| Ref | Part Number | Description |
|---|
| 0 |
640231 |
CARBURETOR This part replaces 632941B. Price: $66.62 |
| 1 |
119-4880 |
SCREW-HH Price: $28.36 |
| 1 |
532199606 |
DECK.WELDMENT.42".2GWB.BLACK This part replaces 532196495. Price: $229.99 |
| 2 |
119-4974 |
O-RING Price: $9.46 |
| 2 |
632928 |
SPRING Price: $2.60 |
| 3 |
125-8039 |
MANUAL VALVE ASM Price: $114.42 |
| 3 |
632926 |
CLIP Price: Call Us |
| 3A |
632950 |
SCREW Price: Call Us |
| 3B |
632949 |
SPACER Price: Call Us |
| 4 |
122-0385 |
HARNESS-WIRE, HOSE REEL Price: $230.60 |
| 4 |
632939A |
WASHER Price: Call Us |
| 5 |
632929A |
WASHER Price: $3.86 |
| 6 |
532195186 |
ARM.SUSPENSION.MOWER.R Price: $8.99 |
| 6 |
632930 |
SHUTTER Price: $10.29 |
| 7 |
532416358 |
SCREW.#10 X 0.750.BOS (2 2) Price: $2.99 |
| 7 |
632931 |
SCREW Price: $2.57 |
| 8 |
532193003 |
BOLT.WASHER.ASM.7/16-2 Price: $5.99 |
| 13 |
587253301 |
MANDREL.NONGREASEABLE.TALL This part replaces 532192872. Price: $32.99 |
| 14 |
532187281 |
HOUSING.MANDREL.4PT. Price: $22.99 |
| 15 |
532110485 |
BEARING Price: $7.99 |
| 17 |
632946 |
SCREW Price: $6.48 |
| 19 |
532196539 |
BOLT.SHOULDER Price: $4.99 |
| 20 |
532159770 |
BAFFLE.VORTEX Price: $12.99 |
| 20 |
632911 |
SCREW Price: $8.60 |
| 21 |
632912 |
SPRING Price: $2.60 |
| 21 |
873800500 |
NUT.71038.31-18.HEX.NYLOCK This part replaces 873680500. Price: $2.99 |
| 23 |
532192557 |
BRKT.DEFLECTOR.38"2005+ Price: $3.99 |
| 24 |
532105304 |
CAP-SLEEVE LT Price: $2.99 |
| 25 |
532197026 |
SPRING.TORSION.DEFLECT Price: $5.99 |
| 26 |
532110452 |
NUT PUSH M Price: $1.99 |
| 27 |
532403004 |
SHIELD.DEFLECTOR.MOWER.42"BLAC Price: $27.99 |
| 27 |
632916 |
PIN Price: $2.49 |
| 28 |
632915 |
LEVER Price: $2.60 |
| 29 |
532131491 |
ROD.HINGE Price: $1.99 |
| 30 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532173984. Price: $1.99 |
| 30 |
632918 |
INLET NEEDLE Price: $7.48 |
| 31 |
532187690 |
WASHER.SPACER.MANDREL Price: $1.99 |
| 31 |
632920 |
SPRING Price: $2.60 |
| 32 |
532195945 |
PULLEY.MANDREL.5.438.P This part replaces 532197473. Price: $7.99 |
| 33 |
532400234 |
NUT.FLANGE.LOCK.TOP Price: $3.99 |
| 34 |
632917 |
SCREW Price: Call Us |
| 34 |
872110612 |
BOLT.3/8-16X1.50 Price: $3.99 |
| 36 |
532196106 |
PULLEY.IDLER.2006 This part replaces 532197379. Price: $14.99 |
| 37 |
819131316 |
WASHER Price: $2.99 |
| 38 |
532432520 |
KEEPER.BELT.MANDREL.PULLEY Price: $5.99 |
| 40 |
532409148 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $2.99 |
| 40 |
632937 |
FUEL JET Price: $15.72 |
| 40A |
632953 |
SEALING CUP Price: $3.86 |
| 42 |
532198410 |
SPRING.TORSION.BRAKE Price: $2.99 |
| 43 |
532197256 |
SRPING.TORSION.RETAINE Price: $2.99 |
| 45 |
632919 |
SCREEN Price: $2.45 |
| 46 |
532137729 |
SCREW.1/4-20X5/8 Price: $2.99 |
| 47 |
532197250 |
BRKT.CLUTCH.CABLE Price: $2.99 |
| 48 |
632902 |
WELCH PLUG Price: Call Us |
| 50 |
632904 |
DIAPHRAGM Price: $14.93 |
| 51 |
632903 |
GASKET Price: $2.60 |
| 52 |
632905 |
COVER Price: Call Us |
| 53 |
632943 |
SCREW Price: $2.28 |
| 55 |
532437110 |
IDLER.ARM.42" Price: $4.99 |
| 56 |
532199092 |
SPACER.RETAINER Price: $3.99 |
| 57 |
817000616 |
SCREW 3/8-16X1 Price: $3.99 |
| 60 |
632933 |
REPAIR KIT Price: Call Us |
| 62 |
640252 |
PUMP DIAPHRAGM This part replaces 632908. Price: $3.86 |
| 62 |
872110616 |
BOLT Price: $3.99 |
| 63 |
532199478 |
ARM.BRAKE.ZINC This part replaces 532199477. Price: $12.99 |
| 63 |
632907 |
GASKET Price: $2.60 |
| 64 |
532199918 |
LINKAGE.BRAKE.ASM.ZINC This part replaces 532199790. Price: $12.99 |
| 64 |
632944 |
COVER Price: $7.34 |
| 65 |
632945 |
SCREW Price: $3.61 |
| 67 |
532403012 |
HANDLE.CLUTCH.CABLE.LT Price: $7.99 |
| 68 |
532429636 |
BELT.DECK.DRIVE.42" Price: $32.99 |
| 69 |
872140505 |
BOLT Price: $2.99 |
| 70 |
532198332 |
CLUTCH.ASM.MANUAL.LT.TEX Price: $54.99 |
| 113 |
817000510 |
BOLT.5/16HEX.WHS.HD Price: $3.99 |
| 116 |
532004898 |
BOLT This part replaces 532124842. Price: $1.99 |
| 117 |
589527401 |
WHEEL.GAUGE.RALLY.NARROW This part replaces 532188606. Price: $2.99 |
| 119 |
734117201 |
WASHER This part replaces 819121414. Price: $1.99 |
| 144 |
532199204 |
KEEPER.BELT.MOWER Price: $3.99 |
| 145 |
532177968 |
PULLEY.IDLER.FLAT This part replaces 532193197. Price: $14.99 |
| 147 |
532401971 |
RETURN SPRING Price: $3.99 |
| 152 |
532435111 |
CABLE.CLUTCH.MANUAL. Price: $19.99 |
| 188 |
532195161 |
STUD.FASTNER.W/ANTI-ROTATE Price: $3.99 |
| 189 |
583612701 |
NUT HEX,LOCK,FLAN This part replaces 873900500. Price: $3.99 |
| 192 |
532197260 |
BRKT.BRAKE.STAND.LH. Price: $8.99 |
| 195 |
817000612 |
SCREW, 3/8-16X3/4 Price: $2.99 |
| 241 |
532152927 |
SCREW.TT.#10-32X.5.3/8.FLANGE Price: $3.99 |
| 242 |
532415598 |
PORT.WASHOUT Price: $5.99 |
