| Ref | Part Number | Description |
|---|
| 1 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 1 |
419797X479 |
LOWER TUBE Price: Call Us |
| 2 |
3296-49 |
NUT-LOCK, NI Price: $4.93 |
| 2 |
418313X479 |
PIVOT SUPPORT Price: Call Us |
| 3 |
3-8514 |
WASHER-THRUST Price: $1.58 |
| 3 |
428867 |
BOLT 5/16-18 X .750 Price: Call Us |
| 4 |
69-8390 |
SPINDLE PULLEY ASSEMBLY This part replaces 69-8390-01. Price: $162.41 |
| 5 |
253-154 |
SEAL-OIL Price: $5.48 |
| 6 |
71-2530 |
BEARING/SPACER KIT Price: $160.66 |
| 7 |
3231-22 |
SCREW-CARR Price: $0.72 |
| 8 |
69-1530 |
HOUSING-SPINDLE Price: $227.62 |
| 9 |
32128-21 |
NUT-HF Price: $0.39 |
| 10 |
138-6388 |
SHAFT-SPINDLE This part replaces 69-6760. Price: $189.44 |
| 11 |
138-6416 |
SPACER-SPINDLE, SHAFT This part replaces 92-9800. Price: $18.44 |
| 12 |
69-6920-03 |
BLADE-20 IN. This part replaces 69-6920-01. Price: $31.92 |
| 13 |
67-7561 |
CUP-SCALP, ANTI Price: $40.99 |
| 14 |
3253-8 |
WASHER-LOCK Price: $0.47 |
| 15 |
51-4060 |
SCREW-BLADE Price: $7.39 |
