DISCONTINUED Price: Call Us |
| 29 |
532122075 |
TIRE.FRT.(16X6).TURF.SAVER This part replaces 532003938. Price: $54.99 |
| 29A |
532008134 |
Tube (AYP part number) Price: $37.99 |
| 30 |
812000029 |
Ring, Klip (AYP part number) Price: $1.99 |
| 31 |
532104757 |
Cap, Axle, Front (AYP part number) Price: $1.99 |
| 32 |
532121748 |
Washer 25/32 x 1-5/8 x 16 Ga. (AYP part number) Price: $1.99 |
| 33 |
532059192 |
Cap, Valve (AYP part number) Price: $3.99 |
| 34 |
532065139 |
Stem, Valve (AYP part number) Price: $5.99 |
| 35 |
532000278 |
FITTING LT This part replaces 532124957. Price: $2.99 |
| 36 |
532106045 |
Spindle, R.H. (AYP part number) Price: $12.34 |
| 38 |
532108137 |
Bellcrank Assembly (AYP part number) Price: $19.10 |
| 39 |
874781044 |
Bolt, Hex 5/8-11 x 2-3/4 Gr. 5 (AYP part number) Price: $3.99 |
| 41 |
532124836 |
Fitting, Grease (AYP part number) Price: $5.99 |
| 42 |
873221000 |
Nut, Hex 5/8-11 (AYP part number) Price: $3.99 |
| 43 |
810041000 |
Washer, Lock 5/8 (AYP part number) Price: $2.99 |
| 44 |
532005298 |
Tube, Pivot, Axle (AYP part number) Price: $5.99 |
| 45 |
532124686 |
Axle Assembly, Front (AYP part number) Price: $3.33 |
| 46 |
532140342 |
KIT GREASE FITTING This part replaces 532005292. Price: $19.99 |
| 48 |
532005284 |
Bracket, Axle (AYP part number) Price: $58.76 |
| 49 |
819292016 |
Washer 29/32 x 1-1/4 x 16 Ga. (AYP part number) Price: $3.99 |
| 50 |
532124858 |
Pulley, Idler (AYP part number) Price: $32.98 |
| 51 |
583789501 |
WASHER.13/32x2 3/8x12GA This part replaces 819133808. Price: $3.99 |
| 53 |
532120542 |
Bracket, Assembly Idler (AYP part number) Price: $34.17 |
| 54 |
532007190 |
Spring, Extension (AYP part number) Price: $7.82 |
| 56 |
532109851 |
Joint, Tie Rod.Thd., L.H. Price: $17.99 |
| 57 |
873700600 |
Nut, Hex Jam 3/8-24 L.H. (AYP part number) Price: $3.99 |
| 58 |
532109849 |
Rod, Tie (AYP part number) Price: $35.47 |
| 59 |
873360600 |
Nut, Hex Jam 3/8-24 (AYP part number) Price: $3.99 |
| 60 |
532121160 |
Joint, Tie Rod, R.H. Thread (AYP part number) This part replaces 532109850. Price: $12.99 |
| 61 |
874760612 |
Bolt Hex 3/8-16 x 3/4 (AYP part number) Price: $1.99 |
| 62 |
873680600 |
Locknut 3/8-16 Price: $1.99 |
| 63 |
874780612 |
Screw, Hex Wsh. Thrdrol. 3/8-16 x 3/4 (AYP part number) This part replaces 817490612. Price: $3.99 |
| 64 |
874780616 |
Bolt, Hex 3/8-16 x 1 Gr. 5 (AYP part number) Price: $3.99 |
| 65 |
874780616 |
BOLT This part replaces 874760616. Price: $3.99 |
| 66 |
819131413 |
Washer 11/32 x 7/8 x 13 Ga. (AYP part number) Price: $2.99 |
| 67 |
873220600 |
Nut, Hex 3/8-16 (AYP part number) Price: $3.99 |
| 68 |
874780516 |
BOLT.FIN.HEX.5/16-18UNC X 1.00 This part replaces 874930516. Price: $3.99 |
| 69 |
532100644 |
Bushing, Handle, Clutch (AYP part number) Price: $3.99 |
| 70 |
734116541 |
WASHER - 25X8.5X2.3 This part replaces 819111416. Price: $3.99 |
| 71 |
873800500 |
NUT.71038.31-18.HEX.NYLOCK This part replaces 873680500. Price: $2.99 |
| 72 |
532677928 |
PIN This part replaces 532106615. Price: $3.99 |
| 73 |
532121749 |
Washer 25/32 x 1-1/4 x 16 Ga. (AYP part number) Price: $1.99 |
| 74 |
874930632 |
BOLT.375-16 This part replaces 874760632. Price: $3.99 |
| 75 |
532102933 |
Spacer, Split (AYP part number) Price: $2.99 |
| 76 |
532121177 |
Collar Weld Assembly (AYP part number) Price: $13.56 |
| 77 |
874760636 |
Bolt 3/8-16 x 2-1/4 (AYP part number) Price: $2.99 |
| 79 |
532120199 |
Tube (AYP part number) Price: $6.99 |
| 80 |
532121232 |
Cover, Dust Cap (AYP part number) Price: $1.99 |
| 81 |
532121748 |
Washer 25/32 x 1-5/8 x 16 Ga. (AYP part number) Price: $1.99 |
| 82 |
532110946 |
Stop, Spindle (AYP part number) Price: $17.99 |
| 83 |
874520632 |
Bolt, Hex 3/8-16 x 2 (AYP part number) Price: $2.99 |
| 84 |
876020816 |
Pin, Cotter 1/4-1 (AYP part number) Price: $3.99 |
