| Ref | Part Number | Description |
|---|
| 1 |
115-4362 |
SCREEN ASM Price: $1,675.38 |
| 2 |
115-4357 |
LATCH-KEEPER Price: $4.16 |
| 2 |
532188655 |
MUFFLER.SINGLE.CYL.KOHL/B&S Price: $39.99 |
| 3 |
3269-3 |
RIVET-POP Price: $0.25 |
| 4 |
125-4576 |
HOOD ASM Price: $4,129.47 |
| 5 |
117-2382 |
PLUG-PLASTIC Price: $0.69 |
| 6 |
114-4192-03 |
SCREEN-HOOD Price: $277.03 |
| 9 |
3290-467 |
PIN-HAIR Price: $0.27 |
| 9 |
596501502 |
Keepers This part replaces 501832602. Price: $9.99 |
| 10 |
120-8020-03 |
BUMPER-REAR Price: $797.60 |
| 12 |
240-14 |
BUMPER-RUBBER Price: $13.84 |
| 12 |
586478501 |
ENGINE.PULLEY Price: $27.99 |
| 13 |
32128-33 |
NUT-HF Price: $0.25 |
| 15 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 15 |
581289901 |
FUEL.TANK.ASM.NON-EPA Price: $44.99 |
| 17 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 18 |
325-6 |
SCREW-HH Price: $1.42 |
| 18 |
581075501 |
CAP.2.25'.VENTED.RATCHET.EPA This part replaces 532430220. Price: $22.99 |
| 19 |
325-33 |
SCREW-HH Price: $11.49 |
| 20 |
114-8108-03 |
TUBE-RH Price: $145.06 |
| 20 |
587242604 |
THROTTLE CABLE This part replaces 587242601. Price: $27.99 |
| 21 |
114-8109-03 |
TUBE-LH Price: $145.06 |
| 21 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 22 |
121-3136-0P |
TUBE ASM R.H. [PRIMED] This part replaces 121-3136-03. Price: $175.86 |
| 23 |
114-8102-0P |
TUBE ASM This part replaces 114-8102-03. Price: $122.71 |
| 24 |
121-3133-0P |
TUBE-HOOD FRAME This part replaces 121-3133-03. Price: $143.88 |
| 25 |
94-5781 |
SCREW-HHF Price: $4.47 |
| 26 |
104-7201 |
NUT-HF Price: $0.69 |
| 27 |
3290-55 |
RIVET-POP Price: $0.25 |
| 28 |
59-9740 |
FLEX DRAW LATCH ASM Price: $36.89 |
| 29 |
105-9877 |
DECAL Price: $59.64 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 30 |
66-1210 |
DECAL Price: $27.06 |
| 31 |
106-6754 |
DECAL-DANGER Price: $9.57 |
| 32 |
249-40 |
KEEPER Price: $9.77 |
| 33 |
3269-17 |
RIVET-POP Price: $0.25 |
| 34 |
3269-10 |
WASHER-BACK Price: $0.61 |
| 35 |
98-1629 |
WASHER Price: $0.89 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 42 |
596238901 |
Washers This part replaces 539990247. Price: $2.99 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 69 |
532272293 |
GASKET.ENG.1.313 ID.TIN PLATED This part replaces 532165291. Price: $8.99 |
| 79 |
596134201 |
Screws This part replaces 532192334. Price: $2.99 |
| 84 |
817060620 |
SCREW.3/8-16 Price: $5.99 |
| 85 |
501606501 |
BOLT.HEX.7/16-20X4.GR5.1.5BLUE Price: $2.99 |
| 87 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 94 |
581880901 |
EXHAUST.TUBE.B&S.28/31 Price: $19.99 |
| 96 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
| 97 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
| 99 |
119-2004 |
CE LATCH KIT Price: $25.85 |
| 102 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 105 |
501267202 |
SHIELD.SIDE.LH.3842"TEX FRN.BK Price: $12.99 |
| 106 |
501268202 |
SHIELD.SIDE.LH.3842"TEX FRN.BK Price: $11.99 |
| 108 |
587179509 |
COVER ENGINE PULLEY COVER WITH Price: $69.99 |
| 115 |
532431761 |
RETAINER Price: $3.99 |
| 122 |
532421922 |
EXTENSION DRAIN OIL Price: $24.99 |
| 136 |
596434001 |
Screws This part replaces 532421756. Price: $2.99 |
