| Ref | Part Number | Description |
|---|
| 1 |
532132671 |
IGNITION HARNESS Price: $139.99 |
| 1 |
93-2085-01 |
ROD ASM This part replaces 93-2085. Price: $134.61 |
| 2 |
532002274 |
SCREW SELF TAPPING, LARGE Price: $3.33 |
| 2 |
74-9110 |
PAD-PEDAL, REVERSE Price: $13.49 |
| 3 |
532068003 |
DETENT, BALL This part replaces 532134400. Price: $2.99 |
| 3 |
74-9100 |
PAD-PEDAL, FORWARD Price: $27.08 |
| 4 |
49-6440-03 |
PEDAL-FORWARD This part replaces 49-6440. Price: $84.90 |
| 4 |
532105904 |
SPRING, DETENT Price: $3.33 |
| 5 |
32121-45 |
PIN-SPRING Price: $0.27 |
| 5 |
532105905 |
SCREW, SET Price: $3.33 |
| 6 |
33124-020 |
SCREW-CARR Price: $0.88 |
| 6 |
532134788 |
SHIFTER KIT This part replaces 532138235. Price: $119.99 |
| 7 |
2411-38 |
JOINT-BALL Price: $21.96 |
| 7 |
532134399 |
BOOT, SHIFTER Price: $3.33 |
| 8 |
532120951 |
PUCK, FRICTION Price: $13.99 |
| 8 |
93-2142 |
DISCONTINUED Price: Call Us |
| 9 |
105-9750-01 |
PLATE-FLOOR This part replaces 94-6399. Price: $194.85 |
| 9 |
532148266 |
Bearing, Flange Price: Call Us |
| 10 |
32144-14 |
SCREW-HWHTF Price: $4.29 |
| 10 |
532002225 |
Ring, Retaining Price: Call Us |
| 11 |
532134793 |
SHIM.KIT.DANA.4689 Price: $11.99 |
| 11 |
94-1371 |
SPACER Price: $14.81 |
| 12 |
532143679 |
PLUG PLASTIC Price: $2.99 |
| 12 |
94-1383 |
PEDAL-PIVOT Price: $229.74 |
| 13 |
256-311 |
BUSHING-SPLIT Price: $13.37 |
| 13 |
532120415 |
WASHER.PLAIN..632X1.38X.046 Price: $2.99 |
| 14 |
33115-090 |
SCREW-HH Price: $13.76 |
| 14 |
532142674 |
KEY.WOODRUFF.DANA Price: $3.99 |
| 15 |
33023-00 |
NUT-LOCK Price: $0.25 |
| 15 |
532106846 |
ASSY, KIT INPUT SHAFT Price: $3.33 |
| 16 |
107-2550 |
CABLE-CONTROL, TRACTION This part replaces 93-2099. Price: $194.40 |
| 16 |
532167148 |
INPUT.SHAFT.BEVEL.6205 This part replaces 532106095. Price: $192.99 |
| 17 |
33024-00 |
NUT-LOCK, NI Price: $0.75 |
| 17 |
532105909 |
RING RETAINING Price: $3.33 |
| 18 |
17-9420 |
SCREW-HANDLE Price: $3.49 |
| 18 |
532105910 |
CHAIN 24 PITCH LT Price: $38.99 |
| 19 |
532105911 |
BEARING, FLANGE LT Price: $8.60 |
| 19 |
94-1373 |
BRACKET-LOCK Price: $24.82 |
| 20 |
532142675 |
GEAR SPUR 14 TTH Price: $12.99 |
| 20 |
94-1372 |
BRACKET-MOW Price: $18.44 |
| 21 |
532148267 |
Collar, Clutch Price: Call Us |
| 21 |
94-1375 |
TRUNNION-BRACKET, LOCK Price: $23.45 |
| 22 |
532138236 |
ASSEMBLY KIT, CLUTCH KEYS This part replaces 532138237. Price: $69.99 |
| 22 |
94-1374 |
TRUNNION-BRACKET, MOW Price: $14.18 |
| 23 |
532148268 |
BEARING.FLANGE (DANA 5511) Price: $3.99 |
| 23 |
94-1386 |
SHAFT-PEDAL Price: $44.42 |
| 24 |
532143673 |
SHAFT INTER 5404 This part replaces 532142676. Price: $211.99 |
| 24 |
94-1304 |
CABLE-LOCK, NEUTRAL Price: $153.45 |
| 25 |
32128-20 |
NUT-HF Price: $0.99 |
| 25 |
532002244 |
KEY, WOODRUFF, #61 Price: $3.33 |
| 26 |
532105916 |
RING, RETAINING LT Price: $2.99 |
| 26 |
94-3489 |
SCREW-HH Price: $1.70 |
| 27 |
140-6108 |
PIN-FLAG, NEUTRAL LOCK This part replaces 94-1300. Price: $31.21 |
| 27 |
532120470 |
SPROCKET 18T Price: $25.54 |
| 28 |
3256-1 |
WASHER-FLAT Price: $0.39 |
| 28 |
532110070 |
SPACER Price: $3.33 |
| 29 |
2411-34 |
JOINT-BALL Price: $29.99 |
| 29 |
532142677 |
GEAR, SPUR 37 TEETH Price: $3.33 |
| 30 |
3296-13 |
NUT-LOCK, NI Price: $0.34 |
| 30 |
532142681 |
GEAR, SPUR 35 TEETH Price: $3.33 |
| 31 |
583670301 |
GEAR SPUR 30T This part replaces 532124644. Price: $54.99 |
| 31 |
93-2092 |
CLAMP-CABLE Price: $3.46 |
| 32 |
33114-016 |
SCREW-HH Price: $0.27 |
| 32 |
532108980 |
GEAR, SPUR 25 TEETH Price: $3.33 |
| 33 |
33025-00 |
NUT-LOCK, NI Price: $0.54 |
| 33 |
532120406 |
GEAR, SPUR 22 TEETH Price: $3.33 |
| 34 |
532134796 |
GEAR Price: $79.99 |
| 34 |
93-2279 |
CLAMP-CABLE Price: $7.12 |
| 35 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 35 |
532105925 |
WASHER, PLAIN .640 X 1.37X.061 Price: $3.33 |
| 36 |
33115-016 |
SCREW-HH Price: $0.75 |
| 36 |
532002232 |
WASHER 025 Price: $2.99 |
| 37 |
33014-00 |
NUT-HEX Price: $0.25 |
| 37 |
532108978 |
SPACER Price: $5.53 |
| 38 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 38 |
532110079 |
ASSM GEAR COMB T NLA Price: $90.68 |
| 39 |
3220-1 |
NUT-JAM Price: $0.99 |
| 39 |
532124639 |
SHAFT IDLER Price: $29.99 |
| 40 |
532120472 |
SPACER, .635 X .875 X .755 Price: $3.33 |
| 41 |
532105928 |
SPROCKET 9T LT Price: $17.99 |
| 42 |
532106605 |
GEAR, SPUR 42T YT Price: $81.63 |
| 43 |
532134394 |
SHIM Price: $14.99 |
| 44 |
532120473 |
SHAFT, DRIVE Price: $3.33 |
| 45 |
532106596 |
SCREW, SELF TAPPING LARGE Price: $3.33 |
| 46 |
532142678 |
GEAR SPUR 12 TEETH Price: $3.33 |
| 47 |
532120407 |
GEAR, SPUR 20 TEETH Price: $3.33 |
| 48 |
532106589 |
GEAR, SPUR 25 TEETH Price: $3.33 |
| 49 |
532120408 |
GEAR, SPUR 28 TEETH Price: $3.33 |
| 50 |
532105937 |
GEAR, SPUR 31 TEETH Price: $3.33 |
| 51 |
532002226 |
WASHER, PLAIN .632 X1.00X.060 Price: $3.33 |
| 52 |
532134401 |
NEOPRENE.WASHER.DANA Price: $5.99 |
| 53 |
532002264 |
WASHER, PLAIN .758 X 1.25X.031 Price: $3.33 |
| 54 |
532154658 |
KIT.AXLE.LH.4997.DANA This part replaces 532120474. Price: $134.99 |
| 55 |
532169651 |
GEAR KIT This part replaces 532110081. Price: $45.99 |
| 56 |
532105941 |
RING, RETAINING Price: $3.33 |
| 57 |
532110071 |
GEAR LT Price: $159.99 |
| 58 |
532120952 |
SHAFT, CROSS Price: $3.33 |
| 59 |
532169651 |
GEAR KIT This part replaces 532110082. Price: $45.99 |
| 60 |
532120475 |
Axle, R.H. Price: Call Us |
| 61 |
532142680 |
LOWER HOUSING Price: $171.99 |
| 62 |
532120961 |
PUCK, FRICTION Price: $13.99 |
| 63 |
532007294 |
BRAKE DISC T Price: $29.98 |
| 64 |
532108989 |
SPACER LT Price: $3.99 |
| 65 |
532164670 |
JAW BRAKE This part replaces 532120953. Price: $55.99 |
| 66 |
532120954 |
PIN Price: $4.99 |
| 67 |
532134799 |
SCREW, SELF TAPPING, LARGE Price: $3.33 |
| 68 |
532108992 |
LEVER ACTUATOR This part replaces 532138244. Price: $24.99 |
| 69 |
532108996 |
WASHER, PLAIN .321 X 1.00X.055 Price: $3.33 |
| 70 |
532120956 |
BRACKET, ANTI ROTATION Price: $3.33 |
| 71 |
873610500 |
This part replaces 873810500. Price: $2.15 |
| 72 |
532148269 |
Seal, Oil Price: Call Us |
