| Ref | Part Number | Description |
|---|
| 1 |
93-5645 |
CENTER SHROUD ASM This part replaces 93-5082. Price: $2,188.91 |
| 2 |
95-6135 |
ROPS ASM-GM3000 This part replaces 93-5044. Price: $1,067.55 |
| 3 |
93-5253 |
STRIP-FOAM, HOOD Price: $21.16 |
| 4 |
2412-108 |
CLAMP-WORM Price: $1.29 |
| 5 |
110-4109 |
HOSE-FUEL This part replaces 93-5482. Price: $11.24 |
| 6 |
109-0308 |
HOSE-FUEL This part replaces 93-5484. Price: $10.99 |
| 7 |
93-5083 |
HOSE-CLEANER, AIR Price: $167.33 |
| 8 |
2412-110 |
CLAMP-BAND/SCREW Price: $3.60 |
| 9 |
93-5111 |
CLEANER-AIR Price: $474.66 |
| 10 |
2412-130 |
CLAMP-HOSE Price: $2.57 |
| 11 |
93-5427 |
SPACER-INTAKE Price: $5.82 |
| 12 |
93-5084 |
HOSE-CLEANER, AIR Price: $83.18 |
| 13 |
93-5420 |
SCREW-HH Price: $1.63 |
| 14 |
3256-6 |
WASHER-FLAT Price: $0.34 |
| 15 |
93-5157-03 |
BAR-ROPS ASM This part replaces 93-5157. Price: $133.96 |
| 16 |
33004-00 |
NUT-HF Price: $0.34 |
| 17 |
94-8099 |
DECAL This part replaces 94-3395. Price: $16.38 |
| 18 |
33104-016 |
SCREW-HHF Price: $0.97 |
| 19 |
33094-00 |
WASHER-PLAIN Price: $0.25 |
| 20 |
33104-020 |
SCREW-HHF Price: $2.07 |
| 21 |
93-5638 |
COVER-TUBE Price: $18.82 |
| 22 |
33113-020 |
SCREW-HH Price: $0.26 |
| 501277401 |
501277401 |
V-RING Price: $11.99 |
| 501284101 |
501284101 |
CONTROL SCREW Price: $2.19 |
| 501288501 |
501288501 |
X-RING Price: $4.99 |
| 501292702 |
501292702 |
DRIVE GEAR BRONZE Price: $42.99 |
| 501293301 |
501293301 |
NEEDLE BEARING Price: $10.12 |
| 501293701 |
501293701 |
Pump Plunger Price: $35.47 |
| 501293801 |
501293801 |
Screw Price: $3.63 |
| 501293902 |
501293902 |
Bushing Price: $16.52 |
| 501519901 |
501519901 |
OIL HOSE Price: $8.99 |
| 501540201 |
501540201 |
CLUTCH DRUM 3/8 X 8 SPUR Price: $32.21 |
| 501544102 |
501544102 |
OIL SCREEN Price: $14.99 |
| 501544801 |
501544801 |
SPRING Price: $3.99 |
| 501598201 |
501598201 |
SEALING Price: $9.99 |
| 501802501 |
503698101 |
OIL PUMP This part replaces 501802501. Price: $119.99 |
| 501803001 |
501803001 |
WORM WHEEL Price: $8.99 |
| 503230019 |
503230019 |
WASHER 6.6X11 Price: $2.99 |
| 503231002 |
503231002 |
WASHER 6.6X11 Price: $2.99 |
| 503253001 |
503253001 |
SUPPORT BUSHING Price: $11.99 |
| 503260205 |
503260205 |
SEALING RING Price: $11.99 |
| 503471801 |
503471801 |
SPRING Price: $4.99 |
| 503471901 |
503701504 |
CLUTCHES This part replaces 503471901. Price: $49.99 |
| 503495001 |
503495001 |
DUST PROTECTION Price: $3.99 |
| 721420325 |
721420325 |
SPRING PIN 3X6 Price: $2.99 |
| 725529556 |
503202620 |
SCREW This part replaces 725529556. Price: $2.99 |
| 740420100 |
740420100 |
O-RING Price: $3.99 |
| 740422400 |
740422400 |
O-RING Price: $5.99 |
