| Ref | Part Number | Description |
|---|
| 1 |
104-4620 |
SEAT This part replaces 66-5400. Price: $273.15 |
| 1 |
532429667 |
KIT.CONTROL.SPEED.SELECTOR.SNO This part replaces 532198474. Price: $74.99 |
| 2 |
817501010 |
SCREW #10-24 X 5/8 Price: $4.99 |
| 2 |
92-6534 |
ORDER COMPLETE SEAT This part replaces 67-9560. Price: Call Us |
| 3 |
532197763 |
DRIVE PLATE WELDMENT Price: $54.99 |
| 3 |
75-4370-03 |
BRACKET-SEAT This part replaces 75-4370. Price: $20.93 |
| 4 |
3296-54 |
NUT-LOCK Price: $3.59 |
| 4 |
532197764 |
SHAFT.HEX.SHORT Price: $11.99 |
| 5 |
597412801 |
BEARING HOUSING ASSY TRUNNION This part replaces 532175344. Price: $29.99 |
| 5 |
75-6330 |
DISCONTINUED Price: Call Us |
| 6 |
583607301 |
RING.RETAINING. This part replaces 812000012. Price: $2.99 |
| 6 |
99-6063 |
SENSOR ASM, SEAT This part replaces 75-6320. Price: $141.95 |
| 7 |
3250-29 |
SCREW-PPH Price: $0.25 |
| 7 |
596039401 |
BOLT ROUND HEAD SQUARE NECK BO This part replaces 872270505. Price: $2.99 |
| 8 |
532188909 |
BEARING FLANGE Price: $24.99 |
| 8 |
75-4360-03 |
BRACKET-SUSPENSION, SEAT This part replaces 75-4360. Price: $17.81 |
| 9 |
532182504 |
SPACER, BEARING Price: $5.99 |
| 10 |
532184077 |
LEVER.SHIFTER.PLATE.BLACK Price: $9.99 |
| 10 |
74-0720 |
TUBE-MANUAL Price: $22.99 |
| 11 |
3256-2 |
WASHER-FLAT Price: $0.39 |
| 11 |
532175349 |
BRACKET, SHIFTER SUPPORT This part replaces 532184076. Price: $4.99 |
| 12 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 12 |
532178695 |
PIN, PIVOT LEVER Price: $4.99 |
| 13 |
322-3 |
SCREW-HH Price: $0.79 |
| 13 |
532085179 |
RETAINER CLIP PM Price: $3.99 |
| 14 |
596437001 |
Screws This part replaces 817490408. Price: $2.99 |
| 14 |
75-3400 |
SHAFT-PIVOT, SEAT Price: $21.81 |
| 15 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 15 |
75-3880 |
DISCONTINUED Price: Call Us |
| 16 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 16 |
532184075 |
PLATE.DRIVE.MOUNTING.BLACK Price: $14.99 |
| 17 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 17 |
596039201 |
GSPW Hardware This part replaces 532155377. Price: $2.99 |
| 18 |
532191080 |
PULLEY.TRACTION.7.75 Price: $49.99 |
| 18 |
75-3680-03 |
ROD-SEAT This part replaces 75-3680. Price: $38.90 |
| 19 |
32121-38 |
PIN-ROLL Price: $0.53 |
| 19 |
819111507 |
WASHER, FLAT Price: $4.99 |
| 20 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 20 |
75-1350 |
THROTTLE CABLE Price: $15.76 |
| 21 |
63-6760 |
FITTING-CONNECTOR This part replaces 67-5110. Price: $61.52 |
| 21 |
874950512 |
SCREW 5/16-18 X .750 Price: $3.99 |
| 22 |
532422111 |
ARM.IDLER.BRAKE.BLACK Price: $12.99 |
| 22 |
67-5100 |
SLEEVE-CONNECTOR Price: $4.11 |
| 23 |
594095301 |
Pulleys This part replaces 532180523. Price: $9.99 |
| 23 |
63-6760 |
FITTING-CONNECTOR This part replaces 67-5120. Price: $61.52 |
| 24 |
532422762 |
KIT.SERVCE.IDLER.PULLEY This part replaces 532184074. Price: $79.99 |
| 24 |
63-6760 |
FITTING-CONNECTOR This part replaces 67-5130. Price: $61.52 |
| 25 |
532175330 |
PIN, IDLER PIVOT Price: $4.99 |
| 25 |
63-6760 |
FITTING-CONNECTOR This part replaces 67-5140. Price: $61.52 |
| 26 |
596582201 |
Bolts This part replaces 874780524. Price: $2.99 |
| 26 |
63-6760 |
FITTING-CONNECTOR This part replaces 67-5150. Price: $61.52 |
| 27 |
585802801 |
NUT.HEX.FL 5/16-18 TOP LCK BLK This part replaces 532166785. Price: $4.99 |
| 27 |
75-3300 |
DISCONTINUED Price: Call Us |
| 28 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 28 |
532414557 |
SPRING.TRACTION.IDLER This part replaces 532181044. Price: $4.99 |
| 29 |
585238401 |
ARM.ASM.TRACTION.IDLER. This part replaces 532184804. Price: $27.99 |
| 29 |
63-6760 |
FITTING-CONNECTOR Price: $61.52 |
| 30 |
3-6657 |
CLIP-SKID Price: $22.64 |
| 30 |
532180522 |
PULLEY.W/SPACER.2.25 Price: $22.99 |
| 31 |
595305701 |
Screws This part replaces 874780520. Price: $3.99 |
| 31 |
66-2920 |
WASHER-FRICTION Price: $2.58 |
| 32 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 32 |
532059289 |
STEEL WASHER Price: $3.99 |
| 33 |
873930500 |
NUT.CENTERLOCK.5/16- Price: $3.99 |
| 34 |
532851084 |
SCREW, HEX HD 3/8-24 X 1-3/8 Price: $2.50 |
| 34 |
75-3430-03 |
LEVER-THROTTLE This part replaces 75-3430. Price: $29.18 |
| 35 |
233-42 |
KNOB Price: $12.88 |
| 35 |
596238701 |
Washers This part replaces 532850263. Price: $3.99 |
| 36 |
121-4600 |
NUT-HEX This part replaces 3296-59. Price: $0.78 |
| 36 |
532400026 |
WASHER, FLAT 3/8 Price: $7.99 |
| 37 |
595926601 |
PULLEY This part replaces 532180478. Price: $27.99 |
| 37 |
75-5270 |
SPACER-KNOB, SEAT Price: $4.61 |
| 38 |
532409475 |
SPACER.ENGINE.PULLEY Price: $7.99 |
| 38 |
75-5260 |
DISCONTINUED Price: Call Us |
| 39 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 39 |
532179095 |
SPRING.RETURN Price: $3.99 |
| 40 |
532155452 |
BELT.GUIDE.RH Price: $4.99 |
| 40 |
75-0760 |
DISCONTINUED Price: Call Us |
| 41 |
237-141 |
GROMMET-RUBBER Price: $2.39 |
| 41 |
874610516 |
SCREW Price: $3.99 |
| 42 |
2412-133 |
CLAMP-R Price: $3.19 |
| 42 |
587343701 |
BUSHING.BRAKE.ARM This part replaces 532175331. Price: $5.99 |
| 43 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 811050500. Price: $2.99 |
| 44 |
67-9570 |
Trim Price: Call Us |
| 45 |
92-6533 |
SEAT CUSHION KIT This part replaces 67-9550. Price: $290.43 |
| 46 |
321-4 |
SCREW-HH Price: $0.99 |
| 47 |
323-4 |
SCREW-HH Price: $1.02 |
| 49 |
75-6830 |
DISCONTINUED Price: Call Us |
| 50 |
2412-93 |
CLAMP-R Price: $1.02 |
| 51 |
52-2860 |
WASHER Price: $0.84 |
