| Ref | Part Number | Description |
|---|
| 1 |
701178 |
CAP-PROTECTOR Price: $1.45 |
| 2 |
3296-58 |
NUT-LOCK, NI Price: $2.19 |
| 3 |
92-7054 |
SPRING-COMPRESSION Price: $13.32 |
| 4 |
322-4 |
SCREW-HH Price: $0.35 |
| 5 |
105503 |
BUSHING Price: $0.61 |
| 6 |
92-6986 |
BOLT-SHOULDER Price: $6.88 |
| 7 |
104-5027 |
DISCONTINUED Price: Call Us |
| 8 |
92-6750 |
SPACER-NYLON Price: $9.49 |
| 9 |
119-8887 |
SEAT-HIGH BACK This part replaces 104-2463. Price: $346.62 |
| 10 |
32144-14 |
SCREW-HWHTF Price: $4.29 |
| 11 |
104-5077-01 |
FENDER Price: $378.48 |
| 12 |
79-0970-03 |
BRACKET-PIVOT, LH Price: $8.10 |
| 13 |
109989 |
SPACER-NYLON Price: $5.09 |
| 14 |
94-2869 |
WASHER Price: $0.88 |
| 15 |
700806 |
KNOB Price: $13.09 |
| 16 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 17 |
79-0950-03 |
BRACKET-PIVOT, RH Price: $9.37 |
| 19 |
100-3524 |
SWITCH-SEAT Price: $57.99 |
| 20 |
3250-31 |
SCREW-PPH Price: $0.25 |
| 21 |
108547 |
DISCONTINUED Price: Call Us |
| 22 |
105202 |
DISCONTINUED Price: Call Us |
| 23 |
3254-1 |
WASHER-LOCK, INT Price: $0.49 |
| 24 |
3296-27 |
NUT-LOCK, NI Price: $0.27 |
| 25 |
104-2488 |
FOAM-SWITCH, SEAT Price: $4.36 |
| 26 |
112564 |
LENS-TAIL LIGHT Price: $5.40 |
| 28 |
106-5846 |
DECAL-FENDER, REAR This part replaces 92-9827. Price: $16.59 |
| 30 |
76-1340 |
DECAL - USA Price: $8.41 |
| 31 |
3255-8 |
WASHER-LOCK Price: $0.31 |
| 32 |
62-7770 |
KEY-IGNITION Price: $4.39 |
| 35 |
46-5780 |
STARTER SWITCH ASM Price: $22.97 |
| 36 |
104-0838 |
DISCONTINUED Price: Call Us |
