| Ref | Part Number | Description |
|---|
| 1 |
137-6115 |
TUBE ROLLER 3.0IN DIA X 20.5IN This part replaces 115-8296-03. Price: $139.68 |
| 1 |
530015880 |
Screw Price: $1.99 |
| 2 |
119-4287 |
SHAFT-REAR ROLLER, 27 INCH Price: $338.12 |
| 2 |
530069232 |
Rope Kit Price: $3.99 |
| 3 |
530069885 |
Starter Pulley Kit Price: $8.99 |
| 4 |
530049488 |
Starter Handle Price: $1.99 |
| 5 |
545008011 |
KIT STARTER SPRING This part replaces 530042086. Price: $5.99 |
| 6 |
530049501 |
Fan Housing w/bearing Price: $3.33 |
| 7 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 7 |
530016386 |
SCREW This part replaces 530015810. Price: $5.99 |
| 8 |
32151-62 |
RING-RETAINING Price: $1.49 |
| 8 |
530015815 |
Screw Price: $1.99 |
| 9 |
119-1868 |
WASHER Price: $2.49 |
| 9 |
530019240 |
O-Ring Price: $3.99 |
| 10 |
119-4276 |
ROLLER-TIPPER Price: $89.28 |
| 10 |
530029182 |
Eyelet Price: $1.99 |
| 12 |
530095355 |
Mulch Blade This part replaces 530095461. Price: $3.99 |
| 13 |
530016279 |
Washer-Flat Model 1650 Price: $1.99 |
| 14 |
530626605 |
Nut Price: $1.99 |
| 15 |
530049313 |
Inlet Door Price: $4.99 |
| 16 |
530402043 |
Spring-Return Cover Price: $2.99 |
| 17 |
530049297 |
Crankcase Cover Price: $6.99 |
| 18 |
530019181 |
Gasket-Crankcase Shroud Price: $1.99 |
| 19 |
530049429 |
Crankshaft Ass'y. Price: $17.99 |
| 20 |
530032125 |
Inner Bearing Price: $11.99 |
| 21 |
530032124 |
Outer Bearing Price: $4.99 |
| 22 |
530019179 |
Crankcase Seal Price: $2.99 |
| 23 |
530015945 |
Retaining Ring Price: $1.99 |
| 26 |
530023817 |
Spring-Starter Dog Price: $1.99 |
| 27 |
530016190 |
Flywheel Spacer Price: $2.99 |
| 28 |
530049713 |
Foam Seal Price: $0.56 |
| 29 |
530016203 |
Muffler Bolt Price: $1.99 |
| 30 |
530049454 |
Muffler Cover Plate Price: $1.99 |
| 31 |
530052241 |
Muffler Ass'y. Price: $4.99 |
| 32 |
530015941 |
Retainer Ring-C'chaft Price: $1.99 |
| 33 |
530049502 |
Muffler Shield Price: $2.99 |
| 34 |
530015953 |
Screw Price: $1.99 |
| 35 |
503235112 |
Spark Plug This part replaces 952030201. Price: $5.99 |
| 36 |
530069813 |
Gasket Kit Price: $7.99 |
| 37 |
530019247 |
Air Dam Price: $1.99 |
| 38 |
530039163 |
Ignition Module Price: $34.99 |
| 39 |
530016208 |
Bolt Price: $1.99 |
| 40 |
530015127 |
Washer Price: $1.99 |
| 41 |
545154001 |
RING PISTON This part replaces 530049903. Price: $1.99 |
| 42 |
530015162 |
Retainer Price: $1.99 |
| 43 |
530049817 |
CONNECTING ROD ASSY This part replaces 530069945. Price: $6.99 |
| 45 |
530016226 |
Pulley Retainer Price: $1.99 |
| 46 |
530054114 |
Fan Housing This part replaces 530032108. Price: $7.99 |
| 47 |
530069865 |
Cylinder Price: $1.92 |
| 48 |
530019182 |
Grommet-Ign. Module Price: $1.99 |
| 49 |
530016080 |
Screw-Starter Pulley Price: $1.99 |
| 50 |
114-5430 |
ROLLER REBUILD KIT Price: $99.53 |
| 50 |
530016240 |
Washer-Belleville Price: $1.99 |
