| Ref | Part Number | Description |
|---|
| 1 |
73900500 |
Nut, Flange 5/16-18 Price: Call Us |
| 1 |
KH-25-237-31-S |
Hose Clamp (KM) This part replaces KH-25-237-14-S. Price: $4.42 |
| 2 |
161415 |
Shield, Side, Outer L. H. Price: Call Us |
| 2 |
KH-47-154-01-S |
Cable Clip Price: $4.87 |
| 3 |
8393J |
Pin, Stake, Depth Price: Call Us |
| 3 |
KH-25-050-22-S1 |
Fuel Filter Price: $18.01 |
| 4 |
12000036 |
Ring, Klip Price: Call Us |
| 4 |
KH-25-111-81-S |
Low Permeation Fuel Hose, 24" This part replaces KH-25-111-34-S. Price: $17.20 |
| 5 |
72140506 |
Bolt, Carriage 5/16-18 x 3/4 Gr 5 Price: Call Us |
| 5 |
KH-20-332-01-S |
INSERT-INTAKE PORT Not Available Price: |
| 6 |
8394J |
Spring Price: Call Us |
| 6 |
KH-24-393-16 |
Fuel Pump Price: $34.85 |
| 7 |
8392J |
Bracket, Latch Price: Call Us |
| 7 |
KH-20-265-09-S |
Heat Deflector Kit (Inc. 5, 12, 15-16) Price: $28.58 |
| 8 |
109230X |
Spring, Depth Stake Price: Call Us |
| 8 |
KH-X-22-11 |
Internal Tooth Lock Washer, 1/4 Price: $2.13 |
| 9 |
102326X505 |
Shield, Tine Price: Call Us |
| 9 |
KH-M-651020-S |
Flange Screw, M6 x 1.0 x 20 Price: $2.23 |
| 10 |
72140508 |
Bolt, Carriage 5/16-18 x 1 Price: Call Us |
| 10 |
KH-20-853-91-S |
CARBURETOR KIT Not Available This part replaces KH-20-853-72-S. Price: |
| 11 |
73220500 |
Nut, Hex 5/16-18 Price: Call Us |
| 11 |
KH-12-041-01 |
Carburetor Gasket Price: $2.29 |
| 12 |
10040500 |
Washer, Lock 5/16 Price: Call Us |
| 12 |
KH-12-041-02 |
Air Cleaner Base Gasket Price: $2.41 |
| 13 |
72110510 |
Bolt, Carriage 5/16-18 x 1-1/4 Price: Call Us |
| 13 |
KH-20-072-10-S |
Stud This part replaces KH-20-072-05-S. Price: $4.58 |
| 14 |
124343X |
Bracket, Shield Tine Price: Call Us |
| 14 |
KH-M-641060-S |
Flange Nut, M6 x 1.0 Price: $4.01 |
| 15 |
161414 |
Shield, Side, Outer R.H. Price: Call Us |
| 15 |
KH-20-072-09-S |
STUD-CARB MTG 85. Not Available This part replaces KH-20-072-07-S. Price: |
| 16 |
73900400 |
Nut, Hex Flange 1/4-20 UNC Price: Call Us |
| 16 |
KH-20-041-18-S |
Heat Deflector Gasket Price: $6.72 |
| 18 |
72040410 |
Bolt, Carriage 1/4-20 x 1-1/4 Gr. 5 Price: Call Us |
| 19 |
102701X |
Grip Price: Call Us |
| 20 |
73220600 |
Nut, Hex 3/8-16 Price: Call Us |
| 21 |
102156X |
Stake, Depth Price: Call Us |
| 22 |
74930632 |
Bolt, Hex 3/8-16 x 2 Price: Call Us |
| 23 |
4440J |
Hinge Price: Call Us |
| 24 |
72140404 |
Bolt, Carriage 1/4-20 x 1/2 Gr. 5 Price: Call Us |
| 25 |
6712 |
J Cap, Vinyl Price: Call Us 6712 J |
| 26 |
109227X |
Pad, Idler Price: Call Us |
| 27 |
102695X505 |
Shield, Leveling Price: Call Us |
| 28 |
120588X |
Pin, Hinge Price: Call Us |
| 29 |
104085X505 |
Shield, Side Price: Call Us |
| 32 |
73220400 |
Nut Fin Hex 1/4-20 UNC Price: Call Us |
