| Ref | Part Number | Description |
|---|
| 1 |
21-1880 |
GRIP-HANDLE Price: $11.67 |
| 2 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $49.99 |
| 2 |
84-8500-01 |
LEVER-PTO This part replaces 21-1550. Price: $107.85 |
| 3 |
21-1600 |
CLAMP-LEVER, PTO Price: $279.65 |
| 4 |
32104-6 |
SCREW-HH, TAP Price: $3.19 |
| 5 |
3255-8 |
WASHER-LOCK Price: $0.31 |
| 6 |
283-15 |
PIN-CLEVIS Price: $4.07 |
| 7 |
21-2080 |
DISCONTINUED Price: Call Us |
| 8 |
21-1520 |
DISCONTINUED Price: Call Us |
| 9 |
3257-5 |
KEY-WOODRUFF Price: $5.13 |
| 9 |
584908001 |
KEEPER BELT ENGINE This part replaces 532194320. Price: $2.99 |
| 10 |
21-1810 |
DISCONTINUED Price: Call Us |
| 11 |
21-0230 |
PULLEY-PTO Price: $409.71 |
| 11 |
532414737 |
KIT.SVC.CLTCH.OG.1.125" This part replaces 532179335. Price: $229.99 |
| 12 |
3256-28 |
WASHER-FLAT Price: $0.48 |
| 12 |
532194343 |
PULLEY ENGINE Price: $44.99 |
| 13 |
3254-7 |
WASHER-LOCK, INT Price: $4.82 |
| 14 |
3219-7 |
NUT-HEX Price: $1.53 |
| 15 |
21-1460 |
DISCONTINUED Price: Call Us |
| 15 |
532193499 |
TANK.FUEL.4GAL Price: $99.99 |
| 16 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 17 |
3296-26 |
NUT-LOCK, NI Price: $2.99 |
| 18 |
3256-4 |
WASHER-FLAT This part replaces 3256-36. Price: $0.28 |
| 18 |
584248701 |
CAP.ASSY.FUEL.3".N-EPA.BLK.428 This part replaces 532430218. Price: $7.99 |
| 19 |
302-11 |
FITTING-LUBE, 45 DEG Price: $1.56 |
| 20 |
251-252 |
BEARING Price: $98.35 |
| 20 |
532423502 |
CONTROL.TH/CK.COBRA.B&S.TWN. Price: $19.99 |
| 21 |
251-234 |
COLLAR-LOCKING Price: $17.04 |
| 21 |
532416358 |
SCREW.#10 X 0.750.BOS (2 2) Price: $2.99 |
| 22 |
32120-22 |
RING-SNAP, INTERNAL Price: $2.29 |
| 23 |
21-0210 |
DISCONTINUED Price: Call Us |
| 24 |
32121-34 |
PIN-ROLL Price: $1.31 |
| 25 |
3245-1 |
SCREW-SET, HSH Price: $0.54 |
| 27 |
32121-9 |
PIN-ROLL, SLOTTED Price: $2.56 |
| 28 |
21-1830 |
SPRING-EXTENSION Price: $34.62 |
| 28 |
532401135 |
LINE.FUEL.64"REAR.EMIS Price: $19.99 |
| 29 |
21-0400-01 |
SPRING-COMPRESSION This part replaces 21-0400. Price: $20.88 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR(392390 B&S) Price: $129.99 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 41 |
532126197 |
WASHER Price: $4.99 |
| 42 |
539990247 |
WASHER 7/16 LOCK This part replaces 810040700. Price: $1.99 |
| 45 |
873680400 |
NUT.CROWNLOCK.1/4 This part replaces 873510400. Price: $2.99 |
| 62 |
532434017 |
SHIELD.HEAT.MUFFLER Price: $11.99 |
| 69 |
532165391 |
GASKET.MUFFLER Price: $9.99 |
| 79 |
532183906 |
SCREW.SOCKET.HEAD.5/16-18 Price: $3.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $2.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN Price: $11.99 |
| 84 |
817060620 |
SCREW.3/8-16 Price: $3.99 |
| 85 |
532179953 |
BOLT HEX 7/16-20 X 3.75 GR. 5 Price: $3.99 |
| 87 |
532198239 |
BOLT.5/16-18UNCX1.W/SEMS.BLK Price: $3.99 |
