| Ref | Part Number | Description |
|---|
| 1 |
133-2313 |
SUPPORT-PLATFORM, RH Price: $501.72 |
| 2 |
131-3179-01 |
PEDAL-TRACTION Price: $80.00 |
| 3 |
3256-1 |
WASHER-FLAT Price: $0.39 |
| 4 |
33023-00 |
NUT-LOCK Price: $0.25 |
| 5 |
33114-016 |
SCREW-HH Price: $0.27 |
| 6 |
94-1374 |
TRUNNION-BRACKET, MOW Price: $14.18 |
| 7 |
33014-00 |
NUT-HEX Price: $0.25 |
| 8 |
94-1375 |
TRUNNION-BRACKET, LOCK Price: $23.45 |
| 9 |
94-3489 |
SCREW-HH Price: $1.70 |
| 10 |
131-3181 |
BRACKET-LOCK Price: $21.73 |
| 11 |
321-9 |
SCREW-HH Price: $0.27 |
| 12 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 13 |
33093-00 |
WASHER-FLAT Price: $0.70 |
| 14 |
2411-41 |
ROD END-BALL JOINT Price: $40.28 |
| 15 |
99-3545 |
SPACER Price: $6.45 |
| 16 |
74-9110 |
PAD-PEDAL, REVERSE Price: $13.49 |
| 17 |
140-5254 |
BRACKET-MOW This part replaces 131-3182. Price: $7.14 |
| 18 |
3296-56 |
NUT-LOCK, NI Price: $2.09 |
| 19 |
131-3177 |
SHAFT-PEDAL Price: $47.72 |
| 20 |
3234-29 |
SCREW-HHF Price: $1.84 |
| 21 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 23 |
33115-016 |
SCREW-HH Price: $0.75 |
| 24 |
140-6108 |
PIN-FLAG, NEUTRAL LOCK This part replaces 94-1300. Price: $31.21 |
| 25 |
94-1386 |
SHAFT-PEDAL Price: $44.42 |
| 26 |
2411-38 |
JOINT-BALL Price: $21.96 |
| 27 |
74-9100 |
PAD-PEDAL, FORWARD Price: $27.08 |
| 28 |
117-9507 |
PEDAL-ACCELERATOR Price: $12.86 |
| 29 |
32121-45 |
PIN-SPRING Price: $0.27 |
| 30 |
131-3178 |
ADAPTOR-SENSOR Price: $41.44 |
| 31 |
7-3590 |
WASHER Price: $1.95 |
| 32 |
32151-62 |
RING-RETAINING Price: $1.49 |
| 33 |
131-3187 |
V-RING Price: $9.99 |
| 34 |
122-0055 |
SENSOR POSITION Price: $115.68 |
| 35 |
131-3184 |
SHIELD-SENSOR Price: $14.41 |
