| Ref | Part Number | Description |
|---|
| 1 |
237-22 |
O-RING Price: $2.43 |
| 2 |
340-98 |
FITTING-ELBOW, 90 DEG Price: $31.91 |
| 2 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $39.99 |
| 4 |
98-4586 |
HOSE ASM - HYD This part replaces 94-5444. Price: $121.91 |
| 5 |
340-4 |
FITTING-STRAIGHT Price: $11.58 |
| 6 |
93-3611 |
CONTROL BLOCK ASSY Price: $5,879.89 |
| 7 |
237-78 |
O-RING Price: $3.85 |
| 9 |
237-79 |
O-RING Price: $5.46 |
| 9 |
532194319 |
KEEPER.BELT.ENGINE.3.25 (3 2) Price: $11.99 |
| 10 |
340-101 |
FITTING-HYD, 45 DEG Price: $31.00 |
| 11 |
354-77 |
FITTING-QUICK Price: $55.94 |
| 11 |
583389701 |
KIT.SVC.CLUTCH.ELE.180505 This part replaces 532180505. Price: $299.99 |
| 12 |
354-79 |
CAP-DUST Price: $7.81 |
| 12 |
532194338 |
PULLEY.ASM.ENG.OGURA.3 Price: $54.99 |
| 13 |
237-30 |
O-RING Price: $2.50 |
| 14 |
86-9190 |
HOSE Price: $84.09 |
| 15 |
532194264 |
TANK.ASM.FUEL.REAR.W/CAP.2.5 This part replaces 532197024. Price: $89.99 |
| 17 |
340-92 |
FITTING-STRAIGHT Price: $12.29 |
| 18 |
237-21 |
O-RING Price: $0.70 |
| 18 |
584248701 |
CAP.ASSY.FUEL.3".N-EPA.BLK.428 This part replaces 532195951. Price: $14.99 |
| 20 |
532175437 |
CONTROL.THROTTLE.BLACK This part replaces 532178385. Price: $24.99 |
| 20 |
75-6640 |
FITTING-HYD, SPECIAL Price: $80.34 |
| 21 |
596321701 |
Screws This part replaces 532191611. Price: $2.99 |
| 21 |
93-0078 |
HOSE ASM Price: $189.33 |
| 22 |
237-65 |
O-RING Price: $2.50 |
| 22 |
532191596 |
CONTROL.CHOKE.ERGO.PUSH-IN.BLA Price: $32.99 |
| 23 |
340-139 |
FITTING-ELBOW 90 Price: $117.76 |
| 24 |
94-4913 |
DISCONTINUED Price: Call Us |
| 25 |
93-3612 |
FITTING-ELBOW 90 Price: $107.81 |
| 26 |
237-81 |
O-RING Price: $2.76 |
| 27 |
98-9347 |
HYD HOSE ASM This part replaces 94-4914. Price: $212.81 |
| 28 |
322-3 |
SCREW-HH Price: $0.79 |
| 28 |
587044864 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532401135. Price: $17.99 |
| 29 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 30 |
75-5900 |
HOSE Price: $78.45 |
| 31 |
532145006 |
PUSH CLIP Price: $2.99 |
| 31 |
82-8270 |
FLOW CONTROL VALVE Price: $181.62 |
| 32 |
340-143 |
ELBOW-SWIVEL, 90 DEG Price: $58.91 |
| 33 |
93-0118 |
HOSE ASM Price: $123.69 |
| 35 |
75-5890 |
HOSE Price: $75.32 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 37 |
98-4589 |
HOSE ASM - HYD This part replaces 94-5447. Price: $205.06 |
| 38 |
93-3642 |
TUBE-PUMP, PORT 1 Price: $90.68 |
| 39 |
93-3643 |
TUBE-PUMP, PORT 2 Price: $78.42 |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 62 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532146629. Price: $11.99 |
| 69 |
532165391 |
GASKET.MUFFLER Price: $9.99 |
| 70 |
581881101 |
EXHAUST.TUBE.LH.BS/TWIN This part replaces 532159955. Price: $27.99 |
| 71 |
581881001 |
EXHAUST.TUBE.RH.B&S.TWIN.INTEK This part replaces 532160589. Price: $22.99 |
| 79 |
596134202 |
Screws This part replaces 532183906. Price: $2.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN This part replaces 532181654. Price: $14.99 |
| 83 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 84 |
817060620 |
SCREW.3/8-16 Price: $5.99 |
| 85 |
501606501 |
BOLT.HEX.7/16-20X4.GR5.1.5BLUE This part replaces 532173937. Price: $2.99 |
