| Ref | Part Number | Description |
|---|
| 1 |
27-1170 |
THRUST WASHER Price: $3.66 |
| 2 |
27-1180 |
BEARING RETAINER Price: $3.37 |
| 3 |
27-1210 |
ROLLER BEARING Price: $32.99 |
| 4 |
68-8980 |
SPANNER-TIRE Price: $8.72 |
| 5 |
27-1190 |
WHEEL Price: $74.99 |
| 6 |
27-1200 |
SPANNER BUSHING Price: $11.99 |
| 501875301 |
501875301 |
KNEE-JOINT Price: $19.99 |
| 508030901 |
508030901 |
SCREW Price: $3.99 |
| 508042214 |
508042216 |
BRACKET This part replaces 508042214. Price: $27.99 |
| 508042323 |
508042323 |
HANDGUARD Price: $32.99 |
| 508043005 |
508043005 |
BRAKE BAND Price: $11.99 |
| 508045401 |
508045401 |
INSULATOR Price: $7.99 |
| 508046001 |
508046001 |
CHAIN TENSIONER Price: $8.99 |
| 508046202 |
508046202 |
SCREW Price: $2.99 |
| 508046301 |
508046301 |
SPRING Price: $3.99 |
| 508046610 |
508046610 |
PIN Price: $2.61 |
| 508046614 |
508046614 |
PIN Price: $2.99 |
| 508047716 |
508047716 |
Pin Price: $3.62 |
| 723133976 |
508046203 |
SCREW This part replaces 723133976. Price: $5.99 |
| 725245776 |
725245776 |
SCREW Price: $4.99 |
| 729527901 |
729527901 |
SCREW Price: $2.99 |
| 729529371 |
729529371 |
SCREW Price: $2.99 |
| 738210102 |
738210102 |
BALL BEARING Price: $14.99 |
