| Ref | Part Number | Description |
|---|
| 1 |
159944X428 |
Wheel Steering Price: Call Us |
| 1 |
93-2085-01 |
ROD ASM Price: $134.61 |
| 2 |
172393 |
Axle Asm Cast Iron LT Price: Call Us |
| 2 |
74-9110 |
PAD-PEDAL, REVERSE Price: $13.49 |
| 3 |
169840 |
Spindle Asm LH Price: Call Us |
| 3 |
74-9100 |
PAD-PEDAL, FORWARD Price: $27.08 |
| 4 |
169839 |
Spindle Asm RH Price: Call Us |
| 4 |
49-6440-03 |
PEDAL-FORWARD Price: $84.90 |
| 5 |
32121-45 |
PIN-SPRING Price: $0.27 |
| 5 |
6266H |
Bearing Race Thrust Harden Price: Call Us |
| 6 |
121748X |
Washer 25/32 X 1-5/8 X 16 Ga Price: Call Us |
| 6 |
33124-020 |
SCREW-CARR Price: $0.88 |
| 7 |
321-9 |
SCREW-HH Price: $0.27 |
| 8 |
12000029 |
Ring Klip #t5304-75 Price: Call Us |
| 9 |
105-9750-01 |
PLATE-FLOOR Price: $194.85 |
| 10 |
175121 |
Link Drag Price: Call Us |
| 10 |
32144-14 |
SCREW-HWHTF Price: $4.29 |
| 11 |
10040600 |
Washer, Lock Hvy. Hlcl. Spr. 3/8 Price: Call Us |
| 11 |
94-1371 |
SPACER Price: $14.81 |
| 12 |
94-1383 |
PEDAL-PIVOT Price: $229.74 |
| 13 |
136518 |
Spacer Brg. Axle Front Price: Call Us |
| 13 |
256-311 |
BUSHING-SPLIT Price: $13.37 |
| 14 |
33115-090 |
SCREW-HH Price: $13.76 |
| 15 |
145212 |
Nut Hex Flange Lock Price: Call Us |
| 15 |
33023-00 |
NUT-LOCK Price: $0.25 |
| 16 |
107-2550 |
CABLE-CONTROL, TRACTION This part replaces 93-2099. Price: $194.40 |
| 17 |
177876 |
Shaft Asm. Steering Price: Call Us |
| 17 |
33024-00 |
NUT-LOCK, NI Price: $0.75 |
| 18 |
17-9420 |
SCREW-HANDLE Price: $3.49 |
| 19 |
94-1373 |
BRACKET-LOCK Price: $24.82 |
| 20 |
94-1372 |
BRACKET-MOW Price: $18.44 |
| 21 |
94-1375 |
TRUNNION-BRACKET, LOCK Price: $23.45 |
| 22 |
94-1374 |
TRUNNION-BRACKET, MOW Price: $14.18 |
| 23 |
94-1386 |
SHAFT-PEDAL Price: $44.42 |
| 24 |
94-1304 |
CABLE-LOCK, NEUTRAL Price: $153.45 |
| 25 |
32128-20 |
NUT-HF Price: $0.99 |
| 26 |
94-3489 |
SCREW-HH Price: $1.70 |
| 27 |
140-6108 |
PIN-FLAG, NEUTRAL LOCK This part replaces 94-1300. Price: $31.21 |
| 28 |
3256-1 |
WASHER-FLAT Price: $0.39 |
| 29 |
17060612 |
Screw 3/8-16x.75 Price: Call Us |
| 29 |
2411-41 |
ROD END-BALL JOINT Price: $40.28 |
| 30 |
3296-56 |
NUT-LOCK, NI Price: $2.09 |
| 31 |
93-2092 |
CLAMP-CABLE Price: $3.46 |
| 32 |
171888 |
Rod Tie Price: Call Us |
| 32 |
33114-016 |
SCREW-HH Price: $0.27 |
| 33 |
19111216 |
Washer 11/32 x 3/4 x 16 Ga. Price: Call Us |
| 33 |
33025-00 |
NUT-LOCK, NI Price: $0.54 |
| 34 |
10040500 |
Washer Lock Hvy Hlcl Spr 5/16 Price: Call Us |
| 34 |
93-2279 |
CLAMP-CABLE Price: $7.12 |
| 35 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 35 |
73540500 |
Crownlock Nut 5/16-24 Price: Call Us |
| 36 |
155099 |
Bushing Strg Price: Call Us |
| 36 |
33115-016 |
SCREW-HH Price: $0.75 |
| 37 |
152927 |
Screw Price: Call Us |
| 37 |
33014-00 |
NUT-HEX Price: $0.25 |
| 38 |
159946X428 |
Insert Cap Strg Wh Au Price: Call Us |
| 38 |
2411-38 |
JOINT-BALL Price: $21.96 |
| 39 |
19132411 |
Washer Price: Call Us |
| 39 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 40 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 40 |
7810H |
Lock nut Price: Call Us |
| 41 |
159945 |
Adaptor Wheel Strg Price: Call Us |
| 41 |
33093-00 |
WASHER-FLAT Price: $0.70 |
| 42 |
145054X428 |
Boot Steering Dash Price: Call Us |
| 43 |
121749X |
Washer 25/32 X 1 1/4 X 16 Ga Price: Call Us |
| 44 |
153720 |
Extension Steering Shaft LR/LT Price: Call Us |
| 46 |
121232X |
Cap Spindle Fr Top Blk Price: Call Us |
| 51 |
73800500 |
Nut Lock Hex w/Ins 5/16-18 Price: Call Us |
| 54 |
74780520 |
Bolt Fin Hex 5/16-18 Unc x 1-1/4 Price: Call Us |
| 63 |
74780616 |
Bolt Fin Hex 3/8-16unc x 1 Gr. 5 Price: Call Us |
| 65 |
160367 |
Brace Axle Price: Call Us |
| 67 |
72140618 |
Bolt Rdhd Sq 3/8-16 Unc x 2-1/4 Price: Call Us |
| 68 |
169827 |
Axle, Brace Price: Call Us |
| 71 |
175146 |
Steering Asm. Price: Call Us |
| 82 |
169835 |
Bracket Susp. Chassis Front Price: Call Us |
| 87 |
173966 |
Washer Flat .781 x 1-1/2 x .14 Price: Call Us |
| 88 |
175118 |
Bolt Shoulder 7/16-20 Unc Price: Call Us |
