| Ref | Part Number | Description |
|---|
| 1 |
596580701 |
Nuts This part replaces 539990184. Price: $2.99 |
| 1 |
603-0860-0637 |
UPPER SEAT PIVOT BRACKET (POWDER BLACK) Not Available Price: |
| 2 |
603-0866 |
SEAT TRACK ASSEMBLY W/LATCH Not Available Price: |
| 2 |
874780528 |
SCREW This part replaces 539990669. Price: $4.99 |
| 3 |
539104427 |
SPACER .70" Price: $7.65 |
| 3 |
703-3208 |
Track Ass'y., Seat w/o Latch Price: $64.46 |
| 3 |
94-3197 |
O-RING Price: $2.63 |
| 4 |
539105308 |
KEY 1/4 SQ X 1.0 Price: $3.99 |
| 4 |
703-3681A |
SEAT PIVOT BRACKET Not Available Price: |
| 4 |
94-3195 |
GASKET-PUMP, WATER Price: $10.32 |
| 5 |
539104429 |
PULLEY Price: $45.99 |
| 5 |
703-3711 |
SEAT BELT MOUNTING BRACKET Not Available Price: |
| 5 |
94-3194 |
WATER PUMP ASSY Price: $202.24 |
| 6 |
539104428 |
SPACER .508" Price: $7.11 |
| 6 |
710-0376 |
Screw, Hex Cap, 5/16-18 x 1.0 GR5 Price: $3.66 |
| 6 |
76-5500 |
CAPSCREW-HH Price: $15.10 |
| 7 |
539104515 |
CLUTCH Price: $279.99 |
| 7 |
710-0451 |
Screw, Carriage, 5/16-18 x .75 Price: $3.53 |
| 7 |
94-3196 |
DISCONTINUED Price: Call Us |
| 8 |
596238901 |
Washers This part replaces 539990427. Price: $2.99 |
| 8 |
710-0528 |
Screw, Hex Cap, 5/16-18 x 1.25 GR5 Price: $3.90 |
| 9 |
539991120 |
BOLT 7/16F X 2 1/2 Price: $5.99 |
| 9 |
710-0759 |
SCREW 5/16-18 x .625 GR5 Not Available Price: |
| 10 |
539103251 |
CLUTCH TIE DOWN Price: $34.99 |
| 10 |
710-3250 |
SCREW 5/16-18X1.5 Not Available Price: |
| 11 |
539105047 |
MUFFLER GUARD, PAINT Price: $22.44 |
| 11 |
712-3004A |
HEX FLANGE NUT Price: $3.49 |
| 12 |
539104415 |
KAW PIGTAIL Price: $27.99 |
| 12 |
539104416 |
KOH PIGTAIL Price: $34.99 |
| 12 |
925-3167 |
Switch, Snap Mount Normally Open (Black) This part replaces 725-3167. Price: $13.53 |
| 13 |
539104956 |
MUFFLER KOH Price: $271.99 |
| 13 |
539104957 |
MUFFLER KAW. Price: $242.60 |
| 13 |
732-3080A |
Spring, Compression, 1.28 x 3.5 Price: $12.91 |
| 14 |
539105048 |
MUFFLER MT, PAINT Price: $25.06 |
| 14 |
738-0140 |
Screw, Shoulder, .435 x .178-5/16-18 Price: $4.93 |
| 15 |
539105025 |
ENGINE MOUNT Price: $19.99 |
| 15 |
750-0258 |
Spacer, .315 x .750 x .375 Price: $10.00 |
| 16 |
539105031 |
ENGINE MOUNT Price: $29.99 |
| 16 |
957-04006 |
EXTRA HIGH BACK SEAT Not Available This part replaces 757-3012. Price: |
| 17 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 539976934. Price: $3.99 |
| 18 |
596134901 |
GSPH This part replaces 539990692. Price: $2.99 |
| 19 |
539103433 |
HCS 1/2C X 3 1/4 Price: $5.99 |
| 20 |
596135601 |
GSPW NUTS This part replaces 539101331. Price: $3.99 |
| 21 |
539104959 |
ISOLATOR WASHER Price: $12.99 |
| 22 |
539104958 |
ISOLATORS Price: $32.99 |
| 23 |
539102757 |
CABLE POSITIVE Price: $7.99 |
| 24 |
539101714 |
SOLENOID Price: $22.99 |
| 25 |
596582501 |
Bolts This part replaces 539990072. Price: $2.99 |
| 26 |
539990761 |
NUT 1/4C CENTER LOCK Price: $2.99 |
| 27 |
539105034 |
ISOLATOR SPACER Price: $11.99 |
| 29 |
539105073 |
PIPE 3/8 NPT 1-1/2 Price: $4.99 |
| 777D01782 |
LABEL-MADE |
IN USA Not Available Price: 777D01782 |
| 777D04541 |
LABEL-SEAT |
BACK Not Available Price: 777D04541 |
