| Ref | Part Number | Description |
|---|
| 1 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 1 |
530071300 |
Kit-Handle / Shroud Type 1,2,3 Price: $12.99 |
| 2 |
530016258 |
Plate Crankcase Price: $0.64 |
| 2 |
93-8806 |
WASHER-HARDENED Price: $1.62 |
| 3 |
140-6221 |
LINK AND BUSHING ASSEMBLY This part replaces 16-9759. Price: $70.43 |
| 3 |
530016349 |
Screw - Type 2 Price: $1.99 |
| 4 |
530016386 |
SCREW This part replaces 530015810. Price: $5.99 |
| 4 |
93-6981 |
SPACER Price: $4.69 |
| 5 |
3231-40 |
BOLT-CARR, SHORT NECK Price: $1.27 |
| 5 |
530071300 |
Kit-Shroud / Handle Type 1,2,3 Price: $12.99 |
| 6 |
115-4263 |
PLATE-SIDE, RH Price: $329.24 |
| 6 |
530052333 |
Air Box Price: $2.99 |
| 7 |
115-4260 |
PLATE-SIDE, LH Price: $329.24 |
| 7 |
530015123 |
Washer Price: $1.99 |
| 8 |
112-8979 |
TUBE-SUPPORT Price: $52.72 |
| 8 |
530015849 |
Screw Price: $1.99 |
| 9 |
112-8978 |
FRAME-CENTER Price: $494.59 |
| 9 |
530047932 |
Foam-Air Filter Price: $1.99 |
| 10 |
530016349 |
Screw Price: $1.99 |
| 11 |
530052332 |
Cover-Air Box Type 1 Price: $1.99 |
| 11 |
530054275 |
Cover-Air Box Type 2 Price: $1.99 |
| 12 |
110-4058 |
BRACKET-CHAIN Price: $32.43 |
| 13 |
530069616 |
Gasket-Carb. Price: $6.99 |
| 14 |
530016014 |
Screw Price: $1.99 |
| 15 |
119-4162 |
SCREW-CARR This part replaces 3231-25. Price: $1.73 |
| 15 |
530049025 |
Carb. Adaptor Price: $5.99 |
| 16 |
3290-357 |
NUT-HHF, WHIZ Price: $0.61 |
| 16 |
530069616 |
Gasket-Cyl/Carb. Adaptor Price: $6.99 |
| 17 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 17 |
530032125 |
Inner Bearing Price: $11.99 |
| 18 |
107-2979 |
BOLT-SHOULDER Price: $3.94 |
| 18 |
530015941 |
Retainer Ring (C'shaft) Price: $1.99 |
| 19 |
530071615 |
Kit-Crankcase Seal Price: $4.99 |
| 20 |
530069616 |
Gasket Kit Price: $6.99 |
| 21 |
530055728 |
Outer Bearing Price: $6.99 |
| 24 |
530023817 |
Spring-Starter Dog Price: $1.99 |
| 27 |
530054139 |
Grommet-Rubber - Type 2 Price: Call Us |
| 28 |
530054121 |
Fan Housing Price: $5.99 |
| 29 |
530015954 |
Screw Price: $1.99 |
| 30 |
530019182 |
Grommet-Ign. Module Price: $1.99 |
| 31 |
530039163 |
Ignition Module Price: $34.99 |
| 32 |
530036145 |
Spacer-Ign. Module Price: $1.99 |
| 33 |
530069616 |
Gasket-Cylinder Price: $6.99 |
| 34 |
530049817 |
CONNECTING ROD ASSY This part replaces 530069945. Price: $6.99 |
| 35 |
530015162 |
Wrist Pin Retainer Price: $1.99 |
| 36 |
530052348 |
Piston Ring Price: $4.99 |
| 38 |
530015953 |
Screw Price: $1.99 |
| 39 |
530012390 |
CYLINDER This part replaces 530069949. Price: $6.99 |
| 41 |
530042088 |
Muffler Spring Price: $1.99 |
| 42 |
952030249 |
Spark Plug (RCJ-6Y) Price: $3.99 |
| 43 |
530016349 |
Screw Price: $1.99 |
| 44 |
530016304 |
Washer - Type 2 Price: $0.04 |
| 45 |
530071625 |
C'case & C'shaft Ass'y. This part replaces 530052344. Price: $39.99 |
| 46 |
530015149 |
Washer This part replaces 530015682. Price: $1.99 |
| 47 |
530016058 |
Screw - Type 1 Price: $1.99 |
| 48 |
530015805 |
Screw - Type 1 Price: $1.99 |
| 49 |
530054432 |
Isolator - Type 3 Price: $3.99 |
| 50 |
530016316 |
Nut - Type 3 Price: $1.99 |
