| Ref | Part Number | Description |
|---|
| 1 |
21-1880 |
GRIP-HANDLE Price: $11.67 |
| 2 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $39.99 |
| 2 |
84-8500-01 |
LEVER-PTO This part replaces 84-8500. Price: $107.85 |
| 3 |
72-4320 |
SWITCH-BALL Price: $90.18 |
| 4 |
237-30 |
O-RING Price: $2.50 |
| 5 |
43-8610 |
GUIDE Price: $23.35 |
| 6 |
84-8520-01 |
BRACKET-SWITCH, PTO This part replaces 84-8520. Price: $11.07 |
| 7 |
283-42 |
PIN-CLEVIS Price: $40.05 |
| 8 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 9 |
43-3860 |
SHAFT-PIVOT, PTO Price: $55.10 |
| 9 |
596501502 |
Keepers This part replaces 532194320. Price: $9.99 |
| 10 |
302-10 |
FITTING-GREASE Price: $2.64 |
| 11 |
3257-5 |
KEY-WOODRUFF Price: $5.13 |
| 11 |
532414336 |
KIT.SVC.CLUTCH.ELECTRIC. This part replaces 532400008. Price: $329.99 |
| 12 |
106-4383 |
BELT-V, BANDED This part replaces 53-9660. Price: $40.02 |
| 12 |
532405097 |
PULLEY.ENGINE.TUFFTORQ Price: $49.99 |
| 13 |
21-0230 |
PULLEY-PTO Price: $409.71 |
| 14 |
3256-28 |
WASHER-FLAT Price: $0.48 |
| 15 |
3254-7 |
WASHER-LOCK, INT Price: $4.82 |
| 15 |
599306004 |
FUEL TANK, 3GAL, 2.25"NECK, 20 This part replaces 532438080. Price: $199.99 |
| 16 |
3219-7 |
NUT-HEX Price: $1.53 |
| 17 |
3272-22 |
PIN-COTTER Price: $0.61 |
| 18 |
3-6498 |
WASHER-THRUST Price: $4.58 |
| 18 |
532439208 |
CAP.ASM.FL.RITCH.3"E10.SYM.498 Price: $37.99 |
| 19 |
3-8812 |
SPACER-SPRING, ANCHOR Price: $15.47 |
| 20 |
3256-6 |
WASHER-FLAT Price: $0.34 |
| 20 |
532177328 |
CONTROL.THROTTLE.LH.COBRA.KNOB This part replaces 532182937. Price: $24.99 |
| 21 |
5-1747 |
SPRING-ADJUSTMENT Price: $5.76 |
| 21 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 22 |
532191596 |
CONTROL.CHOKE.ERGO.PUSH-IN.BLA Price: $32.99 |
| 22 |
92-5727 |
SCREW-LOCK, PATCH Price: $0.92 |
| 23 |
92-5723 |
BUSHING-FORK, PTO Price: $4.74 |
| 24 |
110-9681-03 |
FORK-PTO This part replaces 92-4060. Price: $195.34 |
| 25 |
27-7370 |
PTO BRAKE ASM Price: $218.20 |
| 26 |
93-3769 |
PIN-CLEVIS Price: $4.14 |
| 27 |
3296-28 |
NUT-LOCK, NI Price: $0.61 |
| 28 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 28 |
587044864 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532401135. Price: $17.99 |
| 29 |
3246-3 |
SCREW-HSH Price: $12.70 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 30 |
92-4058-01 |
ARM PTO This part replaces 92-4058. Price: $136.94 |
| 31 |
100-6599 |
PTO PIVOT ASM This part replaces 43-5500. Price: $780.32 |
| 32 |
43-5550 |
SHAFT-ACTUATOR, PTO Price: $143.65 |
| 33 |
3219-3 |
NUT-HEX Price: $0.34 |
| 34 |
3296-6 |
NUT-LOCK Price: $1.49 |
| 35 |
27-7900 |
SCREW-ADJUSTING Price: $21.70 |
| 36 |
3256-41 |
WASHER Price: $1.18 |
| 37 |
5-0652 |
SPACER Price: $5.35 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 38 |
43-5570-01 |
ARM-ACTUATOR This part replaces 43-5570. Price: $164.96 |
| 39 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 40 |
251-252 |
BEARING Price: $98.35 |
| 41 |
251-234 |
COLLAR-LOCKING Price: $17.04 |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 42 |
32120-22 |
RING-SNAP, INTERNAL Price: $2.29 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 43 |
43-5540 |
SHAFT-PTO Price: $846.33 |
| 44 |
100-6564 |
DRIVESHAFT ASM This part replaces 62-4260. Price: $924.10 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 46 |
3246-1 |
SCREW-SET Price: $6.24 |
| 47 |
256-113 |
BUSHING-FLANGE Price: $5.58 |
| 48 |
21-0400-01 |
SPRING-COMPRESSION This part replaces 21-0400. Price: $20.88 |
| 49 |
32121-9 |
PIN-ROLL, SLOTTED Price: $2.56 |
| 50 |
21-1830 |
SPRING-EXTENSION Price: $34.62 |
| 51 |
43-5630 |
YOKE-PTO Price: $80.75 |
| 52 |
5-0701 |
ANCHOR Price: $4.07 |
| 53 |
212-93 |
CLAMP-CASING Price: $3.46 |
| 54 |
21-1600 |
CLAMP-LEVER, PTO Price: $279.65 |
| 55 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 56 |
32104-6 |
SCREW-HH, TAP Price: $3.19 |
| 62 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532434017. Price: $11.99 |
| 66 |
43-8600 |
SPRING-COMPRESSION Price: $3.03 |
| 67 |
43-8860 |
PLUNGER-SWITCH Price: $11.85 |
| 68 |
43-8620 |
PIN-GUIDE, SWITCH Price: $88.57 |
| 69 |
237-7 |
O-RING Price: $8.82 |
| 69 |
532186054 |
GASKET.EXHAUST.KOHL.CV18-CV26 Price: $5.99 |
| 70 |
218-461 |
NUT-HH Price: $2.50 |
| 71 |
43-8870 |
BOOT-SWITCH Price: $47.92 |
| 72 |
321-4 |
SCREW-HH Price: $0.99 |
| 73 |
86-7050 |
BRACKET-SWITCH, ACTUATOR Price: $16.28 |
| 74 |
3296-16 |
NUT-LOCK, NI Price: $1.39 |
| 75 |
75-9890 |
WASHER-SHIM Price: $3.18 |
| 79 |
596134201 |
Screws This part replaces 532192334. Price: $2.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN Price: $14.99 |
| 85 |
501606501 |
BOLT.HEX.7/16-20X4.GR5.1.5BLUE This part replaces 532173937. Price: $2.99 |
| 87 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 91 |
532187495 |
BUSHING.1.375OD Price: $4.99 |
| 92 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
