| Ref | Part Number | Description |
|---|
| 1 |
3241-7 |
SCREW-SQH This part replaces 324-12. Price: $3.39 |
| 2 |
66-6480 |
WASHER Price: $1.29 |
| 3 |
26-1890 |
DISCONTINUED Price: Call Us |
| 3 |
532430771 |
LOGO.HUSQ.GT.LT.CROWN.H This part replaces 532405012. Price: $5.99 |
| 4 |
32128-21 |
NUT-HF Price: $0.39 |
| 5 |
532408703 |
DASH Price: $54.99 |
| 5 |
63-8410 |
WASHER Price: $1.76 |
| 6 |
93-6697 |
DECAL-LUBE This part replaces 70-2560. Price: $11.38 |
| 7 |
39-3330-01 |
PLATE-CLAMP, CASTOR ARM This part replaces 39-3330. Price: $36.10 |
| 8 |
325-14 |
SCREW-HH Price: $2.64 |
| 9 |
39-3340-01 |
BRACKET-ARM CLAMP This part replaces 39-3340. Price: $101.90 |
| 10 |
32128-23 |
NUT-HF Price: $1.51 |
| 11 |
108-1370 |
GEARBOX REPLACEMENT KIT This part replaces 68-6810. Price: $862.61 |
| 12 |
3257-5 |
KEY-WOODRUFF Price: $5.13 |
| 13 |
93-9838-03 |
SHROUD-SHAFT, DRIVE This part replaces 63-1970. Price: $56.70 |
| 14 |
32104-82 |
SCREW-HHF Price: $0.95 |
| 14 |
532442396 |
HOOD.ASM.HUSQVARNA.GT.TEX.ORAN This part replaces 532411046. Price: $149.99 |
| 15 |
26-1900 |
DISCONTINUED Price: Call Us |
| 15 |
532198907 |
LENS.LH.TEX.GT.HUSQ.CL Price: $22.99 |
| 16 |
3290-384 |
PIN-LYNCH Price: $18.43 |
| 17 |
63-0070 |
SPACER Price: $1.82 |
| 18 |
532408607 |
GRILL.ASM.HUSQ.TG/CRD.W/TRIM Price: $129.99 |
| 18 |
94-1291 |
BUSHING This part replaces 28-9290. Price: $10.99 |
| 19 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 20 |
38-9420 |
LH CASTOR ARM ASM Price: $993.47 |
| 21 |
3-6781 |
WASHER-THRUST Price: $1.40 |
| 22 |
75-9680-01 |
FORK-CASTOR This part replaces 75-9680. Price: $151.01 |
| 23 |
325-18 |
SCREW-HH Price: $3.19 |
| 24 |
3256-6 |
WASHER-FLAT Price: $0.34 |
| 25 |
532198906 |
LENS.RH.TEX.GT.HUSQ.CL Price: $32.99 |
| 25 |
62-5580 |
BEARING-OUTSIDE Price: $6.58 |
| 26 |
63-1770 |
SPANNER Price: $17.94 |
| 27 |
302-11 |
FITTING-LUBE, 45 DEG Price: $1.56 |
| 28 |
63-8400 |
CASTER WHEEL ASM Price: $75.13 |
| 29 |
63-8580 |
BEARING-ROLLER Price: $12.48 |
| 30 |
3233-2 |
SCREW-CARR Price: $1.49 |
| 31 |
32128-49 |
NUT-HHF Price: $1.04 |
| 32 |
32128-42 |
NUT-HF Price: $0.98 |
| 33 |
325-22 |
SCREW-HH Price: $4.26 |
| 34 |
580910801 |
PLATE.ENGINE.WELDED.CHASSIS This part replaces 532196125. Price: $59.99 |
| 34 |
62-5570 |
BEARING-ROLLER Price: $18.63 |
| 35 |
302-40 |
FITTING-GREASE, 90 DEG Price: $1.70 |
| 36 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK This part replaces 817060512. Price: $4.99 |
| 37 |
597652401 |
SERVICE KIT FENDER.TLT.CPH.615 This part replaces 532418714. Price: $219.99 |
| 37 |
62-4340 |
SPANNER Price: $16.93 |
| 38 |
26-1530-01 |
FORK-CASTOR This part replaces 26-1530. Price: $178.41 |
| 39 |
23-1640 |
BUSHING-TAPERLOCK Price: $68.50 |
| 40 |
3247-4 |
SCREW-SET Price: $0.54 |
| 41 |
26-1400 |
PULLEY-DECK Price: $539.17 |
| 42 |
3231-26 |
SCREW-CARR Price: $0.86 |
| 43 |
68-9890-01 |
COVER-GEARBOX, FRONT This part replaces 68-9890. Price: $47.21 |
| 44 |
63-9750 |
MOUNT Price: $18.92 |
| 45 |
68-8560-03 |
BRACKET-GEARBOX This part replaces 68-8560. Price: $57.56 |
| 46 |
323-4 |
SCREW-HH Price: $1.02 |
| 47 |
38-9370 |
RH CASTOR ARM ASM Price: $946.82 |
| 52 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 58 |
531152601 |
SERVICE KIT DRAWBAR FENDER DRA This part replaces 532412280. Price: $44.99 |
| 68 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 130 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 137 |
532407590 |
BUMPER DASH Price: $3.99 |
| 138 |
532439747 |
HOLDER.CUP.LT.GREY This part replaces 532402954. Price: $4.99 |
| 150 |
532198513 |
AIR.DUCT.TEXGT.HUSQ.SV Price: $37.99 |
| 152 |
531169901 |
SERVICE KIT SHIELD SHIELD.BROW This part replaces 532199535. Price: $19.99 |
| 159 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 162 |
596134101 |
Screws This part replaces 532142432. Price: $2.99 |
| 175 |
590607702 |
PLATE.PNT.CROSSMEMBER.HUSQ/PRE This part replaces 532196304. Price: $32.99 |
| 176 |
532400776 |
SCREW.#10-24X5/8.RN.QU Price: $4.99 |
| 177 |
532195227 |
BUSHING, STEERING Price: $5.99 |
| 178 |
532199782 |
CARGO.ASM.NET.TXGT.W/C Price: $29.99 |
| 180 |
532415063 |
CHASS.WLDMNT.TL.12GA/2P.48/54 Price: $169.99 |
| 181 |
532403025 |
BUSHING.MNT.FEND.CRGO. Price: $4.99 |
| 182 |
532406859 |
DASH.LOWER.COMMON.12V.ADAPTOR Price: $84.99 |
| 183 |
595305701 |
Screws This part replaces 874780520. Price: $3.99 |
| 189 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 194 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 195 |
532404137 |
PLUG.HOLE.DASH.LOWER.12V.BLK Price: $4.99 |
| 196 |
547634701 |
CONSOLE.DECKLIFT.GREY.PKG.KIT This part replaces 532414580. Price: $17.99 |
| 202 |
532403048 |
VENT.SIDE.HOOD.HUSQ.RH.GREY Price: $7.99 |
| 203 |
532403076 |
VENT.SIDE.HOOD.HUSQ.LH.GRAY Price: $7.99 |
| 204 |
532416615 |
VENT.ASM.TORPHD.HUSQGT.LOGO.CL This part replaces 532416613. Price: $16.99 |
| 205 |
532401709 |
SKIRT.HOOD.SIDE.HUSQ.RH.GREY Price: $6.99 |
| 206 |
532401711 |
SKIRT.HOOD.SIDE.HUSQ.LH.GREY Price: $5.99 |
| 207 |
532197198 |
BEZEL.RH.TEX.GT.HUSQ Price: $19.99 |
| 208 |
532197199 |
BEZEL.LH.TEX.GT.HUSQ Price: $17.99 |
| 209 |
532199130 |
INSERT.HEX.GRILL.HUSQ.GREY Price: $4.99 |
| 210 |
532199131 |
INSERT.HEX.GRILL.HUSQ. Price: $2.99 |
| 211 |
532199132 |
INSERT.HEX.GRILL.HUSQ. Price: $2.99 |
| 212 |
532199133 |
INSERT.HEX.GRILL.HUSQ. Price: $2.99 |
| 213 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 874760512. Price: $3.99 |
| 214 |
532199145 |
CLIP.RETAINER.TINNER. Price: $2.99 |
| 217 |
532409167 |
ROD.PIVOT.HOOD Price: $9.99 |
| 218 |
532196395 |
X-PIECE.HOOD.STOP.NON/ Price: $6.99 |
| 228 |
593824001 |
STUD.W/"D"ANTI-ROTATION This part replaces 532195161. Price: $3.99 |
| 230 |
532170165 |
SHOULDER BOLT 5/16-18TT Price: $3.99 |
| 234 |
532404742 |
BUMPER.HOOD.TEX.HUSQVARNA Price: $5.99 |
| 235 |
596564201 |
Spacers This part replaces 532406129. Price: $4.99 |
| 236 |
873930500 |
NUT.CENTERLOCK.5/16- Price: $3.99 |
| 238 |
532408606 |
TRIM.HUSQ.TG/CRD.SERVICE Price: $17.99 |
| 239 |
532110452 |
NUT PUSH M Price: $2.99 |
