| Ref | Part Number | Description |
|---|
| 1 |
28-0650 |
SHAFT-AXLE, FLANGED Price: $1,130.23 |
| 2 |
530042088 |
Muffler Spring Price: $1.99 |
| 2 |
99-6969 |
SEAL-OIL, WHEEL END This part replaces 21-8330. Price: $14.71 |
| 3 |
21-8180 |
BEARING ASM Price: $65.11 |
| 3 |
530015953 |
Screw-Cylinder Price: $1.99 |
| 4 |
24-9180 |
STRUT AND LEVER ASM Price: $86.76 |
| 4 |
952030249 |
Spark Plug (RCJ 6Y) Price: $3.99 |
| 5 |
21-9450 |
SHIELD-DUST Price: $45.14 |
| 5 |
530012416 |
Cylinder This part replaces 530071359. Price: $17.99 |
| 6 |
21-9410 |
SEE P.B.#734A Price: Call Us |
| 6 |
530071363 |
Gasket-Cyl/Carb.(kit) Price: $5.99 |
| 7 |
21-9430 |
SPRING-RETURN, RH Price: $19.96 |
| 7 |
530055535 |
Adaptor-carb. Price: $3.99 |
| 8 |
28-0670 |
SEAL-GREASE Price: $19.74 |
| 8 |
530016014 |
Screw Price: $1.99 |
| 9 |
21-9470 |
SEE PB #747 Price: Call Us |
| 9 |
530071363 |
Gasket-Carb.(kit) Price: $5.99 |
| 10 |
21-9460 |
RETAINER-LEVER, BRAKE Price: $2.18 |
| 11 |
242-34 |
STUD-DRIVE Price: $11.61 |
| 11 |
530047914 |
Plate-Choke Mounting Price: $3.99 |
| 12 |
21-8360 |
CLIP-RETAINING Price: $1.29 |
| 12 |
530047916 |
Lever-Choke Price: $1.99 |
| 13 |
28-0680-03 |
DRUM-BRAKE This part replaces 28-0680. Price: $358.84 |
| 13 |
530015254 |
Washer Price: $1.99 |
| 14 |
21-9440 |
SPRING-SCREW, ADJUSTING Price: $11.92 |
| 14 |
530016353 |
Screw Price: $1.99 |
| 15 |
21-9390 |
SOCKET-SCREW, ADJUSTING Price: $5.56 |
| 15 |
530016141 |
Screw Price: $1.99 |
| 16 |
21-9370 |
SCREW-ADJUSTING Price: $18.80 |
| 16 |
530015957 |
Screw This part replaces 530015966. Price: $1.99 |
| 17 |
21-9380 |
NUT-PIVOT Price: $26.77 |
| 17 |
530049079 |
Cover-Air Box Price: $2.99 |
| 18 |
32152-5 |
NUT-HEX Price: $0.54 |
| 18 |
530047932 |
Foam-Air Filter Price: $1.99 |
| 19 |
21-9420 |
SPRING-RETURN, LH Price: $19.96 |
| 19 |
530047908 |
Box-Air Price: $3.99 |
| 20 |
21-8320 |
REFER TO(PB#807 OR MISC COMM SB#50) Price: Call Us |
| 20 |
530015852 |
Spacer-Choke Price: $1.99 |
| 21 |
24-8840 |
RING-RETAINING, WHEEL BEARING Price: $37.15 |
| 22 |
545154001 |
RING PISTON This part replaces 530055120. Price: $1.99 |
| 23 |
530015162 |
Retainer-Piston Pin Price: $1.99 |
| 24 |
530049817 |
CONNECTING ROD ASSY This part replaces 530069945. Price: $6.99 |
| 25 |
530071363 |
Gasket-Cylinder(kit) Price: $5.99 |
| 26 |
530036145 |
Spacer-Module Price: $1.99 |
| 27 |
530055160 |
Ignition Module Price: $34.99 |
| 28 |
530015954 |
Screw Price: $1.99 |
| 29 |
530049389 |
Assy-Ground Wire Price: $1.99 |
| 30 |
530049390 |
Assy-Leadwire Price: $0.28 |
| 31 |
530016386 |
SCREW This part replaces 530015810. Price: $5.99 |
| 32 |
530071356 |
Kit-Momentary Switch Price: $4.99 |
| 33 |
530027569 |
Handle-Starter Price: $1.99 |
| 34 |
530069232 |
Kit - Rope Price: $3.99 |
| 35 |
530016080 |
Screw Price: $1.99 |
| 36 |
530027953 |
Coupling-Drive Price: $1.99 |
| 37 |
530023817 |
Spring-Starter Dog Price: $1.99 |
| 38 |
530015941 |
Retain. Ring-C'shaft Price: $1.99 |
| 39 |
530032124 |
Bearing-Outer Price: $4.99 |
| 40 |
530019179 |
Seal-C'case Price: $2.99 |
| 41 |
530015945 |
Retainer Ring-C'case Price: $1.99 |
| 42 |
530032125 |
Bearing-Inner Price: $11.99 |
| 43 |
530049233 |
Shroud Price: $3.33 |
| 44 |
530015880 |
Screw Price: $1.99 |
| 45 |
530016386 |
SCREW This part replaces 530015810. Price: $5.99 |
| 46 |
530054536 |
Guard-Muffler Price: $1.99 |
| 47 |
530036793 |
Isolator-Shroud Price: $5.99 |
| 48 |
530071363 |
O-Ring-C'case(kit) Price: $5.99 |
| 49 |
530054753 |
Assy-Crankshaft Price: $27.99 |
| 50 |
530036792 |
Isolator-Crankcase Price: $4.99 |
| 53 |
545221701 |
FLYWHEEL ASSY This part replaces 530069886. Price: $8.99 |
| 54 |
530015828 |
Washer-Flat Price: $1.99 |
| 55 |
530015957 |
Screw This part replaces 530015966. Price: $1.99 |
| 56 |
530016226 |
Retainer-Can Price: $1.99 |
| 58 |
545008011 |
KIT STARTER SPRING This part replaces 530042086. Price: $5.99 |
| 59 |
530049468 |
Assy-Fan Housing Price: $17.99 |
| 61 |
530014347 |
Assy-Fuel Cap Price: $4.99 |
| 63 |
530095646 |
Assy-Fuel Pickup Price: $2.99 |
| 64 |
530069247 |
Kit-Fuel Line Price: $3.99 |
