| Ref | Part Number | Description |
|---|
| 1 |
88-1610 |
FIELD & ROTOR ASM Price: $816.64 |
| 2 |
88-1370 |
PLATE-BRAKE Price: $262.22 |
| 3 |
98-7253 |
ARMATURE ASM Price: $744.91 |
| 4 |
44-8320 |
SPRING Price: $8.31 |
| 38 |
710-04980 |
Bolt M6X35 Price: $3.42 |
| 41 |
710-04916 |
Bolt M6X14 Multi-Purpose Price: $3.86 |
| 57 |
710-04922 |
Bolt M8X50 Price: $3.66 |
| 86 |
951-11624 |
CRANKSHAFT ASSEMBLY Not Available Price: |
| 87 |
751P10307A |
WOODRUFF KEY This part replaces 951-10307. Price: $2.01 |
| 88 |
736-04491 |
Crankshaft Thrust Washer Price: $3.78 |
| 90 |
951-11764B |
Dipstick Assembly Price: $13.22 |
| 91 |
951-11547 |
OIL FILL TUBE O-RING Price: $3.71 |
| 92 |
951-11765A |
Oil Filler Tube Assemlby Price: $18.04 |
| 93 |
710-04906 |
Oil Drain Plug Price: $5.86 |
| 94 |
736-04440A |
FLAT WASHER This part replaces 736-04440. Price: $6.01 |
| 95 |
715-04089 |
DOWEL PIN Not Available Price: |
| 96 |
951-11625 |
GOVERNOR GEAR MOUNTING PLATE Not Available Price: |
| 97 |
951-11626 |
GOVERNOR GEAR/SHAFT ASSEMBLY Not Available Price: |
| 107 |
715-04096A |
DOWEL PIN 9 X 14 This part replaces 715-04092. Price: $3.66 |
| 108 |
951-11794 |
CRANKCASE COVER Not Available Price: |
| 109 |
951-11627 |
LOWER CRANKSHAFT SEAL Not Available Price: |
