| Ref | Part Number | Description |
|---|
| 1 |
94-5129 |
HOSE ASM Price: $180.03 |
| 2 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 2 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $39.99 |
| 3 |
94-5986 |
HOSE ASM Price: $110.05 |
| 6 |
94-5987 |
HOSE ASM Price: $122.18 |
| 7 |
237-30 |
O-RING Price: $2.50 |
| 8 |
340-4 |
FITTING-STRAIGHT Price: $11.58 |
| 9 |
237-79 |
O-RING Price: $5.46 |
| 9 |
596501502 |
Keepers This part replaces 532194320. Price: $9.99 |
| 10 |
340-2 |
FITTING-STRAIGHT Price: $11.43 |
| 11 |
237-22 |
O-RING Price: $2.43 |
| 11 |
583389701 |
KIT.SVC.CLUTCH.ELE.180505 This part replaces 532180505. Price: $299.99 |
| 12 |
237-42 |
O-RING Price: $2.78 |
| 12 |
532405097 |
PULLEY.ENGINE.TUFFTORQ Price: $49.99 |
| 14 |
94-5985 |
HOSE ASM Price: $174.96 |
| 15 |
340-6 |
FITTING-STRAIGHT Price: $18.79 |
| 15 |
532193499 |
TANK.FUEL.4GAL Price: $69.99 |
| 16 |
237-80 |
O-RING Price: $6.10 |
| 17 |
93-6972 |
GEAR MOTOR ASM Price: $1,163.35 |
| 18 |
340-105 |
FITTING-ELBOW, 90 DEG Price: $39.67 |
| 18 |
584248702 |
CAP.ASSY.FUEL.3".N-EPA.GRY.498 This part replaces 532194267. Price: $14.99 |
| 19 |
322-10 |
SCREW-HH Price: $0.70 |
| 20 |
532175437 |
CONTROL.THROTTLE.BLACK This part replaces 532178385. Price: $24.99 |
| 20 |
69-9760 |
COVERPLATE Price: $5.38 |
| 21 |
56-7970 |
CLAMP-TUBE Price: $10.02 |
| 21 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 22 |
340-109 |
FITTING-TEE Price: $59.90 |
| 22 |
532187768 |
CONTROL.CHOKE.ERGO.BLACK This part replaces 532189541. Price: $27.99 |
| 23 |
340-153 |
FITTING-ELBOW, 90 DEG Price: $64.96 |
| 24 |
237-65 |
O-RING Price: $2.50 |
| 25 |
340-155 |
FITTING-STRAIGHT Price: $28.90 |
| 26 |
93-6803 |
FITTING-90 DEG Price: $35.80 |
| 27 |
93-6805 |
HOSE Price: $23.30 |
| 28 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 28 |
587044864 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532401135. Price: $17.99 |
| 29 |
32128-44 |
NUT Price: $2.69 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 30 |
93-6918 |
TUBE-HYD Price: $72.46 |
| 31 |
340-70 |
NUT-LOCK Price: $2.10 |
| 31 |
532145006 |
PUSH CLIP Price: $2.99 |
| 32 |
340-74 |
NUT-LOCK, BULKHEAD Price: $4.83 |
| 33 |
93-6790 |
HOSE-HYD Price: $124.62 |
| 35 |
340-77 |
FITTING-ELBOW, 90 DEG Price: $24.95 |
| 36 |
93-6975 |
MOTOR-GEAR Price: $1,163.35 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 37 |
93-8823 |
COUPLER-MOTOR, REEL Price: $138.11 |
| 38 |
32128-48 |
NUT-LOCK, HHF Price: $1.03 |
| 40 |
93-6789 |
HOSE-HYD Price: $111.78 |
| 41 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 42 |
93-6796-01 |
BRACKET-BULKHEAD This part replaces 93-6796. Price: $16.10 |
| 43 |
93-6919 |
DISCONTINUED Price: Call Us |
| 44 |
93-6920 |
TUBE-HYD Price: $134.55 |
| 45 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 46 |
2412-36 |
CLAMP-HOSE Price: $1.28 |
| 47 |
354-79 |
CAP-DUST Price: $7.81 |
| 48 |
354-77 |
FITTING-QUICK Price: $55.94 |
| 62 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532146629. Price: $11.99 |
| 70 |
532181444 |
EXHAUST TUBE LH KAWI Price: $54.99 |
| 71 |
532181442 |
EXHAUST TUBE RH KAWI Price: $59.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 85 |
501606501 |
BOLT.HEX.7/16-20X4.GR5.1.5BLUE This part replaces 532173937. Price: $2.99 |
| 86 |
532184362 |
NUT.HEX.FLANGE.TOPLOCK Price: $3.99 |
| 87 |
532198239 |
BOLT.5/16-18UNCX1.W/SEMS.BLK Price: $3.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 92 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
