| Ref | Part Number | Description |
|---|
| 1 |
532439997 |
WHEEL.STEERING.HUSQ.PREM.HRDRM Price: $49.99 |
| 1 |
MA-19562611000 |
FRONT GRILL Not Available Price: |
| 2 |
532413591 |
AXLE.SVC.ASM CAST IRON.TEX This part replaces 532195968. Price: $119.99 |
| 2 |
MA-19562612AG0 |
SCREEN-GRILL Not Available Price: |
| 3 |
MA-04322105012 |
SCREW Not Available Price: |
| 4 |
538690801 |
SPINDLE.WLDMT.LH.13IN BLK.X431 This part replaces 532416845. Price: $37.99 |
| 4 |
MA-19572615000 |
COVER-GRILL FRONT Not Available Price: |
| 5 |
538690701 |
SPINDLE.WLDMT.RH.13IN BLK.X431 This part replaces 532416846. Price: $34.99 |
| 5 |
MA-19562616000 |
REFLECTOR-HEADLAMP Not Available Price: |
| 6 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 6 |
MA-F3000106001 |
NUT Not Available Price: |
| 7 |
532121748 |
WASHER Price: $3.99 |
| 7 |
MA-19572637ZB0 |
BRACKET-GRILLE Not Available This part replaces MA-19572637000. Price: |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 8 |
MA-F3000106001 |
NUT Not Available Price: |
| 9 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 9 |
MA-H1540108016 |
BOLT,W/WASHER Not Available Price: |
| 10 |
MA-19572636AG0 |
BRACKET-HOOD LATCH MT Not Available Price: |
| 11 |
MA-F1540108020 |
BOLT,W/SPRING WASH Not Available Price: |
| 12 |
MA-19740722000 |
SPRING Not Available Price: |
| 13 |
532121749 |
WASHER Price: $2.99 |
| 13 |
MA-10382636001 |
BRACKET-HOOD LATCH Not Available This part replaces MA-10382636000. Price: |
| 14 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 14 |
MA-19572638000 |
LEVER-HOOD Not Available Price: |
| 15 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 15 |
MA-19562641BC0 |
COVER-GRILL LOWER Not Available Price: |
| 16 |
587738903 |
KIT.SRVC.STEERINGSHAFT.3HISHFT This part replaces 585869202. Price: $44.99 |
| 16 |
MA-H1440106016 |
Bolt,w/Washer Price: $2.83 |
| 17 |
MA-19562659000 |
ROD-HOOD S Not Available Price: |
| 18 |
MA-05200125015 |
COTTER PIN Not Available This part replaces MA-05200125016. Price: |
| 19 |
531169101 |
SERVICE KIT PLATE PLATE.STEER. This part replaces 532194729. Price: $19.99 |
| 19 |
MA-03500160826 |
WASHER Not Available Price: |
| 20 |
532441425 |
STEERING.BOOT.HUSQ.LT Price: $7.99 |
| 20 |
MA-H1540108016 |
BOLT,W/WASHER Not Available Price: |
| 21 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 532186737. Price: $7.99 |
| 21 |
MA-04322106012 |
TAP SCREWPING Not Available Price: |
| 22 |
587738901 |
KIT.SRVC.STEERINGSHAFT.LWRBSHG This part replaces 585029802. Price: $14.99 |
| 22 |
MA-03500130613 |
WASHER Not Available Price: |
| 23 |
MA-19562682000 |
CUSHION-RUBBER Not Available Price: |
| 24 |
MA-27553236000 |
CUSHION-RUBBER Not Available Price: |
| 25 |
MA-19562687000 |
CUSHION-RUBBER Not Available Price: |
| 26 |
532439743 |
INSERT.CAP.WHL.STRG.HUSQ.PREM Price: $8.99 |
| 26 |
MA-19562685001 |
SCREW Not Available Price: |
| 27 |
596933401 |
Washers This part replaces 819211616. Price: $2.99 |
| 27 |
MA-19572625000 |
CUSHION-LOWER GRIL Not Available Price: |
| 28 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 28 |
MA-19572626000 |
CUSHION-RUBBER Not Available Price: |
| 29 |
MA-35323804200 |
STRIP-RUBBER SEAL Not Available Price: |
| 30 |
MA-10410441000 |
CUSHION-RUBBER Not Available Price: |
| 31 |
MA-10402624001 |
SPRING Not Available Price: |
| 32 |
MA-F0500106016 |
Bolt,Flange Price: Call Us |
| 33 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 33 |
MA-27935289000 |
SPACER Not Available Price: |
| 34 |
MA-05200125015 |
COTTER PIN Not Available This part replaces MA-05200125016. Price: |
| 35 |
532194732 |
GEAR.SECTOR.PLATE.DDL. Price: $27.99 |
| 45 |
596040001 |
Washers This part replaces 819113812. Price: $6.99 |
| 53 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 57 |
532407465 |
BRACKET.UPSTOP.TEX Price: $5.99 |
| 58 |
532194747 |
BOLT.SHOULDER.SECTOR.P Price: $7.99 |
| 60 |
583612801 |
NUT.FLANGE.LOCK.5/8-11 This part replaces 873971000. Price: $3.99 |
| 61 |
597047802 |
Links This part replaces 532194740. Price: $11.99 |
| 62 |
597047902 |
Links This part replaces 532194741. Price: $11.99 |
| 63 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 64 |
532199849 |
RETAINER.CLIP.SPRING.S Price: $4.99 |
| 66 |
871020748 |
BOLT HEX FGHD 7/16-14 X 3 SERR Price: $4.99 |
| 67 |
529496302 |
BUSHING, AXLE This part replaces 532194737. Price: $2.99 |
| 68 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 69 |
532199162 |
WASHER.1.5X.505X.118 Price: $4.99 |
| 70 |
532417065 |
BRACKET.SUSP.MWR.FRT.30"SRD Price: $19.99 |
| 71 |
532190752 |
SHAFT.EXTEN.STRG.SPLINE Price: $11.99 |
| 72 |
596039701 |
Bolts This part replaces 532428982. Price: $3.99 |
| 75 |
587738906 |
KIT.SRVC.STEERINGSHAFT.PINION This part replaces 580683702. Price: $4.99 |
| 76 |
580683601 |
SCREW HEAD SOCKET LRVB Price: $2.99 |
| 122 |
583576601 |
CAP.GEAR.SECTOR.TEX This part replaces 532444962. Price: $4.99 |
