| Ref | Part Number | Description |
|---|
| 1 |
325-4 |
SCREW-HH Price: $0.95 |
| 1 |
603000264 |
FITTING, 1/4-28 THRD FRM GREAS Price: $3.99 |
| 2 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 2 |
603000895 |
SHOCK, COIL OVER, REAR HD Price: $499.99 |
| 3 |
3256-6 |
WASHER-FLAT Price: $0.34 |
| 3 |
603000941 |
WELDMENT, RECEIVER, REAR Price: $379.99 |
| 4 |
110-0009 |
JOINT ARM ASM This part replaces 75-3010-03. Price: $199.32 |
| 4 |
603001292 |
BOLT, FLG, M12X1.75X70 Price: $5.99 |
| 5 |
32121-122 |
PIN-ROLL Price: $2.93 |
| 5 |
603001310 |
WASHER, STRIP, SWINGARM Price: $9.99 |
| 6 |
282-4 |
SHACKLE Price: $32.98 |
| 6 |
603001311 |
BOLT FLG, M12X1.75X50 Price: $5.99 |
| 7 |
104-0028 |
GUIDE-HOSE Price: $46.21 |
| 7 |
603001312 |
NUT FLG, M12X1.75, NYLON GR 10 Price: $5.99 |
| 8 |
32121-27 |
PIN-ROLL Price: $1.56 |
| 9 |
603000944 |
BUSHING, PIVOT, URETHANE Price: $11.99 |
| 10 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 10 |
603001148 |
BUSHING, TEFLON Price: $19.99 |
| 11 |
283-6 |
PIN-CLEVIS Price: $1.70 |
| 11 |
603004117 |
SWINGARM, REAR, AWD Price: $279.99 |
| 12 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 13 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 13 |
603001597 |
PIN, SWINGARM, WELDMENT Price: $119.99 |
| 14 |
603001599 |
WASHER, M12 HARD REGULAR Price: $2.99 |
| 14 |
92-9097 |
SCREW-HS Price: $1.56 |
| 15 |
603001602 |
NUT Price: $2.99 |
| 15 |
93-0142 |
BUSHING-STRAIGHT Price: $3.21 |
| 16 |
603001606 |
BRKT, LINE, HYD, SHK MNT, DRV Price: $9.99 |
| 16 |
94-4919-03 |
BRACKET-CLAMP, HOSE Price: $19.76 |
| 17 |
322-13 |
SCREW-HH Price: $2.73 |
| 17 |
603001607 |
BRKT, LINE, HYD, SHK MNT, PASS Price: $9.99 |
| 18 |
75-4520 |
SPRING-TORSION, RH Price: $25.31 |
| 19 |
75-4530 |
SPRING-TORSION, LH Price: $25.31 |
| 22 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 23 |
100-3828 |
DISCONTINUED Price: Call Us |
| 24 |
100-3827 |
LH REAR LIFT ARM ASM Price: $720.05 |
| 25 |
256-115 |
WASHER-THRUST Price: $1.90 |
| 26 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 27 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 28 |
32136-4 |
NUT-HEX,SLOTTED This part replaces 322-12. Price: $1.56 |
| 29 |
5-1096 |
CHAIN-LIFT Price: $18.82 |
| 30 |
100-3834-03 |
ROD-PIVOT Price: $69.13 |
