| Ref | Part Number | Description |
|---|
| 1 |
530047721 |
Bulb-Purge Price: $3.99 |
| 1 |
66-6370 |
LIFT ARM ASM This part replaces 21-3100. Price: $430.43 |
| 2 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 2 |
530071717 |
Kit-Choke Lever Price: $7.99 |
| 3 |
32136-2 |
NUT-SHH Price: $3.55 |
| 3 |
530015843 |
Screw-tank Price: $1.99 |
| 4 |
21-3020-01 |
MOUNT-BALLJOINT, RH This part replaces 21-3020. Price: $178.87 |
| 4 |
530057973 |
Assy - Fuel Cap w/retainer This part replaces 530049386. Price: $7.99 |
| 5 |
21-1830 |
SPRING-EXTENSION Price: $34.62 |
| 5 |
530095646 |
Assy-Fuel pickup Price: $2.99 |
| 6 |
3256-25 |
WASHER-FLAT Price: $0.25 |
| 6 |
530069247 |
Kit-Carb./Purge Fuel line Price: $3.99 |
| 7 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 7 |
530069216 |
Kit-Tank/Purge Fuel line Price: $3.99 |
| 8 |
3217-8 |
NUT-HEX Price: $1.34 |
| 8 |
530015775 |
Screw Price: $1.99 |
| 9 |
530054935 |
Cover-Air box Price: $1.99 |
| 9 |
66-7150 |
ARM-PUSH, RH This part replaces 21-2910. Price: $536.26 |
| 10 |
3272-24 |
PIN-COTTER Price: $0.54 |
| 10 |
530054946 |
Filter-Air Price: $1.99 |
| 11 |
24-9510 |
PIN Price: $77.49 |
| 11 |
530015849 |
Screw-Carb. Price: $1.99 |
| 12 |
5-1754 |
WASHER-FLAT Price: $2.17 |
| 12 |
530054934 |
Box-Air Price: $3.99 |
| 13 |
256-126 |
BUSHING Price: $9.36 |
| 14 |
3272-33 |
PIN-COTTER Price: $0.54 |
| 15 |
23-1950-01 |
SUPPORT-REINFORCEMENT This part replaces 23-1950. Price: $69.64 |
| 16 |
324-5 |
SCREW-HH Price: $0.54 |
| 16 |
530015771 |
Screw-Crankcase Price: $1.99 |
| 17 |
3-7292 |
PIN-CLEVIS Price: $44.11 |
| 17 |
530015952 |
Screw-Shroud Price: $1.99 |
| 18 |
5-3126 |
PIN-LYNCH Price: $0.73 |
| 18 |
530058797 |
Shroud Price: $14.99 |
| 19 |
3241-7 |
SCREW-SQH This part replaces 324-12. Price: $3.39 |
| 20 |
21-3750 |
SUPPORT PLT Price: $14.42 |
| 20 |
530027593 |
Valve-Reed Price: $1.99 |
| 21 |
21-2860-01 |
PUSH ARM BRACKET ASM This part replaces 21-2860. Price: $154.46 |
| 21 |
530054596 |
Stop-Reed Price: $1.99 |
| 22 |
32121-84 |
PIN-SPIRAL Price: $1.29 |
| 22 |
545227101 |
SCREW 6-19X.437 This part replaces 530016064. Price: $1.99 |
| 23 |
21-2990 |
SHAFT-PIVOT Price: $227.21 |
| 23 |
530015875 |
Screw-Retainer Price: $1.99 |
| 24 |
3296-48 |
NUT-LOCK, NI Price: $0.37 |
| 24 |
530055492 |
Isolator-Tank Price: $1.99 |
| 25 |
302-33 |
FITTING-GREASE Price: $2.31 |
| 25 |
530054941 |
Ret.-Tank Price: $1.99 |
| 26 |
21-2960 |
ARM-PUSH, LH Price: $519.38 |
| 26 |
530054834 |
Handle-Starter Price: $1.99 |
| 27 |
21-2900-01 |
SPRING-TORSION, LH This part replaces 21-2900. Price: $566.83 |
| 27 |
530071325 |
Kit-Rope Price: $3.99 |
| 28 |
21-2890-01 |
SPRING-TORSION, RH This part replaces 21-2890. Price: $566.83 |
| 28 |
530032103 |
Bearing-Inner Price: Call Us |
| 29 |
21-3050-01 |
LH BALL JOUNT MOUNT ASM This part replaces 21-3050. Price: $153.41 |
| 29 |
530015787 |
Retainer Price: $1.99 |
| 30 |
530019158 |
Seal Price: $2.99 |
| 30 |
86-8100-01 |
BALL JOINT ASM This part replaces 21-0160. Price: $137.53 |
| 31 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 31 |
530032102 |
Bearing-Outer Price: $8.99 |
| 32 |
21-3000-01 |
NUT-JAM, PUSH ARM This part replaces 21-3000. Price: $37.02 |
| 32 |
530015789 |
Ret.-Crankshaft Price: $2.99 |
| 33 |
530028807 |
Assy-Crankshaft Price: $19.99 |
| 33 |
61-3610 |
WARNING DECAL This part replaces 36-4060. Price: $16.67 |
| 34 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 35 |
5-2942 |
SHACKLE Price: $16.99 |
| 36 |
530055524 |
Assy-Flywheel Price: $22.99 |
| 37 |
530016030 |
Washer Price: $1.99 |
| 38 |
530055620 |
Spacer Price: $4.99 |
| 39 |
530015775 |
Screw-Baffle Price: $1.99 |
| 40 |
545115201 |
Plate-Baffle This part replaces 530054939. Price: $2.99 |
| 41 |
530016391 |
Screw-Rope Price: $1.99 |
| 43 |
545008011 |
KIT STARTER SPRING This part replaces 530042086. Price: $5.99 |
| 44 |
530019182 |
Grommet Price: $1.99 |
| 45 |
530016386 |
SCREW This part replaces 530015810. Price: $5.99 |
| 46 |
530055248 |
Assy.-Fan Housing Price: $17.99 |
| 47 |
530094189 |
Washer-Clutch Price: $2.99 |
| 48 |
530055122 |
Assy-Clutch Price: $8.99 |
| 49 |
530028799 |
Assy-Clutch Drum Price: $4.48 |
| 50 |
530010960 |
Assy-Conn. Rod Price: $14.99 |
| 51 |
530015162 |
Ret.-Piston pin Price: $1.99 |
| 52 |
530012595 |
Ring-Piston Price: $4.99 |
| 55 |
530058846 |
Assy-Leadwire Price: $4.99 |
| 56 |
530069310 |
Kit-Muffler Price: $9.99 |
| 57 |
530058957 |
Shield Price: $3.99 |
| 58 |
530036409 |
Spring-Muffler Price: $1.99 |
| 59 |
530012490 |
Cylinder Price: $27.99 |
| 61 |
530001624 |
Bolt-Cyl. 1/4-20' Price: $1.99 |
| 62 |
530039218 |
Module-Ignition Price: $32.99 |
| 63 |
530016357 |
Screw-Module Price: $1.99 |
