| Ref | Part Number | Description |
|---|
| 1 |
323-6 |
SCREW-HH Price: $0.66 |
| 1 |
52-281-23 |
DUCT, AIR Price: Call Us |
| 2 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 2 |
X-82-2 |
NUT Price: Call Us |
| 3 |
32149-2 |
NUT-KEPS Price: $2.39 |
| 3 |
52-282-01 |
COVER, AIR DUCT Price: Call Us |
| 4 |
321-3 |
SCREW-HH Price: $0.28 |
| 4 |
52-281-05 |
DUCT, AIR Price: Call Us |
| 5 |
256-273 |
BUSHING-FLANGE Price: $4.55 |
| 5 |
52-063-36 |
BAFFLE Price: Call Us |
| 6 |
43-6320 |
COLLAR Price: $24.71 |
| 6 |
52-755-71 |
KIT, BLOWER HOUSING Price: Call Us |
| 7 |
52-086-11 |
SCREW Price: Call Us |
| 7 |
71-0440 |
ABRASIVE-PEDAL Price: $15.80 |
| 8 |
52-468-16 |
WASHER Price: Call Us |
| 8 |
69-9390 |
SHAFT-PEDAL Price: $71.62 |
| 9 |
52-217-01 |
SUPPORT, UPPER HOUSING Price: Call Us |
| 9 |
71-0450 |
ABRASIVE-PEDAL, REAR Price: $10.39 |
| 10 |
3234-14 |
SCREW-HHF Price: $0.61 |
| 10 |
X-67-83 |
SCREW Price: Call Us |
| 11 |
32128-20 |
NUT-HF Price: $0.99 |
| 11 |
52-063-30 |
BAFFLE Price: Call Us |
| 12 |
3217-7 |
NUT-HEX Price: $0.28 |
| 13 |
69-9030 |
POST-DEVICE, NEUTRAL Price: $39.15 |
| 14 |
23-2270 |
BUSHING-RUBBER Price: $17.07 |
| 15 |
3256-6 |
WASHER-FLAT Price: $0.34 |
| 16 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 17 |
107-1179-03 |
CONTROL-ROD Price: $189.90 |
| 18 |
3220-5 |
NUT-JAM This part replaces 3220-5-01. Price: $0.65 |
| 19 |
21-0141 |
RH BALL JOINT ASM This part replaces 21-0141-03. Price: $109.12 |
| 20 |
3220-3 |
NUT-HJ Price: $0.28 |
| 21 |
3272-7 |
PIN-COTTER Price: $0.25 |
| 22 |
99-5347-03 |
TRACTION PEDAL ASM Price: $219.38 |
| 23 |
3245-32 |
SCREW-HSH Price: $3.59 |
| 24 |
99-5348 |
PLATE-CLUTCH Price: $61.10 |
| 25 |
43-6200 |
SPRING-COMPRESSION Price: $20.42 |
| 26 |
100-8016 |
FIELD CORE COIL ASM Price: $165.29 |
| 27 |
92-9701 |
SHAFT-CRUISE Price: $101.17 |
