| Ref | Part Number | Description |
|---|
| 1 |
106-8085 |
SUSPENSION ASM Price: $723.03 |
| 1 |
159944X428 |
Wheel Steering Price: Call Us |
| 2 |
172393 |
Axle Asm Cast Iron LT Price: Call Us |
| 2 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 3 |
106-1031 |
TENSION ADJUSTER KNOB ASM Price: $68.93 |
| 3 |
169840 |
Spindle Asm LH Price: Call Us |
| 4 |
169839 |
Spindle Asm RH Price: Call Us |
| 5 |
6266H |
Bearing Race Thrust Harden Price: Call Us |
| 6 |
121748X |
Washer 25/32 X 1-5/8 X 16 Ga Price: Call Us |
| 6 |
66-9290 |
SPACER-SUSPENSION Price: $3.60 |
| 7 |
76-2940 |
BUMPER Price: $9.73 |
| 8 |
108-6703 |
ADJUSTER-SEAT This part replaces 66-8530. Price: $183.47 |
| 8 |
12000029 |
Ring Klip #t5304-75 Price: Call Us |
| 9 |
603773 |
LOCKNUT This part replaces 32153-2. Price: $2.09 |
| 10 |
108-6702 |
ADJUSTER-SEAT, W/HANDLE This part replaces 66-8510. Price: $239.09 |
| 10 |
175121 |
Link Drag Price: Call Us |
| 11 |
10040600 |
Washer, Lock Hvy. Hlcl. Spr. 3/8 Price: Call Us |
| 11 |
75-3570 |
TIP-VINYL Price: $2.48 |
| 12 |
73940800 |
Nut Hex Jam Toplock 1/2-20 UNF Price: Call Us |
| 13 |
136518 |
Spacer Brg. Axle Front Price: Call Us |
| 13 |
32128-25 |
NUT-HF Price: $3.19 |
| 15 |
145212 |
Nut Hex Flange Lock Price: Call Us |
| 15 |
93-3163 |
SPRING Price: $26.01 |
| 17 |
180641 |
Shaft Asm. Steering Price: Call Us |
| 29 |
17060612 |
Screw 3/8-16x.75 Price: Call Us |
| 32 |
171888 |
Rod Tie Price: Call Us |
| 33 |
19111216 |
Washer 11/32 x 3/4 x 16 Ga. Price: Call Us |
| 34 |
10040500 |
Washer Lock Hvy Hlcl Spr 5/16 Price: Call Us |
| 35 |
73540500 |
Crownlock Nut 5/16-24 Price: Call Us |
| 36 |
155099 |
Bushing Strg Price: Call Us |
| 37 |
152927 |
Screw Price: Call Us |
| 38 |
159946X428 |
Insert Cap Strg Wh Au Price: Call Us |
| 39 |
19182411 |
Washer 9/16 ID x 1 1/2 OD.11 Ga Price: Call Us |
| 40 |
7810H |
Lock nut Price: Call Us |
| 41 |
159945 |
Adaptor Wheel Strg Price: Call Us |
| 42 |
145054X428 |
Boot Steering Dash Price: Call Us |
| 43 |
121749X |
Washer 25/32 X 1 1/4 X 16 Ga Price: Call Us |
| 44 |
180640 |
Extension Steering Shaft LR/LT Price: Call Us |
| 46 |
121232X |
Cap Spindle Fr Top Blk Price: Call Us |
| 51 |
73540400 |
Nut Crownlock 1/4-28 Price: Call Us |
| 54 |
71130420 |
Bolt Hex 1/4-28 UNF x 1-1/4 Ga 8 Price: Call Us |
| 65 |
160367 |
Brace Axle Price: Call Us |
| 67 |
72140618 |
Bolt Rdhd Sq 3/8-16 Unc x 2-1/4 Price: Call Us |
| 68 |
169827 |
Axle, Brace Price: Call Us |
| 71 |
175146 |
Steering Asm. Price: Call Us |
| 82 |
169835 |
Bracket Susp. Chassis Front Price: Call Us |
| 87 |
173966 |
Washer Flat .781 x 1-1/2 x .14 Price: Call Us |
| 88 |
175118 |
Bolt Shoulder 7/16-20 Unc Price: Call Us |
