| Ref | Part Number | Description |
|---|
| 1 |
532439822 |
SEAT.TH150.MS498.GRY.HUSQ.TEX This part replaces 532406621. Price: $159.99 |
| 1 |
94-5033-03 |
BRACKET-SUPPORT, CYLINDER This part replaces 83-9760. Price: $182.59 |
| 2 |
32128-43 |
NUT-FLANGE Price: $0.94 |
| 2 |
532180166 |
BRKT.PIVOT.FENDER Price: $11.99 |
| 3 |
532140675 |
STRAP Price: $5.99 |
| 3 |
92-7905 |
SWITCH AND BRACKET ASM Price: $293.34 |
| 4 |
3256-53 |
WASHER-FLAT Price: $0.25 |
| 5 |
3254-9 |
WASHER-LOCK, INTERNAL Price: $0.25 |
| 6 |
3249-3 |
SCREW-PRH Price: $0.34 |
| 6 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 7 |
5-2655 |
CABLE KEEPER Price: $28.04 |
| 7 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK This part replaces 532124181. Price: $5.99 |
| 8 |
5-2653 |
PULLEY ASM Price: $38.12 |
| 8 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 9 |
283-42 |
PIN-CLEVIS Price: $40.05 |
| 10 |
321-43 |
CAPSCREW Price: $0.41 |
| 10 |
596768801 |
KIT.PLATE.SEAT This part replaces 532196977. Price: $49.99 |
| 11 |
84-8440 |
BUSHING Price: $49.87 |
| 12 |
72-4190 |
PIN-GUIDE, CYLINDER Price: $79.12 |
| 13 |
3272-4 |
PIN-COTTER Price: $0.25 |
| 14 |
283-6 |
PIN-CLEVIS Price: $1.70 |
| 15 |
3296-4 |
NUT-LOCK Price: $0.25 |
| 16 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 17 |
3234-25 |
SCREW-HHF Price: $7.69 |
| 18 |
80-6990 |
WASHER-HARDENED Price: $3.06 |
| 19 |
83-8590 |
CABLE - LIFT Price: $34.95 |
| 20 |
323-23 |
SCREW-HH Price: $2.07 |
| 21 |
587907801 |
BOLT.5/16-18X5/8.SHOULDER This part replaces 532171852. Price: $2.99 |
| 21 |
92-7906 |
DISCONTINUED Price: Call Us |
| 22 |
61-3210 |
PULLEY ASM Price: $45.48 |
| 23 |
256-1 |
BUSHING Price: $21.99 |
| 24 |
61-3230 |
SPACER Price: $18.93 |
| 25 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 26 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 27 |
83-9130 |
CABLE KEEPER Price: $20.60 |
| 28 |
63-1400 |
ROD-BELT Price: $17.83 |
| 29 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 30 |
5-2656 |
CABLE KEEPER Price: $27.15 |
| 31 |
282-4 |
SHACKLE Price: $32.98 |
| 32 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 33 |
61-3830 |
CHAIN Price: $14.52 |
| 34 |
71-1380 |
PIN - SWITCH ACTUATOR Price: $51.88 |
| 35 |
71-1370 |
SPRING Price: $8.21 |
| 36 |
283-78 |
PIN-CLEVIS Price: $9.25 |
| 37 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 37 |
76-0020 |
DISCONTINUED Price: Call Us |
| 38 |
237-42 |
O-RING Price: $2.78 |
| 39 |
340-87 |
FITTING-ELBOW, 45 DEG Price: $18.39 |
| 40 |
237-22 |
O-RING Price: $2.43 |
| 40 |
595088102 |
Handles This part replaces 532197661. Price: $4.99 |
| 41 |
110-0973 |
HOSE-HYD This part replaces 85-4990. Price: $84.41 |
| 41 |
532198200 |
SPRING.LATCH.SEAT.TEX Price: $3.99 |
| 42 |
83-9620 |
DISCONTINUED Price: Call Us |
| 43 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 43 |
874760612 |
BOLT Price: $3.99 |
| 44 |
HY2562 |
DISCONTINUED This part replaces 256-2. Price: Call Us |
| 45 |
61-2430 |
LIFT HUB WA Price: $116.98 |
| 46 |
119-4162 |
SCREW-CARR This part replaces 323-13. Price: $1.73 |
| 47 |
340-2 |
FITTING-STRAIGHT Price: $11.43 |
