Chain Brake Assembly
Parts (59)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 115-8294-0P | TUBE-LONG This part replaces 115-8294-03. Price: $233.63 |
| 1 | 507430848 | Thrust Washer Price: $1.99 |
| 2 | 114-5407 | SHAFT-LONG, REAR ROLLER Price: $84.05 |
| 2 | 952004746 | Rim Sprocket (3/8 7 tooth) Price: Call Us |
| 3 | 114-3717 | SEAL-OIL Price: $2.77 |
| 3 | 530032049 | Bearing Price: $8.99 |
| 4 | 112-5290 | BEARING-STEEL, STAINLESS Price: $12.64 |
| 5 | 112-7494 | SEAL Price: $6.37 |
| 5 | 507433102 | Clutch Shoe Price: $7.99 |
| 6 | 114-5411 | NUT-LOCK, BEARING Price: $24.46 |
| 6 | 507433133 | Clutch Driver Price: $17.99 |
| 7 | 302-5 | FITTING-GREASE Price: $0.59 |
| 7 | 507430800 | Nut Price: $1.99 |
| 8 | 507431200 | Clutch Spring Price: $2.99 |
| 10 | 507431675 | Screw Price: $0.99 |
| 11 | 507431673 | Screw Price: $0.99 |
| 12 | 507476582 | Cover Price: $3.99 |
| 13 | 50747648618 | Kickback Guard Assy. Price: Call Us |
| 14 | 507431697 | Screw Price: $0.44 |
| 15 | 507430930 | Washer Price: $2.99 |
| 16 | 507433529 | Bushing Price: $4.99 |
| 17 | 507431036 | Shoulder Bolt Price: $4.99 |
| 18 | 507433185 | Spring Price: $14.99 |
| 19 | 507431038 | Locking Plate Price: $1.99 |
| 20 | 507476284 | Band Ass'y. Price: $16.24 |
| 21 | 507430878 | Washer Price: $1.99 |
| 22 | 507433532 | Washer Price: $1.99 |
| 23 | 507432613 | Screw Price: $2.99 |
| 24 | 507431636 | Retaining Ring Price: $0.24 |
| 25 | 507425672 | Pin Price: $3.99 |
| 26 | 507431698 | Nut Price: $3.33 |
| 27 | 507433036 | Strut Nut Price: $1.99 |
| 28 | 5074762741 | Clutch Cover & Tension Price: Call Us |
| 30 | 507433109 | Guide Plate-Outer Price: $6.99 |
| 31 | 507429266 | Terminal Screw Price: $1.99 |
| 32 | 507432686 | Guide Plate-Inner Price: $2.99 |
| 33 | 507431642 | Screw Price: $1.99 |
| 34 | 507431596 | Dirt Shield Price: $1.20 |
| 35 | 507431669 | Screw Price: $1.99 |
| 36 | 507476534 | Oil Pump Ass'y. Price: $37.99 |
| 37 | 507430227 | Hose Price: $5.99 |
| 38 | 507474959 | Oil Pickup Ass'y. Price: $2.24 |
| 40 | 507430231 | Wire Worm Price: $3.99 |
| 41 | 507430228 | Gasket Price: $1.48 |
| 42 | 507430229 | Seal Price: $0.99 |
| 43 | 507431359 | O-Ring Price: $1.99 |
| 44 | 507430385 | Adjusting Screw Price: $3.99 |
| 45 | 507474932 | Plunger Ass'y. Price: $0.28 |
| 46 | 507430880 | Gear Price: $0.72 |
| 47 | 507431221 | Plunger Spring Price: $5.12 |
| 48 | 507433184 | Screw Price: $0.99 |
| 49 | 507431706 | Washer Price: $2.99 |
| 50 | 114-5430 | ROLLER REBUILD KIT Price: $99.53 |
| 50 | 50747620018 | Front Handle Kit Price: Call Us |
| 51 | 507431687 | Screw Price: $0.99 |
| 52 | 507431247 | Screwdriver Price: $1.40 |
| 53 | 545006011 | SCRENCH This part replaces 530031146. Price: $6.99 |
| 54 | 507431699 | Roll Pin Price: $1.99 |
| 55 | 507476193 | Front Handle Full Wrap Price: $32.44 |
